Installation and Maintenance Manual

General Information
RLC-SVX09H-EN 15
Table 7. General Data - RTWD 50 Hz - high efficiency
Size 60 70 80 90 100 110 120 130 140 160 180 200 220 250
Compressor K1/K1 K2/K2 K2/L1 L1/L1 L1/L2 L2/L2 L2/M1 M1/M1 M1/M2 M2/M2 M2/N1 N1/N1 N1/N2 N2/N2
Quantity 22222222222222
Nominal Size 40/40 45/45 45/55 55/55 55/65 65/65 65/70 70/70 70/85 85/85 85/100
100/
100
100/
120
120/
120
Evaporator
2 Pass Arrangement
Water
Conn. Size
NPS44455555555666
mm 100 100 100 125 125 125 125 125 125 125 125 150 150 150
Water
Storage
(gal) 9.8 10.6 11.9 15.3 15.3 16.4 17.3 19.2 20.3 22.3 24.2 28.6 29.9 31.8
(L) 37.0 40.2 45.2 57.9 57.9 62.3 65.4 72.6 77.0 84.5 91.5 108.3 113.3 120.3
Minimum
Flow
(gpm) 72 80 92 112 112 123 130 141 151 170 186 211 223 240
(L/s) 4.6 5.1 5.8 7.1 7.1 7.8 8.2 8.9 9.5 10.7 11.8 13.3 14.1 15.1
Maximum
Flow
(gpm) 263 291 336 408 408 448 476 515 555 622 683 773 818 879
(L/s) 16.6 18.3 21.2 25.8 25.8 28.2 30.0 32.5 35.0 39.2 43.1 48.8 51.6 55.5
3 Pass Arrangement
Water
Conn. Size
NPS33344444444444
mm 80 80 80 100 100 100 100 100 100 100 100 100 100 100
Water
Storage
(gal) 9.8 10.6 11.9 15.3 15.3 16.4 17.3 18.8 20.0 22.0 23.8 27.9 29.2 31.0
(L) 37.0 40.2 45.2 57.9 57.9 62.3 65.4 71.2 75.6 83.2 90.1 105.5 110.5 117.5
Minimum
Flow
(gpm) 48 53 61 75 75 82 86 94 101 113 124 141 149 160
(L/s) 3.1 3.4 3.9 4.7 4.7 5.2 5.5 5.9 6.4 7.1 7.8 8.9 9.4 10.1
Maximum
Flow
(gpm) 175 193 223 271 271 298 316 344 370 415 456 515 545 586
(L/s) 11.0 12.2 14.1 17.1 17.1 18.8 19.9 21.7 23.3 26.2 28.7 32.5 34.4 37.0
Condenser
Water
Conn. Size
NPS55555556666666
mm 125 125 125 125 125 125 125 150 150 150 150 150 150 150
Water
Storage
(gal) 11.9 11.9 13.8 15.3 16.6 16.6 18.0 21.6 22.9 24.6 26.2 31.1 31.1 35.2
(L) 45.1 45.1 52.2 58.1 62.7 62.7 68.3 81.7 86.8 93.0 99.2 117.8 117.8 133.3
Minimum
Flow
(gpm) 87 87 106 117 130 130 145 159 173 189 206 244 244 286
(L/s) 5.5 5.5 6.7 7.4 8.2 8.2 9.1 10.0 10.9 11.9 13.0 15.4 15.4 18.0
Maximum
Flow
(gpm) 317 317 387 427 473 473 528 584 634 695 755 896 896 1047
(L/s) 20.0 20.0 24.4 26.9 29.8 29.8 33.3 36.8 40.0 43.8 47.6 56.5 56.5 66.1
General Unit
Refrig Type R-134a R-134a R-134a R-134a R-134a R-134a R134a R-134a R-134a R-134a R134a R-134a R-134a R-134a
# Refrig
Circuits
22222222222222
Refrigerant
Charge
(lb)
99.2/
99.2
99.2/
99.2
97/97
121.3/
121.3
121.3/
123.5
121.3/
121.3
119/
119
134.5/
134.5
132.3/
136.7
134.5/
134.5
132.3/
136.7
178.6/
178.6
176.4/
183.0
180.8/
180.8
(kg) 45/45 45/45 44/44 55/55 55/56 55/55 54/54 61/61 60/62 61/61 60/62 81/81 80/83 82/82
Oil Charge
(qts)
7.2/
7.2
7.2/
7.2
7.2/
7.2
7.2/
7.2
7.2/
10.5
10.5/
10.5
10.5/
10.5
10.5/
10.5
10.5/
10.5
10.5/
10.5
10.5/
12.4
12.4/
12.4
12.4/
12.4
12.4/
12.4
(L)
6.8/
6.8
6.8/
6.8
6.8/
6.8
6.8/
6.8
6.8/
9.9
9.9/
9.9
9.9/
9.9
9.9/
9.9
9.9/
9.9
9.9/
9.9
9.9/
11.7
11.7/
11.7
11.7/
11.7
11.7/
11.7
Notes:
1. Data containing information on two circuits is shown as circuit 1/circuit 2.
2. Flow limits are for water only.
