Installation - Electrical
102 RLC-SVX09H-EN
Table 85. Customer Wire Selection - RTWD - 50 Hz - standard efficiency - standard condensing temperature
Size
Rated
Voltage
#
Conn
Wire Selection
Main Terminal Block Disconnect Circuit Breaker Hi-Fault Panel Ckt Brkr
Size Wire Range Size Wire Range Size Wire Range Size Wire Range
Amp XL YD Amp XL YD Amp XL YD Amp XL YD
70 400
1 380 #4–500 #4–500 250 #6–#350 #6–#350 150 #6–#350 #6–#350 150 #6–#350 #6–#350
2 175 #14–2/0 #14–2/0 100 #10–1/0 #10–1/0 100 #6–#350 #6–#350 100 #6–#350 #6–#350
80 400
1 380 #4–500 #4–500 250 #6–#350 #6–#350 175 #6–#350 #6–#350 175 #6–#350 #6–#350
2 175 #14–2/0 #14–2/0 100 #10–1/0 #10–1/0
100
125
#6–#350 #6–#350
100
125
#6–#350 #6–#350
90 400
1 380 #4–500 #4–500 250 #6–#350 #6–#350 175 #6–#350 #6–#350 175 #6–#350 #6–#350
2 175 #14–2/0 #14–2/0 100 #10–1/0 #10–1/0 125 #6–#350 #6–#350 125 #6–#350 #6–#350
100 400
1 380 #4–500 #4–500 250 #6–#350 #6–#350 200 #6–#350 #6–#350 200 #6–#350 #6–#350
2 175 #14–2/0 #14–2/0 100 #10–1/0 #10–1/0
125
150
#6–#350 #6–#350
125
150
#6–#350 #6–#350
110 400
1 380 #4–500 #4–500 250 #6–#350 #6–#350 225 #6–#350 #6–#350 225 #6–#350 #6–#350
2 175 #14–2/0 #14–2/0 100 #10–1/0 #10–1/0 150 #6–#350 #6–#350 150 #6–#350 #6–#350
120 400
1 380 #4–500 #4–500 250 #6–#350 #6–#350 250 #6–#350 #6–#350 250 #6–#350 #6–#350
2 175 #14–2/0 #14–2/0 100 #10–1/0 #10–1/0
150
175
#6–#350 #6–#350
150
175
#6–#350 #6–#350
130 400
1 380 #4–500 #4–500 250 #6–#350 #6–#350 250 #6–#350 #6–#350 250 #6–#350 #6–#350
2 175 #14–2/0 #14–2/0 100 #10–1/0 #10–1/0 175 #6–#350 #6–#350 175 #6–#350 #6–#350
140 400
1 380 #4–500 #4–500 250 #6–#350 #6–#350 300 3/0-500
(a)
3/0-500
(a)
300 3/0-500
(a)
3/0-500
(a)
2 175 #14–2/0 #14–2/0
100
250
#10–1/0
#6–#350
#10–1/0
#6–#350
175
200
#6–#350 #6–#350
175
200
#6–#350 #6–#350
150 400
1 380 #4–500 #4–500 250 #6–#350 #6–#350 300 3/0-500
(a)
3/0-500
(a)
300 3/0-500
(a)
3/0-500
(a)
2 175 #14–2/0 #14–2/0 250 #6–#350 #6–#350 200 #6–#350 #6–#350 200 #6–#350 #6–#350
Notes:
1. Optional non-fused disconnect and circuit breaker.
2. Copper wire only, based on nameplate minimum circuit ampacity (MCA).
3. Standard condensing temperature option refers to entering condenser water temperatures 95°F (35°C) and below.
4. Circuit two information is the same as circuit one unless listed on a separate line below circuit one values.
5. XL - across-the-line starter and YD - wye-delta starter.
(a) Will accept 2conduits per phase in this size.
