Installation - Electrical
11 8 RLC-SVX09H-EN
Device Address Binding
Networking Options
Character Sets
Indicates support for multiple characters sets, but does not
imply that all character sets are supported simultaneously.
Maximum supported string length is 64 bytes (any
character set).
Object Data Points and Diagnostic Data Points
with Corresponding Chiller Models
For quick reference, the following tables are listed two
different ways. Table 99 through Table 104 are listed by
input/output type and sorted by object identifier.These
tables provide the user with the units type for each object
type. Table 105 is sorted by object name and provides a
complete list of object names, types, values/ranges, and
descriptions. Not all points are available to the user.The
available data points are defined during self-configuration
and are dependent on the type of equipment
Device Address Binding Supported?
Static Device Binding Supported ü
Networking Descriptions
Supported
Option
Annex H, BACnet Tunneling
BACnet/IP Broadcast Management Device (BBMD)
Does the BBMD Support Registrations by Foreign Devices?
Router
Character Set Descriptions Supported
ANSI X3.4
ü
IBM/Microsoft DBCS
ISO 10646 (UCS-4)
ISO 10646 (UCS2)
ü
ISO 8859-1
ü
JIS C 6226
Table 99. Analog output
Object
Identifier
Object
Name
Description Units
Valid
Range
Relinq
Default
Analog
Output 1
Chilled
Water
Setpoint
Desired
leaving water
temperature if
chiller is in
cooling mode.
Degrees-
Fahrenheit
(64)
0°F to
75°F
44°F
Analog
Output 2
Current
Limit
Setpoint
Sets the
maximum
capacity that
the chiller can
use.
Percent
(98)
0% to
120%
100%
Analog
Output 4
Hot
Water
Setpoint
Desired
leaving water
temperature if
chiller is in
heating mode.
Degrees-
Fahrenheit
(64)
80°F to
140°F
120°F
Table 100. Analog Input
Object
Identifier
Object Name Description Units
Analog
Input, 1
Active Cool
(Heat Setpoint
Temperature
Active chiller water
or hot water
setpoint.
Degrees-
Fahrenheit
(64)
Analog
Input, 2
Active Current
Limit Setpoint
Active capacity
current limit
setpoint.
Percent (98)
Analog
Input, 5
Actual Running
Capacity
Level of capacity
that the chiller is
currently running at.
Percent (98)
Analog
Input, 7
Suction
Pressure- Ckt 1
Circuit 1 suction
pressure.
PSI
Analog
Input, 10
Suction
Pressure- Ckt 2
Circuit 2 suction
pressure.
PSI
Analog
Input, 12
Evaporator
Saturated
Refrigerant
Temperature-
Ckt 1
Circuit 2 evaporator
refrigerant
temperature.
Degrees-
Fahrenheit
(64)
Analog
Input, 14
Evaporator
Saturated
Refrigerant
Temperature-
Ckt 2
Circuit 2 evaporator
refrigerant
temperature.
Degrees-
Fahrenheit
(64)
Analog
Input, 16
Condenser
Refrigerant
Pressure- Ckt 1
Circuit 1 condenser
refrigerant pressure.
PSI
Analog
Input, 18
Condenser
Refrigerant
Pressure- Ckt 2
Circuit 2 condenser
refrigerant pressure.
PSI
Analog
Input, 20
Condenser
Saturated
Refrigerant
Temperature-
Ckt 1
Circuit 1 condenser
refrigerant
temperature.
Degrees-
Fahrenheit
(64)
Analog
Input, 22
Condenser
Saturated
Refrigerant
Temperature-
Ckt 2
Circuit 2 condenser
refrigerant
temperature.
Degrees-
Fahrenheit
(64)
