Installation and Maintenance Manual

Installation - Electrical
80 RLC-SVX09H-EN
250
200/60/3 752 1000 420/415 700/700 332/332 701/701 2156/2156
230/60/3 654 800 365/362 600/600 289/289 571/571 1756/1756
380/60/3 408 500 228/225 400/400 180/180 345/345 1060/1060
460/60/3 329 450 184/182 300/300 145/145 285/285 878/878
575/60/3 263 350 147/145 250/250 116/116 229/229 705/705
Notes:
1. Voltage Utilization Range: +/- 10% of rated voltage
Rated voltage (use range): 208/60/3 (187.2-228.8), 230/60/3(208-254), 380/60/3 (342-418), 460/60/3 (414-506), 575/60/3 (516-633)MCA–
minimum circuit ampacity
2. MOP–maximum overcurrent protection
3. RLA–rated load amps are rated in accordance with UL Standard 1995.
4. LRA–locked rotor amps are based on full winding starts.
5. LRA YD–Locked Rotor Amps in Wye configuration. LRA XL–Locked Rotor Amps in the Delta configuration.
6. Local codes may take precedence.
7. Data containing information on two circuits shown as follows: circuit 1/circuit 2.
8. High condensing temperature option refers to entering condenser water temperatures above 95°F (35°C).
Table 70. Electrical Data - RTWD - 60 Hz - high efficiency - high condensing temperature (continued)
Unit
Size
Rated
Voltage
Unit Wiring
Single Point Power -
1 Power Connection
Dual Point Power -
2 Power Connections Motor Data
MCA MOP MCA MOP RLA LRA YD LRA XL
Table 71. Electrical Data - RTWD - 60 Hz - premium efficiency - high condensing temperature
Unit
Size
Rated
Voltage
Unit Wiring
Single Point Power -
1 Power Connection
Dual Point Power -
2 Power Connections Motor Data
MCA MOP MCA MOP RLA LRA YD LRA XL
150
200/60/3 498 700 252/295 400/500 198/236 419/487 1368/1498
230/60/3 430 600 219/254 350/450 172/203 367/427 1200/1314
380/60/3 266 350 138/155 225/250 108/124 229/260 747/801
460/60/3 218 300 112/128 175/225 88/102 184/212 600/652
575/60/3 178 250 91/105 150/175 71/84 148/172 483/528
160
200/60/3 536 700 300/295 500/500 236/236 487/487 1498
230/60/3 461 600 258/254 450/450 203/203 427/427 1314/1314
380/60/3 282 400 158/155 250/250 124/124 260/260 801/801
460/60/3 232 300 130/128 225/225 102/102 212/212 652/652
575/60/3 191 250 107/105 175/175 84/84 172/172 528/528
180
200/60/3 583 800 300/343 500/600 236/274 487/600 1498/1845
230/60/3 511 700 258/304 450/500 203/243 427/506 1314/1556
380/60/3 307 450 158/180 250/300 124/144 260/316 801/973
460/60/3 253 350 130/149 225/250 102/119 212/252 652/774
575/60/3 207 300 107/122 175/200 84/97 172/205 528/631
200
200/60/3 621 800 347/343 600/600 274/274 600/600 1845/1845
230/60/3 551 700 308/304 500/500 243/243 506/506 1556/1556
380/60/3 327 450 183/180 300/300 144/144 316/316 973/973
460/60/3 270 350 151/149 250/250 119/119 252/252 774/774
575/60/3 220 300 123/122 200/200 97/97 205/205 631/631
Notes:
1. Voltage Utilization Range: +/- 10% of rated voltage
Rated voltage (use range): 208/60/3 (187.2-228.8), 230/60/3(208-254), 380/60/3 (342-418), 460/60/3 (414-506), 575/60/3 (516-633)
2. MCA–minimum circuit ampacity
3. MOP–maximum overcurrent protection
4. RLA–rated load amps are rated in accordance with UL Standard 1995.
5. LRA–locked rotor amps are based on full winding starts.
6. LRA YD–Locked Rotor Amps in Wye configuration. LRA XL–Locked Rotor Amps in the Delta configuration.
7. Local codes may take precedence.
8. Data containing information on two circuits shown as follows: circuit 1/circuit 2.
9. High condensing temperature option refers to entering condenser water temperatures above 95°F (35°C).
