Installation and Maintenance Manual

Installation - Electrical
RLC-SVX09H-EN 77
120
200/60/3 347 500 177/205 300/350 138/164 355/419 1137/1368
230/60/3 302 400 154/179 250/300 120/143 294/367 942/1200
380/60/3 184 250 93/109 150/175 73/87 177/229 566/747
460/60/3 152 200 77/90 125/150 60/72 147/184 471/600
575/60/3 121 175 61/71 100/125 48/57 118/148 377/483
130
200/60/3 373 500 209/205 350/350 164/164 419/419 1368/1368
230/60/3 325 450 182/179 300/300 143/143 367/367 1200/1200
380/60/3 198 250 111/109 175/175 87/87 229/229 747/747
460/60/3 164 225 92/90 150/150 72/72 184/184 600/600
575/60/3 130 175 73/71 125/125 57/57 148/148 483/483
150
200/60/3 414 600 210/245 350/400 164/196 419/487 1368/1498
230/60/3 361 500 183/214 300/350 143/171 367/427 1200/1314
380/60/3 218 300 111/129 175/225 87/103 229/260 747/801
460/60/3 182 250 92/108 150/175 72/86 184/212 600/652
575/60/3 145 200 73/87 125/150 57/69 148/172 483/528
160
200/60/3 446 600 250/245 400/400 196/196 487/487 1498/1498
230/60/3 389 500 218/214 350/350 171/171 427/427 1314/1314
380/60/3 234 300 131/129 225/225 103/103 260/260 801/801
460/60/3 196 250 110/108 175/175 86/86 212/212 652/652
575/60/3 157 225 88/87 150/150 69/69 172/172 528/528
180
200/60/3 484 700 250/284 400/500 196/227 487/600 1498/1845
230/60/3 421 600 218/247 350/400 171/197 427/506 1314/1556
380/60/3 256 350 131/150 225/250 103/120 260/316 801/973
460/60/3 213 300 110/125 175/225 86/100 212/252 652/774
575/60/3 171 250 88/100 150/175 69/80 172/205 528/631
200
200/60/3 515 700 288/284 500/500 227/227 600/600 1845/1845
230/60/3 447 600 250/247 400/400 197/197 506/506 1556/1556
380/60/3 273 350 153/150 250/250 120/120 316/316 973/973
460/60/3 227 300 127/125 225/225 100/100 252/252 774/774
575/60/3 182 250 102/100 175/175 80/80 205/205 631/631
220
200/60/3 583 800 288/352 500/600 227/281 600/701 1845/2156
230/60/3 509 700 250/308 400/500 197/246 506/571 1556/1756
380/60/3 309 450 153/187 250/300 120/149 316/345 973/1060
460/60/3 256 350 127/154 225/250 100/123 252/285 774/878
575/60/3 204 300 102/123 175/200 80/98 205/229 631/705
250
200/60/3 637 800 356/352 600/600 281/281 701/701 2156/2156
230/60/3 558 800 312/308 500/500 246/246 571/571 1756/1756
380/60/3 338 450 189/187 300/300 149/149 345/345 1060/1060
460/60/3 279 700 156/154 250/250 123/123 285/285 878/878
575/60/3 222 300 124/123 200/200 98/98 229/229 705/705
Notes:
1. Voltage Utilization Range: +/- 10% of rated voltage
Rated voltage (use range): 208/60/3 (187.2-228.8), 230/60/3(208-254), 380/60/3 (342-418), 460/60/3 (414-506), 575/60/3 (516-633)
2. MCA–minimum circuit ampacity
3. MOP–maximum overcurrent protection
4. RLA–rated load amps are rated in accordance with UL Standard 1995.
5. LRA–locked rotor amps are based on full winding starts.
6. LRA YD–Locked Rotor Amps in Wye configuration. LRA XL–Locked Rotor Amps in the Delta configuration.
7. Local codes may take precedence.
8. Data containing information on two circuits shown as follows: circuit 1/circuit 2.
9. Standard condensing temperature option refers to entering condenser water temperatures 95°F/35°C) and below.
Table 68. Electrical Data - RTWD - 60 Hz - high efficiency - standard condensing temperature (continued)
Unit
Size
Rated
Voltage
Unit Wiring
Single Point Power -
1 Power Connection
Dual Point Power -
2 Power Connections Motor Data
MCA MOP MCA MOP RLA LRA YD LRA XL
