Installation and Maintenance Manual

General Information
RLC-SVX09H-EN 13
Table 5. General Data – Condenser byTrane – 60 Hz
Size 80 90 100 110 120 130 150 160 180 200 220 250
Condenser
Condenser
Quantity
111111222222
Fins/Inch 12 10 10 12 8 10 8/12 12/12 12/8 8/8 8/10 10/10
Coil Length (in) 162 216 216 216 270 270 162/162 162/162 162/216 216/216 216/216 216/216
(mm) 4115 5486 5486 5486 6858 6858
4115/
4115
4115/
4115
4115/
5486
5486/
5486
5486/
5486
5486/
5486
Coil Width (in) 85 85 85 85 85 85 85/85 85/85 85/85 85/85 85/85 85/85
(mm) 2159 2159 2159 2159 2159 2159
2159/
2159
2159/
2159
2159/
2159
2159/
2159
2159/
2159
2159/
2159
Number of Rows 3 3 4 4 4 4 3/3 3/3 3/3 3/3 3/4 4/4
Condenser Fans
Fan Quantity 6 8 8 8 10 10 6/6 6/6 6/8 8/8 8/8 8/8
Diameter (in) 30 30 30 30 30 30 30 30 30 30 30 30
(mm) 762 762 762 762 762 762 762 762 762 762 762 762
Nominal RPM (rpm) 850 850 850 850 850 850 850 850 850 850 850 850
Air Flow (cfm) 56,646 78,280 72,248 69,280 94,490 90,310
60,954/
56,646
56,646/
56,646
56,646/
81,272
81,272/
81,272
81,272/
72,248
72,248/
72,248
Tip Speed (fpm) 6676 6676 6676 6676 6676 6676 6676 6676 6676 6676 6676 6676
Motor HP (hp) 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5 1.5
General
Recommended
Refrigerant
Charge¹
(lbs) 55/55 92/92 97/97 97/97 98/98 122/122 109/109 109/109 109/146 146/146 146/195 195/195
(kg)
24.9/
24.9
41.7/
41.7
44.0/
44.0
44.0/
44.0
44.5/
44.5
55.3/
55.3
49.4/
49.4
49.4/
49.4
49.4/
66.2
66.2/
66.2
66.2/
88.5
88.5/
88.5
Discharge/Liquid
Connection
Diameters
(in) 2.1 2.1 2.1 2.1 2.1 2.1 2.125 2.125 2.125 2.125 2.125 2.125
(mm) 54 54 54 54 54 54 54 54 54 54 54 54
Notes:
1. Data containing information on two condensers is shown as cond 1/cond 2.
2. Data containing information on two circuits is shown as circuit 1/circuit 2.
3. Condenser is not factory charged, the refrigerant must be purchased and charged in
the field.
