184PIN DDR266 Unbuffered DIMM
512MB With 32Mx8 CL2.5
Transcend Information Inc.
2
Dimensions
Side Millimeters Inches
A 133.35±0.20 5.250±0.008
B 72.39 2.850
C 6.35 0.250000
D 2.20 0.0870
E 30.48±0.20 1.200±0.008
F 19.80 0.779
G 4.00 0.157
H 12.00 0.472
I 1.27±0.10 0.050±0.004
(Refer Placement)
Pin Identification
Symbol Function
A0~A12,BA0,BA1 Address input
DQ0~DQ63, Data Input / Output.
DQS0~DQS7 Data strobe input/output
CK0, /CK0, CK1,
/CK1, CK2, /CK2
Clock Input.
CKE0,CKE1 Clock Enable Input.
/CS0,/CS1 Chip Select Input.
/RAS Row Address Strobe
/CAS Column Address Strobe
/WE Write Enable
DM0~DM7 Data-in Mask
VDD +2.5 Voltage power supply
VDDQ +2.5 Voltage Power Supply for DQS
VREF Power Supply for Reference
VDDSPD
+2.5 Voltage Serial EEPROM
Power Supply
SA0~SA2 Address in EEPROM
SCL Serial PD Clock
SDA Serial PD Add/Data input/output
VSS Ground
NC No Connection
