Installation and Maintenance Manual

Installation - Electrical
124 RLC-SVX09H-EN
BCI-C Alarming
The BCI-C unit has three binary input points used to
communicate alarms and one binary output point used to
reset alarms remotely.Those inputs and output points are:
BI 23; Alarm Present. •This object indicates if any
alarms are active regardless of severity. A notification
will be sent to any recipients of the Information
Notification Class object when the point transitions
from No Alarm to Alarm.
BI 24; Shutdown Alarm Present. •This object
indicates if any alarms that result in the shutdown of
the chiller are active. A notification will be sent to any
recipients of the Critical Notification Class object when
the point transitions from No Alarm to Alarm.
BI 25; Last Diagnostic. •The active text of this object
will reflect the description of the last diagnostic to
occur on the chiller.
BO 2; Remote Diagnostic Reset Command. •This
object is used to remotely reset diagnostics on the
chiller. Immediately after commanding this point value
to 1, the BCI-C will send the reset command to the
chiller and set this point value back to 0 and clear the
priority array.
Note: Not all diagnostics are able to be reset remotely.
Some will require local reset at the chiller front
panel.
Binary
Input, 3
Capacity Limited
Indicates if conditions may exist
that prevent the chiller from
reaching setpoint.
Binary
Input, 4
Chiller Running
State
Indicates if the chiller is running or
stopped.
Binary
Input, 5
Condenser Water
Flow Status
Condenser water flow status.
Binary
Input, 6
Maximum Capacity
Indicates if all available chiller
capacity is being used.
Binary
Input, 7
Head Relief
Request
Indicates if the chiller is asking an
outside system to provide more
heat
Binary
Input, 9
Compressor 1A
Running
Indicates if compressor 1A is
running.
Binary
Input, 10
Compressor 1B
Running
Indicates if compressor 1B is
running.
Binary
Input, 11
Compressor 2A
Running
Indicates if compressor 2A is
running.
Binary
Input, 12
Compressor 2B
Running
Indicates if compressor 2B is
running.
Binary
Input, 17
Evaporator Water
Pump Request
Indicates a request from the chiller
to turn on the evaporator water
pump.
Binary
Input, 19
Condenser Water
Pump Request
Indicates a request from the chiller
to turn on the condenser water
pump.
Binary
Input, 20
Noise Reduction
Active
Indicates if the chiller is in a state
where noise is being reduced.
Binary
Input, 22
Evaporator Water
Flow Status
Indicates if water is flowing through
the evaporator.
Binary
Input, 23
Alarm Present Indicates if an alarm is active.
Binary
Input, 24
Shutdown Alarm
Present
Indicates if a shutdown alarm is
present.
Binary
Input, 25
Last Diagnostic
Indicates the last diagnostic for the
chiller.
(a) AI=Analog Input, AO=Analog Output, AV=Analog Value, BI=Binary In-
put, BO=Binary Output, MI=Multistate Input, MO=Multistate Output
Table 105. All ObjectTypes Sorted by Object Name (Refer to
previous tables for detailed descriptions of objects
)
Object
Identifie
r
(a)
Object Name Description
