RLC-SVX09H-EN 75
Installation - Electrical
General Recommendations
All wiring must comply with local codes and the National
Electric Code.Typical field wiring diagrams are included at
the end of the manual. Minimum circuit ampacities and
other unit electrical data are on the unit nameplate and in
Table 67. See the unit order specifications for actual
electrical data. Specific electrical schematics and
connection diagrams are shipped with the unit. Important: Do not allow conduit to interfere with other
components, structural members or
equipment. Control voltage (115V) wiring in
conduit must be separate from conduit
carrying low voltage (<30V) wiring. To
prevent control malfunctions, do not run
low voltage wiring (<30V) in conduit with
conductors carrying more than 30 volts.
NOTICE: WARNING
Hazardous Voltage!
Disconnect all electric power, including remote
disconnects before servicing. Follow proper lockout/
tagout procedures to ensure the power can not be
inadvertently energized. Failure to disconnect power
before servicing could result in death or serious injury.
NOTICE:
Use Copper Conductors Only!
Unit terminals are not designed to accept other types
of conductors. Failure to use copper conductors could
result in equipment damage.
Table 67. Electrical Data - RTWD - 60 Hz - standard efficiency - standard condensing temperature
Unit
Size
Rated
Voltage
Unit Wiring
Single Point Power -
1 Power Connection
Dual Point Power -
2 Power Connections Motor Data
MCA MOP MCA MOP RLA LRA YD LRA XL
80
200/60/3 216 300 122/118 200/200 94/94 276/276 912/912
230/60/3 188 250 106/103 175/175 82/82 238/238 786/786
380/60/3 115 150 65/63 110/110 50/50 138/138 456/456
460/60/3 94 125 53/51 90/90 41/41 114/114 376/376
575/60/3 76 100 43/41 70/70 33/33 93/93 308/308
90
200/60/3 249 350 140/136 225/225 109/109 304/304 1003/1003
230/60/3 217 300 122/119 200/200 95/95 262/262 866/866
380/60/3 130 175 73/71 125/125 57/57 161/161 530/530
460/60/3 110 150 62/60 100/100 48/48 131/131 433/433
575/60/3 87 110 49/48 80/80 38/38 105/105 346/346
100
200/60/3 291 400 140/178 225/300 109/142 304/355 1003/1137
230/60/3 252 350 122/154 200/250 95/123 262/294 866/942
380/60/3 153 225 73/94 125/150 57/75 161/177 530/566
460/60/3 127 175 62/78 100/125 48/62 131/147 433/471
575/60/3 102 150 49/63 80/110 38/50 105/118 346/377
110
200/60/3 324 450 182/178 300/300 142/142 355/355 1137/1137
230/60/3 280 400 157/154 250/250 123/123 294/294 942/942
380/60/3 171 225 96/94 150/150 75/75 177/177 566/566
460/60/3 141 200 80/78 125/125 62/62 147/147 471/471
575/60/3 114 150 64/63 110/110 50/50 118/118 377/377
120
200/60/3 356 500 182/210 300/350 142/168 355/419 1137/1368
230/60/3 309 450 157/183 250/300 123/146 294/367 942/1200
380/60/3 187 250 96/110 150/175 75/88 177/229 566/747
460/60/3 155 225 79/91 125/150 62/73 147/184 471/600
575/60/3 125 175 64/74 110/125 50/59 118/148 377/483
