User's Manual

M-FALCON2 Rev B
Copyright © 2000 Trango Systems, Inc. (All rights reserved)
2
Quick Start Guide
1• Verify proper operation of camera and monitor/event
recorder using coaxial cable prior to installing wireless link.
2• Install transmitter (VTX5900) and receiver (VRX5900) units
to a steel pole in desired location per installation drawing
(see Figure 1A). The pole must be securely mounted so that
it does not move, and may be from 1.5” to 3” in diameter.
3• Install antennas above the enclosures.
WARNING
USE EXTREME CARE WHEN INSTALLING ANTENNAS
NEAR POWER LINES.
4• Slide heatshrink over antenna cable. Tighten antenna cable
to receiver and transmitter. Heat the heatshrink until it
contracts around the connector junction.
5• Connect video, audio, power, alarm, PC interface cables as
needed to units through flanges. Tighten flanges to allow
small air gap at bottom of enclosure.
IMPORTANT NOTE:
Power adapter must be kept dry.
6• Verify that LEDs are lit up and transmitter and receiver are
on same channel.
7• Tighten lid of enclosure.
8• To help protect against potential lightning damage, use a
lightning surge arrestor in line with all cabling entering a
structure and at the antenna input.
