Installation and Maintenance Manual

Diagnostics
206 RLC-SVX09H-EN
Oil Analysis
Recommended – Ckt
#2
Circuit Info Latch
“Service Messages”
enabled
Diagnostic occurs when accumulated circuit
operating hours since last initialized exceeds
2000 hours. Diagnostic can be manually
cleared but will reoccur every month (720
hours on real time clock) as long as
accumulator is not re-initialized.
Remote
Oil Filter Change
Recommended – Cprsr
1A
Circuit Info Latch
“Service Messages”
enabled
Diagnostic occurs only when “service
messages” are enabled and when Oil Filter Life
remaining falls below 5%. Diagnostic can be
manually cleared but will reoccur every month
real time (720 hours on real time clock) as long
as the oil filter life remaining does not rise
above 20% (through normal calculations or
reinitializing) (Prior to RTUD Release in Fall of
09): Diagnostic occurs only when “service
messages” are enabled and when average oil
pressure drop exceeds 18%. Diagnostic can be
manually cleared but will reoccur every month
(720 hours on real time clock) as long as
average pressure drop does not fall below 16%.
Remote
Oil Filter Change
Recommended – Cprsr
2A
Circuit Info Latch
“Service Messages”
enabled
Diagnostic occurs only when “service
messages” are enabled and when Oil Filter Life
remaining falls below 5%. Diagnostic can be
manually cleared but will reoccur every month
real time (720 hours on real time clock) as long
as the oil filter life remaining does not rise
above 20% (through normal calculations or
reinitializing) (Prior to RTUD Release in Fall of
09): Diagnostic occurs only when “service
messages” are enabled and when average oil
pressure drop exceeds 18%. Diagnostic can be
manually cleared but will reoccur every month
(720 hours on real time clock) as long as
average pressure drop does not fall below 16%.
Remote
Oil Pressure System
Fault – Circuit 1
Circuit Immediate Latch
Starter Contactor
Energized [all Stop
modes]
The Intermediate Oil Pressure Transducer for
this cprsr is reading a pressure either above its
respective circuit’s Condenser Pressure by 15
Psia or more, or below its respective Suction
Pressure 10 Psia or more for 30 seconds
continuously.
Local
Oil Pressure System
Fault – Circuit 2
Circuit Immediate Latch
Starter Contactor
Energized [all Stop
modes]
The Intermediate Oil Pressure Transducer for
this cprsr is reading a pressure either above its
respective circuit’s Condenser Pressure by 15
Psia or more, or below its respective Suction
Pressure 10 Psia or more for 30 seconds
continuously.
Local
Oil Pressure
Transducer –
Compressor 1A
Circuit Immediate Latch All Bad Sensor or LLID Remote
Oil Pressure
Transducer –
Compressor 2A
Circuit Immediate Latch All Bad Sensor or LLID Remote
Outdoor Air
Temperature Sensor
Chiller
RTUD with
ACFC?NONE–
Normal
Shutdown;
OATS=INST-
Special Action
Latch All
Bad Sensor or LLID. If the outdoor temperature
is used for CHW reset, there shall be no CHW
reset. Apply slew rates per Chilled Water Reset
spec. RTUD: if this diagnostic occurs,
operational pumpdown will be performed
regardless of the last valid temperature. For
RTWD, if installed for low ambient lockout,
there shall be no LA lockout .
Remote
Table 134. Main Processor Diagnostics (continued)
Diagnostic Name
Affects
Target Severity Persistence
Active Modes
[Inactive
Modes] Criteria
Reset
Level
