Installation - Mechanical
36 RLC-SVX09H-EN
Table 24. RTWD Corner weights, 60 Hz - Figure 16 -lb(kg)
Corner Weights - lb (kg)
Operating Weight-lb (kg)Unit G1 G2 G3 G4
High Efficiency, No Panel
150 1425 (646) 2102 (953) 1482 (672) 2185 (991) 7194 (3262)
160 1524 (691) 2361 (1071) 1498 (680) 2322 (1053) 7706 (3495)
180 1539 (698) 2385 (1081) 1520 (689) 2356 (1068) 7798 (3537)
200 1556 (706) 2410 (1093) 1538 (698) 2383 (1081) 7887 (3577)
220 1712 (777) 2611 (1184) 1769 (802) 2697 (1223) 8789 (3986)
250 1793 (813) 2826 (1282) 1837 (833) 2895 (1313) 9352 (4241)
Premium Efficiency, No Panel
150 1638 (743) 2299 (1043) 1704 (773) 2393 (1085) 8033 (3643)
160 1716 (778) 2525 (1145) 1715 (778) 2524 (1145) 8481 (3846)
180 1736 (787) 2564 (1163) 1737 (788) 2564 (1163) 8601 (3901)
200 1749 (793) 2572 (1166) 1751 (794) 2575 (1168) 8647 (3921)
Table 25. RTWD Corner weights, 60 Hz- Figure 16 -lb(kg)
Corner Weights - lb (kg)
Operating Weight-lb (kg)Unit G1 G2 G3 G4
High Efficiency, With Panel
150 1181 (853) 2010 (911) 1937 (878) 2070 (939) 7897 (3581)
160 1987 (901) 2261 (1025) 1946 (883) 2215 (1004) 8409 (3814)
180 2002 (908) 2284 (1036) 1969 (893) 2246 (1019) 8502 (3856)
200 2020 (916) 2309 (1047) 1989 (902) 2273 (1031) 8590 (3896)
220 2171 (985) 2515 (1141) 2226 (1010) 2579 (1170) 9492 (4305)
250 2256 (1023) 2728 (1237) 2296 (1041) 2776 (1259) 10056 (4560)
Premium Efficiency, With Panel
150 2089 (947) 2195 (996) 2171 (985) 2281 (1035) 8737 (3962)
160 2173 (985) 2416 (1096) 2176 (987) 2420 (1097) 9184 (4165)
180 2194 (995) 2454 (1113) 2198 (997) 2458 (1115) 9304 (4220)
200 2207 (1001) 2461 (1116) 2213 (1004) 2468 (1119) 9350 (4240)
Table 26. RTWD Corner weights, 50 Hz- Figure 16 -lb(kg)
Corner Weights - lb (kg)
Operating Weight-lb (kg)Unit G1 G2 G3 G4
High Efficiency, No Panel
130 1429 (648) 2307 (1046) 1434 (650) 2316 (1050) 7486 (3395)
140 1443 (654) 2328 (1056) 1448 (657) 2336 (1059) 7555 (3426)
160 1465 (664) 2355 (1068) 1469 (666) 2362 (1071) 8069 (3470)
180 1480 (671) 2401 (1089) 1597 (724) 2592 (1175) 8069 (3660)
200 1735 (787) 2724 (1235) 1782 (808) 2798 (1269) 9039 (4099)
220 1748 (793) 2731 (1238) 1794 (814) 2803 (1271) 9075 (4116)
250 1779 (807) 2784 (1263) 1824 (827) 2854 (1294) 9240 (4191)
Premium Efficiency, No Panel
160 1651 (749) 2504 (1136) 1675 (759) 2540 (1152) 8370 (3796)
180 1679 (762) 2590 (1174) 1813 (822) 2796 (1268) 8877 (4026)
200 1785 (809) 2823 (1280) 1833 (831) 2900 (1315) 9341 (4236)
