Installation and Maintenance Manual

Installation - Electrical
RLC-SVX09H-EN 123
Analog
Input, 68
Phase AB Voltage-
Compressor 2B
Phase AB voltage, compressor 2B.
Analog
Input, 69
Phase BC Voltage-
Compressor 2B
Phase BC voltage, compressor 2B.
Analog
Input, 70
Phase CA Voltage-
Compressor 2B
Phase CA voltage, compressor 2B
Analog
Input, 71
Line 1 Current (in
Amps)-
Compressor 1A
Line 1 Current (in Amps)-
Compressor 1A
Analog
Input, 72
Line 2 Current (in
Amps)-
Compressor 1A
Line 2 Current (in Amps)-
Compressor 1A
Analog
Input, 73
Line 3 Current (in
Amps)-
Compressor 1A
Line 3 Current (in Amps)-
Compressor 1A
Analog
Input, 74
Line 1 Current (in
Amps)-
Compressor 1B
Line 1 Current (in Amps)-
Compressor 1B
Analog
Input, 75
Line 2 Current (in
Amps)-
Compressor 1B
Line 2 Current (in Amps)-
Compressor 1B
Analog
Input, 76
Line 3 Current (in
Amps)-
Compressor 1B
Line 3 Current (in Amps)-
Compressor 1B
Analog
Input, 77
Line 1 Current (in
Amps)-
Compressor 2A
Line 1 Current (in Amps)-
Compressor 2A
Analog
Input, 78
Line 2 Current (in
Amps)-
Compressor 2A
Line 2 Current (in Amps)-
Compressor 2A
Analog
Input, 79
Line 3 Current (in
Amps)-
Compressor 2A
Line 3 Current (in Amps)-
Compressor 2A
Analog
Input, 80
Line 1 Current (in
Amps)-
Compressor 2B
Line 1 Current (in Amps)-
Compressor 2B
Analog
Input, 81
Line 2 Current (in
Amps)-
Compressor 2B
Line 2 Current (in Amps)-
Compressor 2B
Analog
Input, 82
Line 3 Current (in
Amps)-
Compressor 2B
Line 3 Current (in Amps)-
Compressor 2B
Analog
Input, 83
Line 1 Current
(%RLA)-
Compressor 1A
Line 1 Current (%RLA)- Compressor
1A
Analog
Input, 84
Line 2 Current
(%RLA)-
Compressor 1A
Line 2 Current (%RLA)- Compressor
1A
Analog
Input, 85
Line 3 Current
(%RLA)-
Compressor 1A
Line 3 Current (%RLA)- Compressor
1A
Analog
Input, 86
Line 1 Current
(%RLA)-
Compressor 1B
Line 1 Current (%RLA)- Compressor
1B
Analog
Input, 87
Line 2 Current
(%RLA)-
Compressor 1B
Line 2 Current (%RLA)- Compressor
1B
Analog
Input, 88
Line 3 Current
(%RLA)-
Compressor 1B
Line 3 Current (%RLA)- Compressor
1B
Table 105. All ObjectTypes Sorted by Object Name (Refer to
previous tables for detailed descriptions of objects
)
Object
Identifie
r
(a)
Object Name Description
Analog
Input, 89
Line 1 Current
(%RLA)-
Compressor 2A
Line 1 Current (%RLA)- Compressor
2A
Analog
Input, 90
Line 2 Current
(%RLA)-
Compressor 2A
Line 2 Current (%RLA)- Compressor
2A
Analog
Input, 91
Line 3 Current
(%RLA)-
Compressor 2A
Line 3 Current (%RLA)- Compressor
2A
Analog
Input, 92
Line 1 Current
(%RLA)-
Compressor 2B
Line 1 Current (%RLA)- Compressor
2B
Analog
Input, 93
Line 2 Current
(%RLA)-
Compressor 2B
Line 2 Current (%RLA)- Compressor
2B
Analog
Input, 94
Line 3 Current
(%RLA)-
Compressor 2B
Line 3 Current (%RLA)- Compressor
2B
Analog
Input, 95
Number of Circuits Number of Circuits
Analog
Input, 96
Number of
Compressors, Ckt 1
Number of Compressors, Ckt 1
Analog
Input, 97
Number of
Compressors, Ckt 2
Number of Compressors, Ckt 2
Multi-
State
Input, 1
Running Mode
Indicates the primary running mode
of the chiller.
Multi-
State
Input, 2
Operating Mode
Indicates the primary operating
mode of the chiller.
Multi-
State
Input, 3
MP Communication
Status
Communication status.
Multi-
State
Input, 4
Refrigerant Type Refrigerant type.
Multi-
State
Input, 5
Model Information
Indicates the model type of the
chiller.
Multi-
State
Input, 6
Cooling Type Cooling type of the condenser.
Multi-
State
Input, 7
Manufacturing
Location
Location where chiller was
manufactured.
Binary
Output, 1
Chiller Auto Stop
Command
Allows the chiller to run if conditions
for running are met.
Binary
Output, 2
Remote Diagnostic
Reset Command
Resets remotely diagnostics that
can be reset.
Binary
Output, 4
Noise Reduction
Request
Requests chiller to enter mode to
reduce noise.
Binary
Output, 1
Chiller Auto Stop
Command
Allows the chiller to run if conditions
for running are met.
Binary
Input, 1
Run Enabled
Indicates if the chiller is available to
run or is currently running.
Binary
Input, 2
Local Setpoint
Control
Indicates if the chiller is being
controlled by local setpoints instead
of BAS setpoints.
Table 105. All ObjectTypes Sorted by Object Name (Refer to
previous tables for detailed descriptions of objects
)
Object
Identifie
r
(a)
Object Name Description
