Data Sheet

SMART Attributes
The following table shows the vendor specific data in byte 2 to 361 of the 512-byte SMART data
Attribute
ID (hex)
Raw Attribute Value Attribute Name
01 MSB 00 00 00 00 00 00 Read Error Rate
05 LSB MSB 00 00 00 00 00 Reallocated sectors count
09 LSB - - MSB 00 00 00 Power-on hours
0C LSB - - MSB 00 00 00 Power Cycle Count
94 LSB - - MSB 00 00 00 SLC Total Erase Count
95 LSB - - MSB 00 00 00 SLC Max Erase Count
96 LSB - - MSB 00 00 00 SLC Min Erase Count
97 LSB - - MSB 00 00 00 SLC Average Erase Count
9F LSB - - MSB 00 00 00 DRAM one bit error count
A0 LSB - - MSB 00 00 00 Uncorrectable sectors count when read/write
A1 LSB MSB 00 00 00 00 00 Number of valid spare blocks
A3 LSB MSB 00 00 00 00 00 Number of initial invalid blocks
A4 LSB - - MSB 00 00 00 TLC Total erase count
A5 LSB - - MSB 00 00 00 TLC Maximum erase count
A6 LSB - - MSB 00 00 00 TLC Minimum erase count
A7 LSB - - MSB 00 00 00 TLC Average erase count
A8 LSB - - MSB 00 00 00 Max Erase count of spec
A9 LSB - - MSB 00 00 00 Remain Life (percentage)
B1 LSB - - MSB 00 00 00 Total wear level count
B5 LSB - - MSB 00 00 00 Total program fail count
B6 LSB MSB 00 00 00 00 00 Total erase fail count
C0 LSB MSB 00 00 00 00 00 Power-off retract Count
C2 MSB 00 00 00 00 00 00 Enclosure temperature
C3 LSB - - MSB 00 00 00 Hardware ECC recovered
C4 LSB - - MSB 00 00 00 Reallocation event count
C7 LSB MSB 00 00 00 00 00 Ultra DMA CRC Error Count
E8 LSB MSB 00 00 00 00 00 Available reserved space
F1 LSB - - - - - MSB Total LBA written (each write unit = 32MB)
F2 LSB - - - - - MSB Total LBA read (each read unit = 32MB)
F5 LSB - - - - - MSB Flash write sector count
