Installation - Mechanical
RLC-SVX09H-EN 63
Table 40. Liquid line sizing RTUD 80 ton
Height (ft)
Ckt 1
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.125 1.125 1.125 1.125 1.125 1.125
50
1.125 1.125 1.125 1.125 1.125 1.125
75
1.125 1.125 1.125 1.125 1.125 1.125
100
1.125 1.125 1.125 1.125 1.125 1.125
125
1.125 1.125 1.125 1.125 1.125 1.125
150
1.125 1.125 1.125 1.125 1.125 1.125
175
1.125 1.125 1.125 1.125 1.125 1.125
200
1.125 1.125 1.125 1.125 1.125 1.125
225
1.125 1.125 1.125 1.125 1.125 1.125
250
1.125 1.125 1.125 1.125 1.125 1.125
275
1.125 1.125 1.125 1.125 1.125 1.125
300
1.125 1.125 1.125 1.125 1.125 1.125
Ckt 2
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.125 1.125 1.125 1.125 1.125 1.125
50
1.125 1.125 1.125 1.125 1.125 1.125
75
1.125 1.125 1.125 1.125 1.125 1.125
100
1.125 1.125 1.125 1.125 1.125 1.125
125
1.125 1.125 1.125 1.125 1.125 1.125
150
1.125 1.125 1.125 1.125 1.125 1.125
175
1.125 1.125 1.125 1.125 1.125 1.125
200
1.125 1.125 1.125 1.125 1.125 1.125
225
1.125 1.125 1.125 1.125 1.125 1.125
250
1.125 1.125 1.125 1.125 1.125 1.125
275
1.125 1.125 1.125 1.125 1.125 1.125
300
1.125 1.125 1.125 1.125 1.125 1.125
Table 41. Liquid line sizing RTUD 90 ton
Height (ft)
Ckt 1
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.125 1.125 1.125 1.125 1.125 1.125
50
1.125 1.125 1.125 1.125 1.125 1.125
75
1.125 1.125 1.125 1.125 1.125 1.125
100
1.125 1.125 1.125 1.125 1.125 1.125
125
1.125 1.125 1.125 1.125 1.125 1.125
150
1.125 1.125 1.125 1.125 1.125 1.125
175
1.125 1.125 1.125 1.125 1.125 1.375
200
1.125 1.125 1.125 1.125 1.375 1.375
225
1.125 1.125 1.125 1.375 1.375 1.375
250
1.125 1.125 1.375 1.375 1.375 1.375
275
1.125 1.375 1.375 1.375 1.375 1.375
300
1.375 1.375 1.375 1.375 1.375 1.375
Ckt 2
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.125 1.125 1.125 1.125 1.125 1.125
50
1.125 1.125 1.125 1.125 1.125 1.125
75
1.125 1.125 1.125 1.125 1.125 1.125
100
1.125 1.125 1.125 1.125 1.125 1.125
125
1.125 1.125 1.125 1.125 1.125 1.125
150
1.125 1.125 1.125 1.125 1.125 1.125
175
1.125 1.125 1.125 1.125 1.125 1.375
200
1.125 1.125 1.125 1.125 1.375 1.375
225
1.125 1.125 1.125 1.375 1.375 1.375
250
1.125 1.125 1.375 1.375 1.375 1.375
275
1.125 1.375 1.375 1.375 1.375 1.375
300
1.375 1.375 1.375 1.375 1.375 1.375
Table 42. Liquid line sizing RTUD 100 ton
Height (ft)
Ckt 1
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.125 1.125 1.125 1.125 1.125 1.125
50
1.125 1.125 1.125 1.125 1.125 1.125
75
1.125 1.125 1.125 1.125 1.125 1.125
100
1.125 1.125 1.125 1.125 1.125 1.125
125
1.125 1.125 1.125 1.125 1.125 1.125
150
1.125 1.125 1.125 1.125 1.125 1.125
175
1.125 1.125 1.125 1.125 1.125 1.125
200
1.125 1.125 1.125 1.125 1.125 1.125
225
1.125 1.125 1.125 1.125 1.125 1.375
250
1.125 1.125 1.125 1.125 1.375 1.375
275
1.125 1.125 1.125 1.375 1.375 1.375
300
1.125 1.125 1.375 1.375 1.375 1.375
Ckt 2
Line
< 0 3 6 9 12 15
Total
Equiv.
Length
(ft)
25
1.125 1.125 1.125 1.125 1.125 1.125
50
1.125 1.125 1.125 1.125 1.125 1.125
75
1.125 1.125 1.125 1.125 1.125 1.125
100
1.125 1.125 1.125 1.125 1.125 1.125
125
1.125 1.125 1.125 1.125 1.125 1.125
150
1.125 1.125 1.125 1.125 1.125 1.125
175
1.125 1.125 1.125 1.125 1.125 1.125
200
1.125 1.125 1.125 1.125 1.375 1.375
225
1.125 1.125 1.125 1.375 1.375 1.375
250
1.125 1.125 1.375 1.375 1.375 1.375
275
1.375 1.375 1.375 1.375 1.375 1.375
300
1.375 1.375 1.375 1.375 1.375 1.375
Table 41. Liquid line sizing RTUD 90 ton (continued)
Height (ft)
