Installation - Mechanical
RLC-SVX09H-EN 39
Table 30. RTWD Center of gravity, 60Hz - Figure 17 - in (mm)
Standard Efficiency
High Efficiency
Unit X Y Z X Y Z
80 61 (1543) 34 (868) 15 (381) 55 (1393) 35 (879) 16 (394)
90 61 (1544) 34 (868) 15 (381) 55 (1395) 35 (877) 16 (394)
100 62 (1566) 35 (879) 15 (382) 55 (1409) 34 (869) 15 (390)
110 61 (1547) 35 (891) 15 (383) 55 (1391) 35 (880) 15 (391)
120 60 (1534) 34 (876) 15 (390) 55 (1393) 35 (879) 15 (391)
130 60 (1535) 35 (876) 15 (391) 55 (1394) 35 (879) 15 (392)
140 63 (1607) 36 (903) 16 (403) - - -
Table 31. RTWD Center of gravity, 50Hz - Figure 17 - in (mm)
Standard Efficiency
High Efficiency
Unit X Y Z X Y Z
60 - - - 55 (1393) 35 (879) 16 (395)
70 61 (1543) 34 (868) 15 (381) 55 (1393) 35 (878) 16 (395)
80 62 (1567) 34 (875) 15 (384) 56 (1416) 35 (885) 16 (397)
90 61 (1562) 35 (882) 15 (387) 55 (1405) 34 (871) 16 (395)
100 61 (1562) 35 (886) 15 (385) 55 (1405) 34 (876) 15 (393)
110 61 (1547) 35 (891) 15 (383) 55 (1393) 35 (879) 15 (391)
120 63 (1612) 36 (905) 16 (403) 57 (1460) 36 (907) 16 (404)
130 63 (1591) 37 (929) 16 (414) 55 (1393) 35 (879) 16 (395)
140 63 (1590) 37 (929) 16 (414) - - -
150 63 (1590) 37 (927) 16 (414) - - -
Table 32. RTWD Center of gravity, 60Hz - Figure 18 - in (mm)
High Efficiency
Premium Efficiency
Unit X Y Z X Y Z
No Panel
150 60 (1518) 38 (959) 17 (441) 70 (1773) 37 (949) 17 (434)
160 58 (1478) 39 (989) 18 (449) 68 (1740) 39 (980) 17 (441)
180 58 (1481) 39 (987) 18 (449) 68 (1740) 38 (978) 17 (442)
200 58 (1482) 39 (985) 18 (449) 68 (1741) 38 (977) 17 (441)
220 60 (1513) 40 (1006) 18 (446) - - -
250 59 (1507) 40 (1019) 18 (451) - - -
With Panel
150 59 (1511) 39 (995) 15 (391) 70 (1772) 39 (986) 15 (388)
160 58 (1475) 40 (1020) 16 (401) 68 (1741) 40 (1012) 16 (397)
180 58 (1478) 40 (1018) 16 (401) 69 (1742) 40 (1010) 16 (398)
200 58 (1479) 40 (1016) 16 (402) 69 (1742) 40 (1008) 16 (398)
220 59 (1508) 41 (1035) 16 (404) - - -
250 59 (1502) 41 (1046) 16 (411) - - -
