Installation and Maintenance Manual

Installation - Electrical
84 RLC-SVX09H-EN
Table 75. Electrical Data - RTWD - 50 Hz - high efficiency - standard condensing temperature
Unit
Size
Rated
Voltage
Unit Wiring
Single Point Power -
1 Power Connection
Dual Point Power -
2 Power Connections Motor Data
MCA MOP MCA MOP RLA LRA YD LRA XL
60 400/50/3 88 125 50/48 80/80 38/38 112/112 370/370
70 400/50/3 103 125 58/56 100/100 45/45 129/129 427/427
80 400/50/3 121 175 58/74 100/125 45/59 129/144 427/462
90 400/50/3 135 175 76/74 125/125 59/59 144/144 462/462
100 400/50/3 150 200 76/89 125/150 59/71 144/180 462/589
110 400/50/3 162 225 91/89 150/150 71/71 180/180 589/589
120 400/50/3 178 250 91/105 150/175 71/84 180/217 589/668
130 400/50/3 192 250 108/105 175/175 84/84 217/217 668/668
140 400/50/3 209 300 108/123 175/200 84/98 217/259 668/796
160 400/50/3 223 300 125/123 200/200 98/98 259/259 796/796
180 400/50/3 247 350 125/147 200/250 98/117 259/291 796/896
200 400/50/3 266 350 149/147 250/250 117/117 291/291 896/896
220 400/50/3 296 400 149/177 250/300 117/141 291/354 896/1089
250 400/50/3 320 450 179/177 300/300 141/141 354/354 1089/1089
Notes:
1. Voltage Utilization Range: +/- 10% of rated voltage. Rated voltage (use range): 400/50/3 (360-440)
2. MCA–minimum circuit ampacity
3. MOP–maximum overcurrent protection
4. RLA–rated load amps are rated in accordance with UL Standard 1995.
5. LRA–locked rotor amps are based on full winding starts.
6. LRA YD–Locked Rotor Amps in Wye configuration. LRA XL–Locked Rotor Amps in the Delta configuration.
7. Local codes may take precedence.
8. Data containing information on two circuits shown as follows: circuit 1/circuit 2.
9. Standard condensing temperature option refers to entering condenser water temperatures 95°F (35°C) or below.
Table 76. Electrical Data - RTWD - 50 Hz - high efficiency - high condensing temperature
Unit
Size
Rated
Voltage
Unit Wiring
Single Point Power -
1 Power Connection
Dual Point Power -
2 Power Connections Motor Data
MCA MOP MCA MOP RLA LRA YD LRA XL
60 400/50/3 110 150 62/60 110/100 48/48 112/112 370/370
70 400/50/3 133 175 75/73 125/125 58/58 129/129 427/427
80 400/50/3 153 225 75/93 125/150 58/74 129/144 427/462
90 400/50/3 169 225 95/93 150/150 74/74 144/144 462/462
100 400/50/3 186 250 95/110 150/175 74/88 144/180 462/589
110 400/50/3 200 250 112/110 200/175 88/88 180/180 589/589
120 400/50/3 215 300 112/125 200/225 88/100 180/217 589/668
130 400/50/3 226 300 128/123 225/200 100/98 217/217 668/668
150 400/50/3 250 350 128/148 225/250 100/118 217/259 668/796
160 400/50/3 268 350 150/148 250/250 118/118 259/259 796/796
180 400/50/3 297 400 150/177 250/300 118/141 259/291 796/896
200 400/50/3 320 450 179/177 300/300 141/141 291/291 896/896
220 400/50/3 352 500 179/209 300/350 141/167 291/354 896/1089
250 400/50/3 378 500 211/209 350/350 167/167 354/354 1089/1089
Notes:
1. Voltage Utilization Range: +/- 10% of rated voltage. Rated voltage (use range): 400/50/3 (360-440)
2. MCA–minimum circuit ampacity
3. MOP–maximum overcurrent protection
4. RLA–rated load amps are rated in accordance with UL Standard 1995.
5. LRA–locked rotor amps are based on full winding starts.
6. LRA YD–Locked Rotor Amps in Wye configuration. LRA XL–Locked Rotor Amps in the Delta configuration.
7. Local codes may take precedence.
8. Data containing information on two circuits shown as follows: circuit 1/circuit 2.
9. High condensing temperature option refers to entering condenser water temperatures above 95°F (35°C).
