Installation and Maintenance Manual

Installation - Electrical
RLC-SVX09H-EN 121
Multi-State
Input, 6
Cooling
Type
Cooling type of
the condenser.
1 = Water Cooled
2 = Air Cooled
Multi-State
Input, 7
Manuf
Location
Location where
chiller was
manufactured.
1 = Field Applied
2 = La Crosse
3 = Pueblo
4 = Charmes
5 = Rushville
6 = Macon
7 = Waco
8 = Lexington
9 = Forsyth
10 = Clarksville
11 = Ft. Smith
12 = Penang
13 = Colchester
14 = Curitiba
15 = Taicang
16 = Taiwan
17 = Epinal
18 = Golbey
Table 103. Binary Output
Object
Identifier
Object
Name
Description
Relinq
Default
Object States
Binary
Output, 1
Chiller Auto
Stop
Command
Allows the
chiller to run if
conditions for
running are
met.
True
Inactive = Stop
Active = Auto
Binary
Output, 2
Remote
Diagnostic
Reset
Command
Resets
remotely
diagnostics
that can be
reset.
False
Inactive = No
Reset Request
Active = Reset
Request
Binary
Output, 4
Noise
Reduction
Request
Requests
chiller to enter
mode to
reduce noise.
False
Inactive =
Normal
Active = Reduced
Noise
Table 104. Binary Input
Object
Identifier
Object
Name
Description Object States
Binary
Input, 1
Run
Enabled
Indicates if the
chiller is available
to run or is
currently running.
Inactive = Stop
Active = Auto
Binary
Input, 2
Local
Setpoint
Control
Indicates if the
chiller is being
controlled by local
setpoints instead
of BAS setpoints.
Inactive =Remote Control
Active = Local Control
Binary
Input, 3
Capacity
Limited
Indicates if
conditions may
exist that prevent
the chiller from
reaching setpoint.
Inactive = Not Limited
Active = Limited
Table 102. Multistate Input (continued)
BCI-C
Object
Identifier
Object
Name
Description Object States
Binary
Input, 4
Chiller
Running
State
Indicates if the
chiller is running
or stopped.
Inactive = Off
Active = On
Binary
Input, 5
Condenser
Water Flow
Status
Condenser water
flow status.
Inactive = No Flow
Active = Flow
Binary
Input, 6
Maximum
Capacity
Indicates if all
available chiller
capacity is being
used.
Inactive = Off
Active = On
Binary
Input, 7
Head Relief
Request
Indicates if the
chiller is asking an
outside system to
provide more heat
rejection from the
condenser water
loop.
Inactive = Off
Active = On
Binary
Input, 9
Compr 1A
Running
Indicates if
compressor 1A is
running.
Inactive = Off
Active = Running
Binary
Input, 10
Compr 1B
Running
Indicates if
compressor 1B is
running.
Inactive = Off
Active = Running
Binary
Input, 11
Compr 2A
Running
Indicates if
compressor 2A is
running.
Inactive = Off
Active = Running
Binary
Input, 12
Compr 2B
Running
Indicates if
compressor 2B is
running.
Inactive = Off
Active = Running
Binary
Input, 17
Evaporator
Water Pump
Request
Indicates a
request from the
chiller to turn on
the evaporator
water pump.
Inactive = Off
Active = On
Binary
Input, 19
Condenser
Water Pump
Request
Indicates a
request from the
chiller to turn on
the condenser
water pump.
Inactive = Off
Active = On
Binary
Input, 20
Noise
Reduction
Active
Indicates if the
chiller is in a state
where noise is
being reduced.
Inactive = Off
Active = On
Binary
Input, 22
Evaporator
Water Flow
Status
Indicates if water
is flowing through
the evaporator.
Inactive = No Flow
Active = Flow
Binary
Input, 23
Alarm
Present
Indicates if an
alarm is active.
Inactive = No Alarm
Active = Alarm
Binary
Input, 24
Shutdown
Alarm
Present
Indicates if a
shutdown alarm is
active.
Inactive = No Alarm
Active = None
Binary
Input, 25
Last
Diagnostic
Indicates last
diagnostic for the
chiller.
Inactive = Off
Active = On
Table 104. Binary Input (continued)
Object
Identifier
Object
Name
Description Object States
