Table 105. All ObjectTypes Sorted by Object Name (Refer to
previous tables for detailed descriptions of objects
)
Object
Identifie
r
(a)
Object Name Description
Analog
Output 1
Chilled Water
Setpoint
Desired leaving water temperature
if chiller is in cooling mode.
Analog
Output 2
Current Limit
Setpoint
Sets the maximum capacity that the
chiller can use.
Analog
Output 4
Hot Water Setpoint
Desired leaving water temperature
if chiller is in heating mode.
Analog
Input, 1
Active Cool/Heat
Setpoint
Temperature
Active chiller water or hot water
setpoint.
Analog
Input, 2
Active Current
Limit Setpoint
Active capacity current limit
setpoint.
Analog
Input, 5
Actual Running
Capacity
Level of capacity that the chiller is
currently running at.
Analog
Input, 7
Suction Pressure-
Ckt 1
Circuit 1 suction pressure.
Analog
Input, 10
Suction Pressure-
Ckt 2
Circuit 2 suction pressure.
Analog
Input, 12
Evaporator
Saturated
Refrigerant
Temperature- Ckt
1
Circuit 2 evaporator refrigerant
temperature.
Analog
Input, 14
Evaporator
Saturated
Refrigerant
Temperature- Ckt
2
Circuit 2 evaporator refrigerant
temperature.
Analog
Input, 16
Condenser
Refrigerant
Pressure- Ckt 1
Circuit 1 condenser refrigerant
pressure.
Analog
Input, 18
Condenser
Refrigerant
Pressure- Ckt 2
Circuit 2 condenser refrigerant
pressure.
Analog
Input, 20
Condenser
Saturated
Refrigerant
Temperature- Ckt
1
Circuit 1 condenser refrigerant
temperature.
Analog
Input, 22
Condenser
Saturated
Refrigerant
Temperature- Ckt
2
Circuit 2 condenser refrigerant
temperature.
Analog
Input, 24
Unit Power
Consumption
The power being consumed by the
chiller.
Analog
Input, 25
Local Atmospheric
Pressure
Local atmospheric pressure.
Analog
Input, 26
Starts-
Compressor 1A
Number of starts for compressor 1A.
Analog
Input, 27
Starts-
Compressor 1B
Number of starts for compressor 1B.
Analog
Input, 28
Starts-
Compressor 2A
Number of starts for compressor 2A.
Analog
Input, 29
Starts-
Compressor 2B
Number of starts for compressor 2B.
Analog
Input, 34
Run Time-
Compressor 1A
Total run time of compressor 1A.
Analog
Input, 35
Run Time-
Compressor 1B
Total run time of compressor 1B.
Analog
Input, 36
Run Time-
Compressor 2A
Total run time of compressor 2A.
Analog
Input, 37
Run Time-
Compressor 2B
Total run time of compressor 2B.
Analog
Input, 42
Airflow
Percentage- Circuit
1
Approximate airflow percentage of
circuit 1.
Analog
Input, 43
Airflow
Percentage- Circuit
2
Approximate airflow percentage of
circuit 2.
Analog
Input, 44
Evaporator
Entering Water
Temp
Temperature of the water entering
the evaporator.
Analog
Input, 45
Evaporator Leaving
Water Temp
Temperature of the water leaving
the evaporator.
Analog
Input, 46
Condenser
Entering Water
Temp
Temperature of the water entering
the condenser.
Analog
Input, 47
Condenser Leaving
Water Temp
Temperature of the water leaving
the condenser.
Analog
Input, 48
High Side Oil
Pressure-
Compressor 1A
Pressure of the oil at the high side of
compressor 1A.
Analog
Input, 49
High Side Oil
Pressure-
Compressor 1B
Pressure of the oil at the high side of
compressor 1B.
Analog
Input, 50
High Side Oil
Pressure-
Compressor 2A
Pressure of the oil at the high side of
compressor 2A.
Analog
Input, 51
High Side Oil
Pressure-
Compressor 2B
Pressure of the oil at the high side of
compressor 2B.
Analog
Input, 56
Refrigerant Disch
Temp- Ckt 1
Temperature of the refrigerant
being discharged from Ckt 1.
Analog
Input, 57
Outdoor Air
Temperature
Outdoor air temperature.
Analog
Input, 58
Condenser Control
Output
Percentage of condenser water flow
being requested by the chiller.
Analog
Input, 59
Phase AB Voltage-
Compressor 1A
Phase AB voltage, compressor 1A.
Analog
Input, 60
Phase BC Voltage-
Compressor 1A
Phase BC voltage, compressor 1A.
Analog
Input, 61
Phase CA Voltage-
Compressor 1A
Phase CA voltage, compressor 1A.
Analo5
Input, 62
Phase AB Voltage-
Compressor 1B
Phase AB voltage, compressor 1B.
Analog
Input, 63
Phase BC Voltage-
Compressor 1B
Phase BC voltage, compressor 1B.
Analog
Input, 64
Phase CA Voltage-
Compressor 1B
Phase CA voltage, compressor 1B.
Analog
Input, 65
Phase AB Voltage-
Compressor 2A
Phase AB voltage, compressor 2A.
Analog
Input, 66
Phase BC Voltage-
Compressor 2A
Phase BC voltage, compressor 2A.
Analog
Input, 67
Phase CA Voltage-
Compressor 2A
Phase CA voltage, compressor 2A.
Table 105. All ObjectTypes Sorted by Object Name (Refer to
previous tables for detailed descriptions of objects
)
Object
Identifie
r
(a)
Object Name Description
