User's Manual

Date: 2011/5/16
Preliminary data subjects to change without notice
2
MDD-24R2001
2.4GHz Digital
Audio Video
Modules
C: Specification
Parameter Min. Typ. Max. Unit
Electrical Section
Supply Voltage 4.9 5.0 5.1 V
Supply current in TX mode 200 mA
Supply current in RX mode 65 mA
RF Section
Modulation Mode QPSK,16QAM
Operating Frequency 2403 ~ 2475 MHz
Channel Bandwidth 3 MHz
Channel 25 channels
Data Rate 3M ~ 12M bps
Transmitter Section
Transmission Power
+14 @16QAM
+18 @QPSK
dBm
Power control range
40 dB
Power control resolution 1 1 3 dB
Receiver Section
Overlay channel spacing 1 MHz
Sensitivity
-78 @ 16QAM
-86 @ QPSK
dBm
Operation
Operating Temperature -10 ~ +60
℃
Storage Temperature -20 ~ +70
℃
