Installation - Electrical
RLC-SVX09H-EN 11 5
Object Types
Table 98. Descriptions and configurations
Object Type Required Properties Read Properties Written
(a)
Optional Properties Read
Ability to
Create
Ability to
Delete
Analog Input • Object_Identifier
• Object_Name
• Object_Type
• Present_Value
• Status_Flags
• Event_State
• Out_Of_Service
• Units
• Object_Name
• Description
• Out_Of_Service
• Present_Value
• Reliability
• Min_Pres_Value
• Max_Pres_Value
• COV_Increment
• Time_Delay
• Notification_Class
• High_Limit
• Low_Limit
• Deadband
• Limit_Enable
• Event_Enable
• Notify_Type
• Description
• Reliability
• Min_Pres_Value
• Max_Pres_Value
• COV_Increment
• Time_Delay
• Notification _Class
• High_Limit
• Low_Limit
• Deadband
• Limit_Enable
• Event_Enable
• Acked_Transitions
• Notify_Type
• Event_Time_Stamps
Yes Yes, only user
created objects
Analog Output • Object_Identifier
• Object_Name
• Object_Type
• Present_Value
• Status_Flags
• Event_State
• Out_Of_Service
• Units
• Priority_Array
• Relinquish_Default
• Object_Name
• Description
• Out_Of_Service
• Present_Value
• Reliability
• Min_Pres_Value
• Max_Pres_Value
• Relinquish_Default
• COV_Increment
• Time_Delay
• Notification_Class
• High_Limit
• Low_Limit
• Deadband
• Limit_Enable
• Event_Enable
• Notify_Type
• Description
• Reliability
• Min_Pres-Value
• Max_Pres_Value
• COV_Increment
• Time_Delay
• Notification _Class
• High_Limit
• Low_Limit
• Deadband
• Limit_Enable
• Event_Enable
• Acked_Transitions
• Notify_Type
• Event_Time_Stamps
Yes Yes, only user
created objects
Analog Value • Object_Identifier
• Object_Name
• Object_Type
• Present_Value
• Status_Flags
• Event_State
• Out_Of_Service
• Units
• Object_Name
• Description
• Out_Of_Service
• Present_Value
• Reliability
• Relinquish_Default
• COV_Increment
• Time_Delay
• Notification_Class
• High_Limit
• Low_Limit
• Deadband
• Limit_Enable
• Event_Enable
• Notify_Type
• Description
• Reliability
• Priority_Array
• Relinquish_Default
• COV_Increment
• Time_Delay
• Notification_Class
• High_Limit
• Low_Limit
• Deadband
• Limit_Enable
• Event_Enable
• Acked_Transitions
• Notify_Type
• Event_Time_Stamps
Yes Yes, only user
created objects
Binary Input • Object_Identifier
• Object_Name
• Object_Type
• Present_Value
• Status_Flags
• Event_State
• Out_Of_Service
• Polarity
• Object_Name
• Description
• Out_Of_Service
• Inactive_Text
• Active_Text
• Present_Value
• Reliability
• Change_Of_State_Count
• Elapsed_Active_Time
• Time_Delay
• Notification_Class
• Alarm_Value
• Event_Enable
• Acked_Transitions
• Notify_Type
• Description
• Inactive_Text
• Active_Text
• Change_Of_State_Time
• Change_Of_State_Count
• Time_Of_State_Count_Reset
• Elapsed_Active_Time
• Time_Of_Active_Time_Reset
• Time_Delay
• Notification_Class
• Alarm_Value
• Event_Enable
• Acked_Transitions
• Notify_Type
• Event_Time_Stamps
• Reliability
Yes Yes, only user
created objects
