Installation - Mechanical
68 RLC-SVX09H-EN
Table 55. Discharge (hot gas) line sizing RTUD 110 ton
Leaving Water
Temperature
Leaving Water
Temperature
Ckt 1
Line
38-65
°F
10-37
°F
Ckt 2
Line
38-65
°F
10-37
°F
Total
Equiv.
Length
(ft)
25
2.125 2.125
Total
Equiv.
Length
(ft)
25
2.125 2.125
50
2.125 2.125 50 2.125 2.125
75
2.125 2.125 75 2.125 2.125
100
2.125 2.125 100 2.125 2.125
125
2.125 2.125 125 2.125 2.125
150
2.625 2.125 150 2.625 2.125
175
2.625 2.125 175 2.625 2.125
200
2.625 2.625 200 2.625 2.125
225
2.625 2.625 225 2.625 2.625
250
2.625 2.625 250 2.625 2.625
275
2.625 2.625 275 2.625 2.625
300
2.625 2.625 300 2.625 2.625
Table 56. Discharge (hot gas) line sizing RTUD 120 ton
Leaving Water
Temperature
Leaving Water
Temperature
Ckt 1
Line
38-65
°F
10-37
°F
Ckt 2
Line
38-65
°F
10-37
°F
Total
Equiv.
Length
(ft)
25
2.625 2.125
Total
Equiv.
Length
(ft)
25
2.625 2.125
50
2.625 2.125 50 2.625 2.125
75
2.625 2.125 75 2.625 2.125
100
2.625 2.125 100 2.625 2.125
125
2.625 2.125 125 2.625 2.125
150
2.625 2.125 150 2.625 2.125
175
2.625 2.125 175 2.625 2.625
200
2.625 2.625 200 2.625 2.625
225
2.625 2.625 225 2.625 2.625
250
2.625 2.625 250 2.625 2.625
275
2.625 2.625 275 2.625 2.625
300
2.625 2.625 300 2.625 2.625
Table 57. Discharge (hot gas) line sizing RTUD 130 ton
Leaving Water
Temperature
Leaving Water
Temperature
Ckt 1
Line
38-65
°F
10-37
°F
Ckt 2
Line
38-65
°F
10-37
°F
Total
Equiv.
Length
(ft)
25
2.625 2.625
Total
Equiv.
Length
(ft)
25
2.625 2.125
50
2.625 2.625 50 2.625 2.125
75
2.625 2.625 75 2.625 2.125
100
2.625 2.625 100 2.625 2.125
125
2.625 2.625 125 2.625 2.125
150
2.625 2.625 150 2.625 2.125
175
2.625 2.625 175 2.625 2.625
200
2.625 2.625 200 2.625 2.625
225
2.625 2.625 225 2.625 2.625
250
2.625 2.625 250 2.625 2.625
275
2.625 2.625 275 2.625 2.625
300
2.625 2.625 300 2.625 2.625
Table 58. Discharge (hot gas) line sizing RTUD 150 ton
Leaving Water
Temperature
Leaving Water
Temperature
Ckt 1
Line
38-65
°F
10-37
°F
Ckt 2
Line
38-65
°F
10-37
°F
Total
Equiv.
Length
(ft)
25
2.625 2.125
Total
Equiv.
Length
(ft)
25
2.625 2.625
50
2.625 2.125 50 2.625 2.625
75
2.625 2.125 75 2.625 2.625
100
2.625 2.125 100 2.625 2.625
125
2.625 2.125 125 2.625 2.625
150
2.625 2.125 150 2.625 2.625
175
2.625 2.625 175 2.625 2.625
200
2.625 2.625 200 2.625 2.625
225
2.625 2.625 225 2.625 2.625
250
2.625 2.625 250 3.125 2.625
275
2.625 2.625 275 3.125 2.625
300
2.625 2.625 300 3.125 2.625
