Installation and Maintenance Manual

Controls Interface
152 RLC-SVX09H-EN
Chiller Current Limit Softload Start Point Setting % 20 100 40
Chiller Variable Evaporator Water Flow Compensation Setting Disable
Chiller Evaporator Pump Off Delay Setting minutes 0 30 1
Chiller Condenser Pump Off Delay Setting minutes 0 30 1
Chiller Condenser Water Pump Pre-Run Tim Setting minutes 0 30 0
Chiller Low Evaporator Leaving Water Temperature Cutout Setting °F (°C) 5 (-15) 36 (2.22) 36 (2.22)
Chiller Low Refrigerant Temperature Cutout Setting °F (°C) -5 (-20.55) 36 (2.22) 28.6 (-1.89)
Chiller High Evaporator Water Temperature Cutout Setting °F (°C) 80 (26.67) 150 (65.56) 105 (40.55)
Chiller Local Atmospheric Pressure Setting psia 68.9 110.3 101.35
Chiller Ice Building Feature Setting Enable
Chiller External Chilled (Hot Water Setpoint Enable Setting Enable
Chiller External Current Limit Setpoint Enable Setting Enable
Chiller Under (Over Voltage Protection Enable Setting Enable
Chiller LCI-C Diagnostic Language Setting English
Chiller LCI-C diagnostic Encoding Setting Text
Chiller Head Relief Relay Filter Time Setting sec 0 1200 600
Chiller Limit Relay Filter Time Setting sec 0 1200 600
Chiller Maximum Capacity Relay Filter Time Setting sec 0 1200 600
Gains
Chiller Cooling Design Delta Temperature (Waterside) Setting °F (°C) 3.6 (2) 32.4 (18) 10 (5.55)
Chiller Heating Design Delta Temperature (Waterside) Setting °F (°C) 3.6 (2) 32.4 (18) 10 (5.55)
Chiller Condenser Pressure Limit Setpoint Setting % 80 120 90
Chiller Carryover Maximum Capacity Limit Setpoint Setpoint % 50 500 500
Chiller Carryover Maximum Capacity Limit Kp Setting 0.03 2.0 .2
Chiller Carryover Maximum Capacity Limit Ti Setting sec 0.1 500 3
Chiller Carryover Maximum Capacity Limit - Input Type Setting
Condenser Head Pressure Control
Chiller Head Pressure Control Coverride Setting Auto
Chiller Off State Output Command Setting volts 0 10 2
Chiller Output Voltage at Desired Minimum Flow Setting volts 0 10 2
Chiller Desired Minimum Flow Setting % 0 100 20
Chiller Output Voltage at Desired Maximum Flow Setting volts 0 10 10
Chiller Actuator Stroke Time Setting sec 1 1000 30
Chiller Damping Coefficient Setting 0.1 1.8 0.5
Chiller Condenser Water Pump Pre-Run Time Setting minutes 0 30 0
Chiller Condenser Water Pump Pre-Run Time Remaining Status mins:secs
Chiller Head Pressure Control Output Status %
Chiller Time Till Actuator at Position Status mins:secs
Chiller Time to Safe Start of Cond Wtr Pump Status mins:secs
Starts & Hours
Chiller Chiller Running Time Status hrs:mins
Circuit 1 Compressor 1A Running Time Status hrs:mins
Circuit 1 Compressor 1A Starts Status
Circuit 1 Revise Compressor 1A Run Time Setting hrs:mins
Circuit 1 Revise Compressor 1A Starts Setting starts 0 4294967295
Circuit 2 Compressor 2A Running Time Status hrs:mins
Circuit 2 Compressor 2A Starts Status
Table 121. Unit view tabs - detail (continued)
Tab System Control Point Name Status Unit Min Max Default
