Controls Interface
RLC-SVX09H-EN 157
Diagnostics View
This window lists the active and inactive (history)
diagnostics.There can be up to 60 diagnostics, both active
and historic. For example, if there were 5 active
diagnostics, the possible number of historic diagnostics
would be 55.You can also reset active diagnostics here,
(i.e., transfer active diagnostics to history and allow the
chiller to regenerate any active diagnostics).
Top Level Mode at Last Diagnostic
Submode 1 at Last Diagnostic
Submode 2 at Last Diagnostic
Submode 3 at Last Diagnostic
Submode 4 at Last Diagnostic
Submode 5 at Last Diagnostic
Submode 6 at Last Diagnostic
Compressor Lockout
Compressor 1A Starts
Compressor 1A Running Time
Compressor Running Indicator hrs:mins
Compressor 1A Load Step
Compressor Refrigerant Discharge Temperature °F (°C)
Compressor 1A Oil Pressure psi gauge
Compressor 1A Line 1 Current % RLA
Compressor 1A Line 2 Current % RLA
Compressor 1A Line 3 Current % RLA
Line 1 Current Amps amps
Line 2 Current Amps amps
Line 3 Current Amps amps
Starter 1A Voltage Vab volts
Compressor 1A Average Line Current % RLA
Maximum Line Current %
Compressor 1A Power Consumption kW
Compressor 1A Power Factor
Circuit 2
EXV Command (%) %
EXV Position Steps steps
EXV Percent Open %
Front Panel Circuit Lockout
Evaporator Refrigerant Liquid Level in
Mode
Sub Level Mode 1
Sub Level Mode 2
Sub Level Mode 3
Sub Level Mode 4
Sub Level Mode 5
Sub Level Mode 6
Condenser Refrigerant Pressure psi gauge
Condenser Saturated Refrigerant Temperature °F (°C)
Evaporator Refrigerant Pressure psi gauge
Evaporator Saturated Refrigerant Temperature °F (°C)
Circuit Running Powered Indicator
Circuit Manual Reset Indicator (CMR)
Table 122. Status view tab - detail (continued)
Tab Control Point Name Units
Circuit Auto Reset Indicator (CAR)
Circuit Informational Warning Indicator (IFW)
Circuit Limit Min Command
Differential Refrigerant Pressure psid
Compressor 1A Service Pumpdown Status
Evaporator Approach Temperature °F (°C)
Condenser Approach Temperature °F (°C)
Compressor Refrigerant Discharge Superheat °F (°C)
Top Level Mode at Last Diagnostic
Submode 1 at Last Diagnostic
Submode 2 at Last Diagnostic
Submode 3 at Last Diagnostic
Submode 4 at Last Diagnostic
Submode 5 at Last Diagnostic
Submode 6at Last Diagnostic
Compressor Lockout
Compressor 2A Starts
Compressor 2A Running Time hrs:mins
Compressor Running Indicator
Compressor 2A Load Step
Compressor Refrigerant Discharge Temperature °F (°C)
Compressor 2A Oil Pressure psi gauge
Compressor 2A Line 1 Current % RLA
Compressor 2A Line 2 Current % RLA
Compressor 2A Line 3 Current % RLA
Line 1 Current Amps amps
Line 2 Current Amps amps
Line 3 Current Amps amps
Compressor 2A Average Line Current % RLA
Maximum Line Current %
Compressor 2A Power Factor
Manual Overrides
Manual Staging/Stepping Control
Manual Capacity Modulation Control
Evaporator Water Pump Override
Condenser Water Pump Override
Compressor 1A service Pumpdown Status
Compressor 1A Pumpdown Command
Table 122. Status view tab - detail (continued)
Tab Control Point Name Units
