Installation - Mechanical
RLC-SVX09H-EN 65
Table 46. Liquid line sizing RTUD 150 ton
Height (ft)
Ckt 1
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.125 1.125 1.125 1.125 1.125 1.125
50
1.125 1.125 1.125 1.125 1.125 1.125
75
1.125 1.125 1.125 1.125 1.125 1.125
100
1.125 1.125 1.125 1.125 1.125 1.125
125
1.125 1.125 1.125 1.125 1.125 1.125
150
1.125 1.125 1.125 1.125 1.125 1.125
175
1.125 1.125 1.125 1.125 1.125 1.125
200
1.125 1.125 1.125 1.125 1.125 1.375
225
1.125 1.125 1.125 1.375 1.375 1.375
250
1.125 1.375 1.375 1.375 1.375 1.375
275
1.375 1.375 1.375 1.375 1.375 1.375
300
1.375 1.375 1.375 1.375 1.375 1.375
Ckt 2
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.125 1.125 1.125 1.125 1.125 1.125
50
1.125 1.125 1.125 1.125 1.125 1.125
75
1.125 1.125 1.125 1.125 1.125 1.125
100
1.125 1.125 1.125 1.125 1.125 1.125
125
1.125 1.125 1.125 1.125 1.125 1.125
150
1.125 1.125 1.125 1.125 1.375 1.375
175
1.125 1.375 1.375 1.375 1.375 1.375
200
1.375 1.375 1.375 1.375 1.375 1.375
225
1.375 1.375 1.375 1.375 1.375 1.375
250
1.375 1.375 1.375 1.375 1.375 1.375
275
1.375 1.375 1.375 1.375 1.375 1.375
300
1.375 1.375 1.375 1.375 1.375 1.375
Table 47. Liquid line sizing RTUD 160 ton
Height (ft)
Ckt 1
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.375 1.375 1.375 1.375 1.375 1.375
50
1.375 1.375 1.375 1.375 1.375 1.375
75
1.375 1.375 1.375 1.375 1.375 1.375
100
1.375 1.375 1.375 1.375 1.375 1.375
125
1.375 1.375 1.375 1.375 1.375 1.375
150
1.375 1.375 1.375 1.375 1.375 1.375
175
1.375 1.375 1.375 1.375 1.375 1.375
200
1.375 1.375 1.375 1.375 1.375 1.375
225
1.375 1.375 1.375 1.375 1.375 1.375
250
1.375 1.375 1.375 1.375 1.375 1.375
275
1.375 1.375 1.375 1.375 1.375 1.375
300
1.375 1.375 1.375 1.375 1.375 1.375
Ckt 2
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.375 1.375 1.375 1.375 1.375 1.375
50
1.375 1.375 1.375 1.375 1.375 1.375
75
1.375 1.375 1.375 1.375 1.375 1.375
100
1.375 1.375 1.375 1.375 1.375 1.375
125
1.375 1.375 1.375 1.375 1.375 1.375
150
1.375 1.375 1.375 1.375 1.375 1.375
175
1.375 1.375 1.375 1.375 1.375 1.375
200
1.375 1.375 1.375 1.375 1.375 1.375
225
1.375 1.375 1.375 1.375 1.375 1.375
250
1.375 1.375 1.375 1.375 1.375 1.375
275
1.375 1.375 1.375 1.375 1.375 1.375
300
1.375 1.375 1.375 1.375 1.375 1.375
Table 48. Liquid line sizing RTUD 180 ton
Height (ft)
Ckt 1
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.375 1.375 1.375 1.375 1.375 1.375
50
1.375 1.375 1.375 1.375 1.375 1.375
75
1.375 1.375 1.375 1.375 1.375 1.375
100
1.375 1.375 1.375 1.375 1.375 1.375
125
1.375 1.375 1.375 1.375 1.375 1.375
150
1.375 1.375 1.375 1.375 1.375 1.375
175
1.375 1.375 1.375 1.375 1.375 1.375
200
1.375 1.375 1.375 1.375 1.375 1.375
225
1.375 1.375 1.375 1.375 1.375 1.375
250
1.375 1.375 1.375 1.375 1.375 1.375
275
1.375 1.375 1.375 1.375 1.375 1.375
300
1.375 1.375 1.375 1.375 1.375 1.375
Ckt 2
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.375 1.375 1.375 1.375 1.375 1.375
50
1.375 1.375 1.375 1.375 1.375 1.375
75
1.375 1.375 1.375 1.375 1.375 1.375
100
1.375 1.375 1.375 1.375 1.375 1.375
125
1.375 1.375 1.375 1.375 1.375 1.375
150
1.375 1.375 1.375 1.375 1.375 1.375
175
1.375 1.375 1.375 1.375 1.375 1.625
200
1.375 1.375 1.375 1.375 1.625 1.625
225
1.375 1.375 1.375 1.625 1.625 1.625
250
1.375 1.375 1.625 1.625 1.625 1.625
275
1.375 1.625 1.625 1.625 1.625 1.625
300
1.625 1.625 1.625 1.625 1.625 1.625
Table 47. Liquid line sizing RTUD 160 ton (continued)
Height (ft)
