Unit Dimensions/Weights
30 RLC-SVX09H-EN
Table 19. Weights - RTWD 50 Hz - IP units
Standard Efficiency High Efficiency Premium Efficiency
Model Operating (lb) Shipping (lb) Operating (lb) Shipping (lb) Operating (lb) Shipping (lb)
60 - - 5706 5525 - -
70 5874 5677 5724 5534 - -
80 6030 5807 5893 5680 - -
90 6187 5938 6319 6063 - -
100 6268 6010 6412 6145 - -
110 6332 6014 6495 6220 - -
120 6903 6614 6914 6619 - -
130 7337 7016 8177 7837 - -
140 7342 7020 8245 7884 - -
150 7395 7049 N/A N/A - -
160 - - 8342 7950 9061 8565
180 - - 8770 8351 9579 9030
200 - - 9758 9259 10060 9467
220 - - 9793 9284 - -
250 - - 9958 9398 - -
Note: All weights +/-3%. Weights include optional base rail forklifting. Subtract 300 lbs if this option is not selected.
Table 20. Weights - RTWD 50 Hz - SI units
Standard Efficiency High Efficiency Premium Efficiency
Model Operating (kg) Shipping (kg) Operating (kg) Shipping (kg) Operating (kg) Shipping (kg)
60 - - 2588 2506 - -
70 2664 2575 2596 2510 - -
80 2735 2634 2673 2576 - -
90 2806 2693 2866 2750 - -
100 2843 2726 2908 2787 - -
110 2872 2755 2946 2821 - -
120 3131 3000 3136 3002 - -
130 3328 3182 3709 3555 - -
140 3330 3184 3740 3576 - -
150 3354 3197 - - - -
160 - - 3784 3606 4110 3885
180 - - 3979 3788 4345 4096
200 - - 4426 4200 4563 4294
220 - - 4442 4211 - -
250 - - 4517 4263 - -
Note: Weights include optional base rail forklifting. Subtract 136.1 kg if this option is not selected.
