Installation - Mechanical
66 RLC-SVX09H-EN
Table 49. Liquid line sizing RTUD 200 ton
Height (ft)
Ckt 1
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.375 1.375 1.375 1.375 1.375 1.375
50
1.375 1.375 1.375 1.375 1.375 1.375
75
1.375 1.375 1.375 1.375 1.375 1.375
100
1.375 1.375 1.375 1.375 1.375 1.375
125
1.375 1.375 1.375 1.375 1.375 1.375
150
1.375 1.375 1.375 1.375 1.375 1.375
175
1.375 1.375 1.375 1.375 1.375 1.625
200
1.375 1.375 1.375 1.375 1.625 1.625
225
1.375 1.375 1.375 1.625 1.625 1.625
250
1.375 1.625 1.625 1.625 1.625 1.625
275
1.625 1.625 1.625 1.625 1.625 1.625
300
1.625 1.625 1.625 1.625 1.625 1.625
Ckt 2
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.375 1.375 1.375 1.375 1.375 1.375
50
1.375 1.375 1.375 1.375 1.375 1.375
75
1.375 1.375 1.375 1.375 1.375 1.375
100
1.375 1.375 1.375 1.375 1.375 1.375
125
1.375 1.375 1.375 1.375 1.375 1.375
150
1.375 1.375 1.375 1.375 1.375 1.375
175
1.375 1.375 1.375 1.375 1.375 1.625
200
1.375 1.375 1.375 1.375 1.625 1.625
225
1.375 1.375 1.375 1.625 1.625 1.625
250
1.375 1.375 1.625 1.625 1.625 1.625
275
1.625 1.625 1.625 1.625 1.625 1.625
300
1.625 1.625 1.625 1.625 1.625 1.625
Table 50. Liquid line sizing RTUD 220 ton
Height (ft)
Ckt 1
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.375 1.375 1.375 1.375 1.375 1.375
50
1.375 1.375 1.375 1.375 1.375 1.375
75
1.375 1.375 1.375 1.375 1.375 1.375
100
1.375 1.375 1.375 1.375 1.375 1.375
125
1.375 1.375 1.375 1.375 1.375 1.375
150
1.375 1.375 1.375 1.375 1.375 1.375
175
1.375 1.375 1.375 1.375 1.375 1.625
200
1.375 1.375 1.375 1.375 1.625 1.625
225
1.375 1.375 1.625 1.625 1.625 1.625
250
1.375 1.625 1.625 1.625 1.625 1.625
275
1.625 1.625 1.625 1.625 1.625 1.625
300
1.625 1.625 1.625 1.625 1.625 1.625
Ckt 2
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.375 1.375 1.375 1.375 1.375 1.375
50
1.375 1.375 1.375 1.375 1.375 1.375
75
1.375 1.375 1.375 1.375 1.375 1.375
100
1.375 1.375 1.375 1.375 1.375 1.375
125
1.375 1.375 1.375 1.375 1.375 1.375
150
1.375 1.375 1.375 1.375 1.375 1.375
175
1.375 1.375 1.375 1.375 1.625 1.625
200
1.375 1.375 1.375 1.625 1.625 1.625
225
1.375 1.625 1.625 1.625 1.625 1.625
250
1.625 1.625 1.625 1.625 1.625 1.625
275
1.625 1.625 1.625 1.625 1.625 1.625
300
1.625 1.625 1.625 1.625 1.625 1.625
Table 51. Liquid line sizing RTUD 250 ton
Height (ft)
Ckt 1
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.375 1.375 1.375 1.375 1.375 1.375
50
1.375 1.375 1.375 1.375 1.375 1.375
75
1.375 1.375 1.375 1.375 1.375 1.375
100
1.375 1.375 1.375 1.375 1.375 1.375
125
1.375 1.375 1.375 1.375 1.375 1.375
150
1.375 1.375 1.375 1.375 1.375 1.375
175
1.375 1.375 1.375 1.375 1.625 1.625
200
1.375 1.375 1.625 1.625 1.625 1.625
225
1.375 1.625 1.625 1.625 1.625 1.625
250
1.625 1.625 1.625 1.625 1.625 1.625
275
1.625 1.625 1.625 1.625 1.625 1.625
300
1.625 1.625 1.625 1.625 1.625 1.625
Ckt 2
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.375 1.375 1.375 1.375 1.375 1.375
50
1.375 1.375 1.375 1.375 1.375 1.375
75
1.375 1.375 1.375 1.375 1.375 1.375
100
1.375 1.375 1.375 1.375 1.375 1.375
125
1.375 1.375 1.375 1.375 1.375 1.375
150
1.375 1.375 1.375 1.375 1.375 1.375
175
1.375 1.375 1.375 1.375 1.625 1.625
200
1.375 1.375 1.625 1.625 1.625 1.625
225
1.375 1.625 1.625 1.625 1.625 1.625
250
1.625 1.625 1.625 1.625 1.625 1.625
275
1.625 1.625 1.625 1.625 1.625 1.625
300
1.625 1.625 1.625 1.625 1.625 1.625
Table 50. Liquid line sizing RTUD 220 ton (continued)
Height (ft)
