Installation - Mechanical
RLC-SVX09H-EN 37
Table 27. RTWD Corner weights, 50 Hz - Figure 16 -lb(kg)
Corner Weights - lb (kg)
Operating Weight-lb (kg)Unit G1 G2 G3 G4
High Efficiency, With Panel
130 1889 (857) 2211 (1003) 1884 (855) 2205 (1000) 8190 (3714)
140 1904 (863) 2231 (1012) 1899 (861) 2225 (1009) 8258 (3745)
160 1927 (874) 2257 (1023) 1921 (871) 2250 (1020) 8355 (3789)
180 1931 (876) 2314 (1049) 2060 (934) 2468 (1119) 8773 (3979)
200 2195 (995) 2628 (1192) 2239 (1015) 2681 (1216) 9743 (4418)
220 2208 (1001) 2635 (1195) 2250 (1021) 2686 (1218) 9779 (4435)
250 2241 (1016) 2686 (1218) 2281 (1035) 2735 (1240) 9943 (4510)
Premium Efficiency, With Panel
160 2106 (955) 2396 (1087) 2138 (970) 2433 (1103) 9073 (4115)
180 2127 (964) 5491 (1130) 2286 (1037) 2677 (1214) 9580 (4345)
200 2245 (1018) 2723 (1235) 2291 (1039) 2778 (1260) 10045 (4555)
Table 28. RTUD Corner weights, 60 Hz - Figure 15 -lb(kg)
Corner Weights - lb (kg)
Operating Weight-lb (kg)Unit G1 G2 G3 G4
High Efficiency
80 1331 (605) 1254 (570) 1173 (533) 1104 (502) 4874 (2211)
90 1338 (608) 1258 (572) 1179 (536) 1109 (504) 4892 (2219)
100 1357 (617) 1280 (582) 1247 (567) 1177 (535) 5073 (2301)
110 1454 (661) 1357 (617) 1296 (589) 1210 (550) 5326 (2416)
120 1468 (666) 1367 (620) 1310 (594) 1219 (553) 5366 (2434)
130 1468 (666) 1367 (620) 1310 (594) 1219 (553) 5366 (2434)
Table 29. RTUD Corner weights, 60 Hz - Figure 16 -lb(kg)
Corner Weights - lb (kg)
Operating Weight-lb (kg)Unit G1 G2 G3 G4
High Efficiency, No Panel
150 964 (438) 1399 (636) 1168 (531) 1698 (772) 5240 (2377)
160 1087 (494) 1775 (807) 1221 (555) 1995 (907) 6089 (2762)
180 1111 (505) 1780 (809) 1252 (569) 2992 (910) 6158 (2793)
200 1162 (528) 1813 (824) 1276 (580) 1991 (905) 6257 (2838)
220 1148 (522) 1837 (835) 1377 (626) 2200 (1000) 6576 (2983)
250 1192 (542) 1956 (889) 1406 (639) 2308 (1049) 6878 (3120)
High Efficiency, With Panel
150 1242 (564) 1549 (704) 1386 (630) 1729 (786) 5917 (2684)
160 1522 (692) 1709 (777) 1676 (762) 1881 (855) 6803 (3086)
180 1549 (704) 1714 (779) 1707 (776) 1890 (859) 6876 (3119)
200 1606 (730) 1745 (793) 1731 (787) 1881 (855) 6980 (3166)
220 1582 (719) 1782 (810) 1844 (838) 2077 (944) 7300 (3311)
250 1628 (740) 1901 (864) 1872 (851) 2185 (993) 7602 (3448)
