Parts Ordering Information
Obtain the required parts from your localTrane Parts
Center.
Chemical Cleaning Procedure
• Scale deposits are best removed by chemical means.
Consult a qualified water treatment specialist (i.e., one
that knows the local water supply chemical/mineral
content) for a recommended cleaning solution suitable
for the job. (A standard condenser water circuit is
composed solely of copper, cast iron and steel.)
Improper chemical cleaning can damage tube walls.
All of the materials used in the external circulation system,
the quantity of the solution, the duration of the cleaning
period, and any required safety precautions should be
approved by the company furnishing the materials or
performing the cleaning.
Note: Chemical tube cleaning should always be followed
by mechanical tube cleaning.
RTUD Air Cooled Condenser Applications -
High Condenser Pressure Limit and High
Pressure Cutout Diagnostics
If a circuit experiences significant time in the High
Condenser Pressure Limit mode, or if it experiences High
Pressure Cutout trip diagnostics, the air cooled condenser
may be the root cause and should be inspected.
The condenser coils should be checked for air flow
restrictions and cleanliness, as well as the possibility of
recirculated air, in which the air entering the coil is
RTWD 150, 160, 180, 200, 220, 250 60 HIGH Return
29.9 (66) M12x1.75
RTWD 150, 160, 180, 200 60 PREM Return
RTWD 130, 140, 160, 180, 200, 220, 250 50 HIGH Return
RTWD 160, 180, 200 50 PREM Return
RTUD 150, 160, 180, 200, 220, 250 60 HIGH Return
Table 130. RTWD Condenser waterbox weights
Standard Grooved Pipe Waterbox
Model Size Hz Effic Waterbox Weight - kg (lbs) Lifting Connection
RTWD 80, 90, 100, 110, 120, 130, 140 60 STD Supply, Return
20.4 (45) M12x1.75
RTWD 80, 90, 100, 110, 120, 130 60 HIGH Supply, Return
RTWD 70, 80, 90, 100, 110, 120, 130, 140, 150 50 STD Supply, Return
RTWD 60, 70, 80, 90, 100, 110, 120 50 HIGH Supply, Return
RTWD 150, 160, 180, 200, 220, 250 60 HIGH Supply, Return
RTWD 150, 160, 180, 200 60 PREM Supply, Return
RTWD 130, 140, 160, 180, 200, 220, 250 50 HIGH Supply, Return
RTWD 160, 180, 200 50 PREM Supply, Return
RTUD 80, 90, 100, 110, 120, 130 60 HIGH Supply, Return
RTWD 150, 160, 180, 200, 220, 250 60 HIGH Supply
38.6 (85) M12x1.75
RTWD 150, 160, 180, 200 60 PREM Supply
RTWD 130, 140, 160, 180, 200, 220, 250 50 HIGH Supply
RTWD 160, 180, 200 50 PREM Supply
RTWD 150, 160, 180, 200, 220, 250 60 HIGH Return
29.9 (66) M12x1.75
RTWD 150, 160, 180, 200 60 PREM Return
RTWD 130, 140, 160, 180, 200, 220, 250 50 HIGH Return
RTWD 160, 180, 200 50 PREM Return
Table 129. RTWD/RTUD Evaporator waterbox weights (continued)
Standard Grooved Pipe Waterbox
Model Size Hz Effic Waterbox Weight - kg (lbs) Lifting Connection
Table 131. Connection devices
Unit Product
Part
Number
RTWD/RTUD -
All units
Safety Hoist Ring M12x1.75 RNG01886
