Installation and Maintenance Manual

ManualsBrandsTrane ManualschillerTrane Series R Model RTUD

Table Of Contents

SAFETY WARNING

Only qualified personnel should install and service the equipment. The installation, starting up, and

servicing of heating, ventilating, and air-conditioning equipment can be hazardous and requires specific

knowledge and training. Improperly installed, adjusted or altered equipment by an unqualified person could

result in death or serious injury. When working on the equipment, observe all precautions in the literature

and on the tags, stickers, and labels that are attached to the equipment.

Series R

Rotary Liquid Chillers

Water-Cooled and Compressor-Chillers

October 2012 RLC-SVX09H-EN

Installation, Operation,

and Maintenance

RTWD 60 RTWD 90 RTWD 120 RTWD 150 RTWD 200

RTWD 70 RTWD 1 00 RTWD 130 RTWD 160 RTWD 220

RTWD 80 RTWD 110 RTWD 140 RTWD 180 RTWD 250

RTUD 80 RTUD 110 RTUD 150 RTUD 200

RTUD 90 RTUD 120 RTUD 160 RTUD 220

RTUD 100 RTUD 130 RTUD 180 RTUD 250

Summary of content (216 pages)

PAGE 1
Installation, Operation, and Maintenance Series R® Rotary Liquid Chillers Water-Cooled and Compressor-Chillers RTWD 60 RTWD 70 RTWD 80 RTWD 90 RTWD 100 RTWD 110 RTWD 120 RTWD 130 RTWD 140 RTWD 150 RTWD 160 RTWD 180 RTUD 80 RTUD 90 RTUD 100 RTUD 110 RTUD 120 RTUD 130 RTUD 150 RTUD 160 RTUD 180 RTUD 200 RTUD 220 RTUD 250 RTWD 200 RTWD 220 RTWD 250 SAFETY WARNING Only qualified personnel should install and service the equipment.
PAGE 2
Warnings, Cautions and Notices Warnings, Cautions and Notices. Note that warnings, cautions and notices appear at appropriate intervals throughout this manual. Warnings are provide to alert installing contractors to potential hazards that could result in death or personal injury. Cautions are designed to alert personnel to hazardous situations that could result in personal injury, while notices indicate a situation that could result in equipment or property-damage-only accidents.
PAGE 3
Warnings, Cautions and Notices Factory Warranty Information • Added Recommended Glycol information. Compliance with the following is required to preserve the factory warranty: • Clarified requirements for liquid line service valves on RTUD units. • Corrections to electrical data. • Updated Customer Wire Selection tables. • Corrected refrigeration circuit graphic in Operating Principals chapter. • Updated Compressor Loading Sequence information.
PAGE 4
Table of Contents Model Number Description . . . . . . . . . . . . . . . 6 Nameplates . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Unit Nameplate . . . . . . . . . . . . . . . . . . . . . 6 Compressor Nameplate . . . . . . . . . . . . . . . 6 Model Number Coding System . . . . . . . . . 6 ASME Nameplate . . . . . . . . . . . . . . . . . . . . 6 Model Number Descriptions . . . . . . . . . . . . 7 RTWD Model Number . . . . . . . . . . . . . . . . 7 Compressor Model Number . . . . . . . . . . .
PAGE 5
Compressor Rotor Oil Supply . . . . . . . . 130 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . .181 Compressor Bearing Oil Supply . . . . . . 130 Weekly Maintenance and Checks . . . . . .181 Oil Separator . . . . . . . . . . . . . . . . . . . . . . 130 Monthly Maintenance and Checks . . . . .181 Compressor Loading Sequence . . . . . . 130 Annual Maintenance . . . . . . . . . . . . . . . .181 Controls Interface . . . . . . . . . . . . . . . . . . . . . .
PAGE 6
Model Number Description Nameplates Model Number Coding System The RTWD/RTUD unit nameplates are applied to the exterior surface of the control panel door. Model numbers for unit and compressors are comprised of numbers and letter which represent equipment features. A compressor nameplate is located on each compressor. Unit Nameplate See “RTWD Model Number,” p. 7 and “Compressor Model Number,” p. 8 for details. • Unit model and size descriptor. • Unit serial number.
PAGE 7
Model Number Descriptions RTWD Model Number Digits 1-4— Chiller Model RTWD= Water Cooled Chiller - Series R® RTUD= Compressor Series R® Chiller Digits 5-7— Unit Nominal Tonnage 060 = 070 = 080 = 090 = 100 = 110 = 120 = 130 = 140 = 150 = 160 = 180 = 200 = 220 = 250 = 60 NominalTons 70 NominalTons 80 NominalTons 90 NominalTons 100 NominalTons 110 NominalTons 120 NominalTons 130 NominalTons 140 NominalTons 150 NominalTons 160 NominalTons 180 NominalTons 200 NominalTons 220 NominalTons 250 NominalTons Digit
PAGE 8
Digit 35— Condenser Leaving Hot WaterTemp Control 0 = 1 = No condenser leaving hot water temperature control Condenser leaving hot water temperature control Digit 45— Factory Charge 0 = 1 = Full factory refrigerant charge (R-134a) Nitrogen charge Digit 46— Base Rail Forklifting Digit 36— Power Meter 0 B 0 P Digit 47— Label and Literature Language = = No power meter Power meter Digit 37— Motor Current Analog Output (%RLA) 0 1 = = No motor current analog output Motor current analog output
PAGE 9
General Information Unit Description The RTWD units are helical-rotary type, water-cooled, liquid chillers, designed for installation indoors.The units have 2 independent refrigerant circuits, with one compressor per circuit.The RTWD units are packaged with an evaporator and condenser. Note: Each RTWD unit is a completely assembled, hermetic package that is factory-piped, wired, leaktested, dehydrated, charged and tested for proper control operations prior to shipment.
PAGE 10
General Information Table 2. General Data - RTWD - 60 Hz - standard efficiency Size Compressor Quantity 80 90 100 110 120 130 140 K1/K1 K2/K2 K2/L1 L1/L1 L1/L2 L2/L2 L2/M1 2 2 2 2 2 2 2 40/40 45/45 45/55 55/55 55/65 65/65 65/70 NPS 4 4 4 4 5 5 5 mm 100 100 100 100 125 125 125 Nominal Size Evaporator 2 Pass Arrangement Water Conn. Size Water Storage Minimum Flow Maximum Flow (gal) 11.2 11.2 12.6 14 15.2 16.2 17.7 (L) 42.2 42.2 47.6 53.0 57.
PAGE 11
General Information Table 3. General Data - RTWD - 60 Hz - high efficiency Size Compressor Quantity Nominal Size 80 90 100 110 120 130 150 160 180 200 220 250 K1/K1 K2/K2 K2/L1 L1/L1 L1/L2 L2/L2 L2/M1 M1/M1 M1/M2 M2/M2 M2/N1 N1/N1 2 2 2 2 2 2 2 2 2 2 2 2 40/40 45/45 45/55 55/55 55/65 65/65 65/70 70/70 70/85 85/85 85/100 100/100 Evaporator 2 Pass Arrangement Water Conn.
PAGE 12
General Information Table 4. General Data – RTUD – 60 Hz Size Compressor Quantity Nominal Size 80 90 100 110 120 130 150 160 180 200 220 250 K1/K1 K2/K2 K2/L1 L1/L1 L1/L2 L2/L2 L2/M1 M1/M1 M1/M2 M2/M2 M2/N1 N1/N1 2 2 2 2 2 2 2 2 2 2 2 2 40/40 45/45 45/55 55/55 55/65 65/65 65/70 70/70 70/85 85/85 85/100 100/100 5 5 5 5 5 5 Evaporator 2 Pass Arrangement Water Conn.
PAGE 13
General Information Table 5.
PAGE 14
General Information Table 6. General Data - RTWD 50 Hz - standard efficiency Size Compressor Quantity Nominal Size 70 80 90 100 110 120 130 140 150 K2/K2 K2/L1 L1/L1 L1/L2 L2/L2 L2/M1 M1/M1 M1/M2 M2/M2 2 2 2 2 2 2 2 2 2 45/45 45/55 55/55 55/65 65/65 65/70 70/70 70/85 85/85 Evaporator 2 Pass Arrangement Water Conn. Size Water Storage Minimum Flow NPS 4 4 4 4 4 5 5 5 5 mm 100 100 100 100 100 125 125 125 125 (gal) 11.2 12.6 14.0 14.0 14.0 16.
PAGE 15
General Information Table 7. General Data - RTWD 50 Hz - high efficiency Size Compressor Quantity 60 70 80 90 100 110 120 130 140 160 180 200 220 250 K1/K1 K2/K2 K2/L1 L1/L1 L1/L2 L2/L2 L2/M1 M1/M1 M1/M2 M2/M2 M2/N1 N1/N1 N1/N2 N2/N2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 85/100 100/ 100 100/ 120 120/ 120 Nominal Size 40/40 45/45 45/55 55/55 55/65 65/65 65/70 70/70 70/85 85/85 Evaporator 2 Pass Arrangement Water NPS Conn.
PAGE 16
General Information Table 8. General Data - RTWD 50 Hz - premium efficiency Size Compressor Quantity Nominal Size 160 180 200 M2/M2 M2/N1 N1/N1 2 2 2 85/85 85/100 100/100 Evaporator 2 Pass Arrangement Water Conn. Size Water Storage Minimum Flow Maximum Flow NPS 6 6 6 mm 150 150 150 (gal) 29.3 31.3 31.8 (L) 110.9 118.3 120.3 (gpm) 186 202 240 (L/s) 11.8 12.7 15.1 (gpm) 683 739 879 (L/s) 43.1 46.7 55.5 4 4 3 Pass Arrangement Water Conn.
PAGE 17
Pre-Installation Inspection Checklist When the unit is delivered, verify that it is the correct unit and that it is properly equipped. Compare the information which appears on the unit nameplate with the ordering and submittal information. See “Model Number Descriptions,” p. 7. Inspect all exterior components for visible damage. Report any apparent damage or material shortage to the carrier and make a “unit damage” notation on the carrier's delivery receipt.
PAGE 18
Unit Dimensions/Weights Service Clearances and Dimension Figure 4.
PAGE 19
Unit Dimensions/Weights Table 10. RTWD/RTUD – 60 Hz dimensions – 80-140 ton Standard Efficiency RTWD/RTUD - High Efficiency 80,90 inch (mm) 100,110 inch (mm) 120,130,140 inch (mm) 80,90 inch (mm) 100,110,120,130 inch (mm) A (2 pass evap) 138.2 (3510) 138.2 (3510) 138.8 (3525) 126.4 (3210) 126.9 (3225) B (3 pass evap) 142.6 (3621) 142.6 (3621) 142.6 (3621) 130.8 (3321) 130.7 (3320) C 75.9 (1929) 76.9 (1955) 76.9 (1955) 76.1 (1933) 76.9 (1955) D 34.3 (871) 34.3 (871) 34.
PAGE 20
Unit Dimensions/Weights Figure 5.
PAGE 21
Unit Dimensions/Weights Table 11. RTWD/RTUD – 60 Hz dimensions – 150-250 tons RTWD High Efficiency RTUD Prem Efficiency 150-200 inch (mm) 220, 250 inch (mm) 150-200 inch (mm) 150 inch (mm) 160-200 inch (mm) 220,250 inch (mm) A (2 pass evap) 132.3 (3360) 136.1 (3456) 147.9 (3755) 126.9 (3225) 132.3 (3360) 132.3 (3360) B (3 pass evap) 132.8 (3371) 136.1 (3456) 150.9 (3831) 130.8 (3321) 132.8 (3371) 132.9 (3376) C 75.6 (1920) 76.9 (1955) 76.8 (1950) 76.9 (1955) 75.6 (1920) 76.
PAGE 22
Unit Dimensions/Weights RTWD - 50 Hz dimensions - 70-150 ton SE, 60-120 ton HE Figure 6.
PAGE 23
Unit Dimensions/Weights Table 12. RTWD – 50 Hz – 70-150 ton SE, 60-120 ton HE RTWD Standard Efficiency High Efficiency 70,80,90,100,110 inch (mm) 120,130,140,150 inch (mm) 60,70,80 inch (mm) 90 inch (mm) 100,110,120 inch (mm) A (2 pass evap) 138.2 (3510) 138.8 (3525) 126.4 (3210) 127.0 (3225) 127.0 (3225) B (3 pass evap) 142.6 (3621) 145.6 (3621) 130.8 (3321) 130.7 (3320) 130.7 (3320) C 75.9 (1929) 76.9 (1955) 76.1 (1933) 76.1 (1933) 76.9 (1955) D 34.3 (871) 34.8 (884) 35.
PAGE 24
Unit Dimensions/Weights Figure 7.
PAGE 25
Unit Dimensions/Weights Table 13. RTWD – 50 Hz dimensions – 130-250 ton HE, 160-200 ton PE RTWD High Efficiency Premium Efficiency 130, 140, 160, 180 inch (mm) 200, 220, 250 inch (mm) 160, 180 inch (mm) 200 inch (mm) A (2 pass evap) 132.3 (3360) 136.1 (3456) 147.9 (3755) 136.1 (3456) B (3 pass evap) 132.8 (3371) 136.1 (3456) 150.8 (3831) 136.1 (3456) C 75.6 (1920) 76.8 (1949) 76.8 (1950) 76.9 (1955) D 47.3 (1202) 47.8 (1213) 47.3 (1202) 47.8 (1213) E 24.6 (624) 24.8 (630) 24.
PAGE 26
Unit Dimensions/Weights Figure 8. RTWD/RTUD Unit footprint P5 Table 14. RTWD/RTUD – unit footprint – all sizes Standard Efficiency High Efficiency 200 PE (50 Hz) Premium Efficiency inch (mm) inch (mm) inch (mm) P1 3.68 (93.5) 3.68 (93.5) 3.68 (93.5) P2 123.78 (3144) 111.97 (2844) 131.65 (3344) P3 2.43 (61.8) 4.30 (109.3) 4.30 (109.3) P4 24.93 (633.2) 24.93 (633.2) 24.93 (633.2) P5 2.5 (64) 2.5 (64) 2.5 (64) Note: Base hole diameters all 0.63 inch (16 mm).
PAGE 27
Unit Dimensions/Weights Figure 9. Trane air-cooled condenser 80T, 150T (cond 1 & 2), 160T (cond 1 & 2), 180T (cond 1) 166.0‚ Disconnect switch 90.5‚ 45.25‚ 64.0‚ 58.5‚ 93.0‚ Approx. center of gravity Service panel 86.5‚ Inlet connection Electrical box split controls 90.5‚ Outlet connection Return bend cover 10.0‚ 22.0‚ 54.0‚ 54.0‚ 54.0‚ 166.0‚ 8.0‚ 0.75 inch anchor holes 184.0‚ Figure 10.
PAGE 28
Unit Dimensions/Weights Figure 11. Trane air-cooled condenser - 120T, 130T 274.0‚ Disconnect switch 90.5‚ 45.25‚ 64.0‚ 58.5‚ 145.0‚ Approx. center of gravity 86.5‚ Electrical box split controls Inlet connection 90.5‚ Outlet connection Return bend cover 22.0‚ 10.0‚ 108.0‚ 54.0‚ 108.0‚ 8.0‚ 274.0‚ 292.0‚ Weights Table 15.
PAGE 29
Unit Dimensions/Weights Table 16.
PAGE 30
Unit Dimensions/Weights Table 19.
PAGE 31
Installation - Mechanical Location Requirements center of gravity dimensions. Refer to the rigging label attached to the unit for further details.\ Noise Considerations • Refer toTrane Engineering Bulletin -Series RChiller Sound Ratings and Installation Guide for sound consideration applications. • Locate the unit away from sound-sensitive areas. • Install the isolation pads under the unit. Refer to “Unit Isolation.” • Install rubber vibration isolators in all water piping.
PAGE 32
Installation - Mechanical Figure 12. RTWD/RTUD rigging 60 D eg. M A X 40” MIN 48” MIN 110” MIN ANTI-ROLLING CABLE 48” MIN CG CG Y X Approximate location of center of gravity Z Unit Isolation and Leveling Neoprene Isolator Installation (optional) Mounting Install the optional neoprene isolators at each mounting location. Isolators are identified by part number and color. Refer to submittal drawing for correct isolators.
PAGE 33
Installation - Mechanical Figure 13. Isolator pad placement Note: Level unit 1/4” (6.35 mm) across Note: Level unit to to 1/4” (6.35 mm) across width and length width and length Figure 14. RTWD/RTUD neoprene isolator L C Mounting molded in Neoprene 1/2-13NC-2B A H (RD) W H (R) D E Table 21. Isolator part numbers and dimensions(a) Isolator Type Maximum Color [Ext](b) Max LoadHz Effic.
PAGE 34
Installation - Mechanical Figure 15. Mounting point locations and weights RTWD - Std efficiency (all) RTWD - High efficiency, 80-120T (60 Hz), 60-120T (50 Hz) RTUD - 80-130T Figure 16.
PAGE 35
Installation - Mechanical Important: Table 22. Isolators need to be placed under G1, G2, G3 and G4.
PAGE 36
Installation - Mechanical Table 24.
PAGE 37
Installation - Mechanical Table 27.
PAGE 38
Installation - Mechanical Center of Gravity Figure 17. Center of gravity RTWD - Std efficiency (all) RTWD - High efficiency, 80-120T (60 Hz), 60-120T (50 Hz) RTUD - 80-130T Figure 18.
PAGE 39
Installation - Mechanical Table 30.
PAGE 40
Installation - Mechanical Table 33.
PAGE 41
Installation - Mechanical NOTICE: Proper Water Treatment! The use of untreated or improperly treated water could result in scaling, erosion, corrosion, algae or slime. It is recommended that the services of a qualified water treatment specialist be engaged to determine what water treatment, if any, is required. Trane assumes no responsibility for equipment failures which result from untreated or improperly treated water, or saline or brackish water.
PAGE 42
Installation - Mechanical The sensor head includes 3 LEDs, two yellow and one green.Wait 15 seconds after power is applied to the sensor before evaluating LEDs for flow status. When wired correctly and flow is established, only the green LED should be lit.
PAGE 43
RLC-SVX09H-EN 0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 0.0 50.0 100.0 RTWD100 High & RTUD110 High RTWD110 High & RTUD120, 130 High RTWD120 High & RTUD150 High RTWD130 High RTWD90 High RTWD80 High RTWD140 Std RTWD130 Std RTWD120 Std RTWD110 Std RTWD100 Std RTWD090 Std RTWD080 Std 150.0 250.0 300.0 Water Flow (GPM) 200.0 350.0 Waterside Pressure Drop - 60 Hz Units - 2 Pass Evaporator 400.0 450.0 500.0 Figure 21. 40.0 45.
PAGE 44
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0 0.0 100.0 RTWD200 Prem RTWD180 Prem RTWD160 Prem RTWD150 Prem RTWD250 High RTWD220 High RTWD200 High RTWD180 High RTWD160 High RTWD150 High 200.0 300.0 500.0 Water Flow (GPM) 400.0 600.0 700.0 Waterside Pressure Drop - 60 Hz Units - 2 Pass Evaporator 800.0 900.0 Installation - Mechanical Figure 22. Evaporator pressure drop curves - 2 pass, 60 Hz - RTWD, RTUD RLC-SVX09H-EN Pressure Drop (ft.
PAGE 45
RLC-SVX09H-EN 0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 0.0 50.0 100.0 RTWD120 High 50Hz RTWD110 High 50Hz RTWD100 High 50Hz RTWD60 High 50Hz & RTUD80 High 60Hz RTWD70 High 50Hz & RTUD90 High 60Hz RTWD80 High 50Hz & RTUD100 High 60Hz RTWD90 High 50Hz RTWD150 Std 50Hz RTWD140 Std 50Hz RTWD130 Std 50Hz RTWD120 Std 50Hz RTWD110 Std 50Hz RTWD100 Std 50Hz RTWD90 Std 50Hz RTWD80 Std 50Hz RTWD70 Std 50Hz 150.0 250.0 300.0 Water Flow (GPM) 200.0 350.0 400.0 450.
PAGE 46
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 50.0 50.0 150.0 RTWD200 Prem RTWD180 Prem RTWD160 Prem RTWD250 High RTWD220 High RTWD200 High RTWD180 High RTWD160 High RTWD140 High RTWD130 High 250.0 350.0 550.0 Water Flow (GPM) 450.0 650.0 Waterside Pressure Drop - 50 Hz Units - 2 Pass Evaporator 750.0 850.0 Installation - Mechanical Figure 24. Evaporator pressure drop curves - 2 pass, 50 hz - RTWD RLC-SVX09H-EN Pressure Drop (ft.
PAGE 47
RLC-SVX09H-EN 0.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 0.0 50.0 RTWD100 High & RTUD110 High RTWD110 High & RTUD120, 130 High RTWD120 High & RTUD150 High RTWD130 High RTWD90 High RTWD80 High RTWD140 Std RTWD130 Std RTWD120 Std RTWD110 Std RTWD100 Std RTWD090 Std RTWD080 Std 100.0 150.0 Water Flow (GPM) 200.0 250.0 300.0 Waterside Pressure Drop - 60 Hz Units - 3 Pass Evaporator 350.0 400.0 Installation - Mechanical Figure 25.
PAGE 48
0.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 0.0 100.0 RTWD200 Prem RTWD180 Prem RTWD160 Prem RTWD150 Prem RTWD250 High RTWD150 High & RTUD160, 180 High RTWD160 High & RTUD200 High RTWD180 High & RTUD 220 High RTWD200 High & RTUD 250 High RTWD220 High 200.0 Water Flow (GPM) 300.0 400.0 Waterside Pressure Drop - 60 Hz Units - 3 Pass Evaporator 500.0 600.0 Installation - Mechanical Figure 26.
PAGE 49
RLC-SVX09H-EN 0.0 10.0 20.0 30.0 40.0 50.0 0.0 50.0 RTWD120 High 50Hz RTWD110 High 50Hz RTWD100 High 50Hz RTWD60 High 50Hz & RTUD80 High 60Hz RTWD70 High 50Hz & RTUD90 High 60Hz RTWD80 High 50Hz & RTUD100 High 60Hz RTWD90 High 50Hz RTWD150 Std 50Hz RTWD140 Std 50Hz RTWD130 Std 50Hz RTWD120 Std 50Hz RTWD110 Std 50Hz RTWD100 Std 50Hz RTWD90 Std 50Hz RTWD80 Std 50Hz RTWD70 Std 50Hz 100.0 150.0 Water Flow (GPM) 200.0 250.0 300.0 350.0 400.0 Figure 27. 60.0 70.
PAGE 50
0.0 10.0 20.0 30.0 40.0 50.0 60.0 70.0 80.0 50.0 150.0 RTWD200 Prem RTWD180 Prem RTWD160 Prem RTWD250 High RTWD220 High RTWD200 High RTWD180 High RTWD160 High RTWD140 High RTWD130 High 250.0 Water Flow (GPM) 350.0 450.0 Waterside Pressure Drop - 50 Hz Units - 3 Pass Evaporator 550.0 Installation - Mechanical Figure 28. Evaporator pressure drop curves - 3 pass, 50 Hz - RTWD RLC-SVX09H-EN Pressure Drop (ft.
PAGE 51
RLC-SVX09H-EN 0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 0.0 100.0 RTWD130 High RTWD120 High RTWD110 High RTWD100 High RTWD90 High RTWD80 High RTWD140 Std RTWD130 Std RTWD120 Std RTWD110 Std RTWD100 Std RTWD090 Std RTWD080 Std 200.0 400.0 Water Flow (GPM) 300.0 500.0 Waterside Pressure Drop - 60 Hz Units - Condenser 600.0 700.0 Installation - Mechanical Figure 29. Condenser pressure drop curves - RTWD 60 Hz 51 Pressure Drop (ft.
PAGE 52
0.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 0.0 200.0 RTWD200 Prem RTWD180 Prem RTWD160 Prem RTWD150 Prem RTWD250 High RTWD220 High RTWD200 High RTWD180 High RTWD160 High RTWD150 High 400.0 Water Flow (GPM) 600.0 800.0 Waterside Pressure Drop - 60 Hz Units - Condenser 1000.0 1200.0 Installation - Mechanical Figure 30. Condenser pressure drop curves - RTWD 60 Hz RLC-SVX09H-EN Pressure Drop (ft.
PAGE 53
RLC-SVX09H-EN 0.0 5.0 10.0 15.0 20.0 25.0 30.0 0.0 100.0 RTWD120 High 50Hz RTWD110 High 50Hz RTWD100 High 50Hz RTWD90 High 50Hz RTWD80 High 50Hz RTWD70 High 50Hz RTWD60 High 50Hz RTWD150 Std 50Hz RTWD140 Std 50Hz RTWD130 Std 50Hz RTWD120 Std 50Hz RTWD110 Std 50Hz RTWD100 Std 50Hz RTWD90 Std 50Hz RTWD80 Std 50Hz RTWD70 Std 50Hz 200.0 400.0 Water Flow (GPM) 300.0 500.0 Waterside Pressure Drop - 50 Hz Units - Condenser 600.0 700.0 Figure 31. 35.0 40.
PAGE 54
0.0 100.0 5.0 10.0 15.0 20.0 25.0 30.0 35.0 40.0 45.0 300.0 RTWD200 Prem RTWD180 Prem RTWD160 Prem RTWD250 High RTWD220 High RTWD200 High RTWD180 High RTWD160 High RTWD140 High RTWD130 High 500.0 Water Flow (GPM) 700.0 900.0 Waterside Pressure Drop - 50 Hz Units - Condenser 1100.0 Installation - Mechanical Figure 32. Condenser pressure drop curves - RTWD 50 Hz RLC-SVX09H-EN Pressure Drop (ft.
PAGE 55
Installation - Mechanical Low Evap Refrigerant Cutout/Percent Glycol Recommendations The table below shows the low evaporator temperature cutout for different glycol levels. be reduced. For some operating conditions this effect can be significant. Additional glycol beyond the recommendations will adversely effect unit performance.
PAGE 56
Installation - Mechanical Condenser Water Piping (RTWD Units Only) Condenser water inlet and outlet types, sizes and locations are given in the Unit Dimensions and Weights. Condenser pressure drops are shown inFigure 29, p. 51 thru Figure 32, p. 54. If the above guidelines cannot be met, then some form of condenser water temperature control must be used. Condenser Piping Components Condenser piping must be in accordance with all applicable local and national codes.
PAGE 57
Installation - Mechanical Refrigerant Relief Valve Venting WARNING Refrigerant under High Pressure! Figure 33. High pressure side relief valves Oil Separator Relief Valves (RTUD only) System contains oil and refrigerant under high pressure. Recover refrigerant to relieve pressure before opening the system. See unit nameplate for refrigerant type. Do not use non-approved refrigerants, refrigerant substitutes, or refrigerant additives.
PAGE 58
Installation - Mechanical RTUD Installation Figure 34. Evaporator relief valves The installation of a split system offers a good economic alternative to satisfy the chilled water demand for cooling a building, particularly in the case of new construction.
PAGE 59
Installation - Mechanical Figure 35. Condenser installed at same elevation as compressor chiller Figure 36.
PAGE 60
Installation - Mechanical Figure 37. Condenser below the compressor chiller Discharge Line Liquid Line 15 ft max Trap Remote Air-Cooled Condenser Interconnection Refrigerant Piping The RTUD compressor chiller is shipped with a full charge of oil and a nitrogen holding charge.The Levitor II unit is an air-cooled condenser that is designed for use with the RTUD unit.The RTUD unit is designed to be most effective when used with the Levitor II aircooled condenser.
PAGE 61
Installation - Mechanical WARNING Hazard of Explosion! Figure 38. Condenser manifolding, 80-130Ton Discharge When sweating line connections, always provide a sufficient purge of dry nitrogen through the tubing to prevent the formation of oxides/scaling caused by high temperature from brazing. Use a pressure regulator in the line between the unit and the high pressure nitrogen cylinder to avoid over-pressurization and possible explosion.
PAGE 62
Installation - Mechanical System Configuration Table 39. The system can be configured in any of the primary arrangements as shown in Figure 35, p. 59, Figure 36, p. 59 and Figure 37, p. 60.The configuration and its associated elevation, along with the total distance between the RTUD and the air-cooled condenser, plays a critical role in determining the liquid line and discharge line sizes.This will also affect the field refrigerant and oil charges.
PAGE 63
Installation - Mechanical Table 41. Table 40. Height (ft) Height (ft) 3 6 9 12 15 25 1.125 1.125 1.125 1.125 1.125 1.125 50 1.125 1.125 1.125 1.125 1.125 1.125 1.125 75 1.125 1.125 1.125 1.125 1.125 1.125 1.125 1.125 100 1.125 1.125 1.125 1.125 1.125 1.125 1.125 1.125 1.125 125 1.125 1.125 1.125 1.125 1.125 1.125 1.125 1.125 1.125 1.125 150 1.125 1.125 1.125 1.125 1.125 1.125 1.125 1.125 1.125 1.125 1.125 175 1.125 1.125 1.125 1.125 1.
PAGE 64
Installation - Mechanical Table 44. Table 43. Height (ft) Ckt 2 Line Height (ft) Ckt 1 Line Total Equiv. Length (ft) Table 44. 6 9 12 15 6 9 12 15 25 1.125 1.125 1.125 1.125 1.125 1.125 25 1.125 1.125 1.125 1.125 1.125 1.125 50 1.125 1.125 1.125 1.125 1.125 1.375 50 1.125 1.125 1.125 1.125 1.125 1.125 75 1.125 1.125 1.125 1.375 1.375 1.375 100 1.125 1.375 1.375 1.375 1.375 1.375 125 1.375 1.375 1.375 1.375 1.375 1.625 150 1.375 1.375 1.375 1.
PAGE 65
Installation - Mechanical Table 47. Table 46. Height (ft) Ckt 2 Line Height (ft) Ckt 1 Line Total Equiv. Length (ft) Table 47. 3 6 9 12 15 3 6 9 12 15 25 1.375 1.375 1.375 1.375 1.375 1.375 25 1.125 1.125 1.125 1.125 1.125 1.125 50 1.375 1.375 1.375 1.375 1.375 1.375 50 1.125 1.125 1.125 1.125 1.125 1.125 75 1.375 1.375 1.375 1.375 1.375 1.375 100 1.375 1.375 1.375 1.375 1.375 1.375 125 1.375 1.375 1.375 1.375 1.375 1.375 150 1.375 1.375 1.
PAGE 66
Installation - Mechanical Table 50. Table 49. Height (ft) Ckt 2 Line Height (ft) Ckt 1 Line Total Equiv. Length (ft) Table 50. 6 9 12 15 6 9 12 15 25 1.375 1.375 1.375 1.375 1.375 1.375 25 1.375 1.375 1.375 1.375 1.375 1.375 50 1.375 1.375 1.375 1.375 1.375 1.375 50 1.375 1.375 1.375 1.375 1.375 1.375 75 1.375 1.375 1.375 1.375 1.375 1.375 100 1.375 1.375 1.375 1.375 1.375 1.375 125 1.375 1.375 1.375 1.375 1.375 1.375 150 1.375 1.375 1.375 1.
PAGE 67
Installation - Mechanical Discharge (Hot Gas) Line Sizing The discharge lines should pitch downward, in the direction of the hot gas flow, at the rate of 1/2 inch per each 10 feet of horizontal run. Discharge line size is based on the velocity needed to obtain sufficient oil return. Basic discharge line sizing is shown in Table 52, p. 67 throughTable 63, p. 70, depending on the unit configuration. Discharge lines are not typically insulated.
PAGE 68
Installation - Mechanical Table 55. Discharge (hot gas) line sizing RTUD 110 ton Leaving Water Temperature Ckt 1 Line Total Equiv. Length (ft) Table 56. 38-65 °F 10-37 °F 25 2.125 2.125 50 2.125 2.125 Ckt 2 Line 38-65 °F 10-37 °F 25 2.125 2.125 50 2.125 2.125 Leaving Water Temperature Ckt 1 Line 38-65 °F 10-37 °F 25 2.625 2.625 50 2.625 2.625 Leaving Water Temperature Ckt 2 Line 38-65 °F 10-37 °F 25 2.625 2.125 50 2.625 2.125 75 2.125 2.125 75 2.125 2.
PAGE 69
Installation - Mechanical Table 59. Discharge (hot gas) line sizing RTUD 160 ton Leaving Water Temperature Ckt 1 Line Total Equiv. Length (ft) Table 60. 38-65 °F 10-37 °F 25 2.625 2.625 50 2.625 2.625 Discharge (hot gas) line sizing RTUD 200 ton Leaving Water Temperature Ckt 2 Line 38-65 °F 10-37 °F 25 2.625 2.625 50 2.625 2.625 Leaving Water Temperature Ckt 1 Line 38-65 °F 10-37 °F 25 2.625 2.625 50 2.625 2.
PAGE 70
Installation - Mechanical Table 63. Discharge (hot gas) line sizing RTUD 250 ton Leaving Water Temperature Ckt 1 Line Total Equiv. Length (ft) 38-65 °F 10-37 °F 25 3.125 3.125 50 3.125 3.125 Leaving Water Temperature Ckt 2 Line 38-65 °F 10-37 °F 25 3.125 3.125 50 3.125 3.125 75 3.125 3.125 75 3.125 3.125 100 3.125 3.125 100 3.125 3.125 125 3.125 3.125 125 3.125 3.125 150 3.125 3.125 150 3.125 3.125 175 3.125 3.125 175 3.125 3.125 200 3.125 3.125 200 3.
PAGE 71
Installation - Mechanical Shown in Figure 40, p. 70 are RTUD 100 ton andTrane Levitor II condenser designed for a leaving evaporator water temperature of 42°F.This example will show how to calculate the line sizes for both the liquid and discharge lines.The discharge line consists of one long radius elbow and 4 short radius elbows.The liquid line also consists of one long radius elbow and 4 short radius elbows. Table 64. System refrigerant charge - lbs Condenser RTUD Max.
PAGE 72
Installation - Mechanical NOTICE: Equipment Damage! Add initial field refrigerant charge only through the service valve on the liquid line, not the service valves on the evaporator, and insure that water is flowing through the evaporator during the charging process. Failure to do the above could result in equipment damage.
PAGE 73
Installation - Mechanical for the field connections to the condenser, will have screw terminals for termination in the RTUD control panel with the exception of the outdoor air temperature sensor (addressed above). Refer to the wiring diagrams. Separate fan control algorithms are used for fixed speed and variable speed systems. For the variable speed fan deck option, the fan control reverts to fixed speed control if an inverter drive fault is detected through a binary input interface with the drive.
PAGE 74
Installation - Mechanical Shipping Spacers NOTICE: Excessive Noise and Vibration! Failure to remove the spacers could result in excessive noise and vibration transmission into the building For RTWD units listed in table below, and all RTUD 80-130 ton units, remove and discard the two shipping spacers with four bolts, located underneath the oil separator, as shown in Figure 42, p. 74 before starting unit. Table 66.
PAGE 75
Installation - Electrical General Recommendations All wiring must comply with local codes and the National Electric Code.Typical field wiring diagrams are included at the end of the manual. Minimum circuit ampacities and other unit electrical data are on the unit nameplate and in Table 67. See the unit order specifications for actual electrical data. Specific electrical schematics and connection diagrams are shipped with the unit.
PAGE 76
Installation - Electrical Table 67.
PAGE 77
Installation - Electrical Table 68.
PAGE 78
Installation - Electrical Table 69.
PAGE 79
Installation - Electrical Table 70.
PAGE 80
Installation - Electrical Table 70.
PAGE 81
Installation - Electrical Table 72.
PAGE 82
Installation - Electrical Table 72.
PAGE 83
Installation - Electrical Table 73. Electrical Data – Trane Air-Cooled Condenser – 60 Hz (continued) Unit Wiring Standard Ambient Unit Size RTUD 150 RTUD 160 RTUD 180 RTUD 200 RTUD 220 RTUD 250 Low Ambient Rated Voltage Fan FLA Fan MCA Fan MOP Fan FLA Fan MCA 208-230/60/3 6 37.5 40 6 37.5 Fan MOP 40 460/60/3 3 18.8 20 3 18.8 20 575/60/3 2.5 15.6 15 2.5 16.8 15 208-230/60/3 6 37.5 40 6 37.5 40 460/60/3 3 18.8 20 3 18.8 20 575/60/3 2.5 15.6 15 2.5 16.
PAGE 84
Installation - Electrical Table 75.
PAGE 85
Installation - Electrical Table 77. Electrical Data - RTWD - 50 Hz - premium efficiency - standard condensing temperature Unit Wiring Unit Size Rated Voltage 160 Single Point Power 1 Power Connection Dual Point Power 2 Power Connections Motor Data MCA MOP MCA MOP RLA LRA YD LRA XL 400/50/3 221 300 124/122 200/200 97/97 259/259 796/796 180 400/50/3 246 350 124/147 200/250 97/117 259/291 796/896 200 400/50/3 266 350 149/147 250/250 117/117 291/291 896/896 Notes: 1.
PAGE 86
Installation - Electrical Table 79.
PAGE 87
Installation - Electrical Table 79.
PAGE 88
Installation - Electrical Table 80.
PAGE 89
Installation - Electrical Table 80.
PAGE 90
Installation - Electrical Table 80.
PAGE 91
Installation - Electrical Table 81.
PAGE 92
Installation - Electrical Table 81.
PAGE 93
Installation - Electrical Table 82.
PAGE 94
Installation - Electrical Table 82.
PAGE 95
Installation - Electrical Table 82.
PAGE 96
Installation - Electrical Table 83.
PAGE 97
Installation - Electrical Table 83.
PAGE 98
Installation - Electrical Table 84.
PAGE 99
Installation - Electrical Table 84.
PAGE 100
Installation - Electrical Table 84.
PAGE 101
Installation - Electrical Table 84.
PAGE 102
Installation - Electrical Table 85.
PAGE 103
Installation - Electrical Table 86.
PAGE 104
Installation - Electrical Table 87.
PAGE 105
Installation - Electrical Table 88.
PAGE 106
Installation - Electrical Power Supply Wiring All power supply wiring must be sized and selected accordingly by the project engineer in accordance with NECTable 310-16. WARNING Proper Field Wiring and Grounding Required! All field wiring MUST be performed by qualified personnel. Improperly installed and grounded field wiring poses FIRE and ELECTROCUTION hazards.
PAGE 107
Installation - Electrical Control Power Supply The unit is equipped with a control power transformer; it is not necessary to provide additional control power voltage to the unit. All units are factory-connected for appropriate labeled voltages. Interconnecting Wiring Chilled Water Flow (Pump) Interlock If paddle option is selected, RTWD/RTUD Series R® chillers require a field-supplied control voltage contact input through a flow proving switch 5S5 and an auxiliary contact 5K9 AUX.
PAGE 108
Installation - Electrical Alarm and Status Relay Outputs (Programmable Relays) A programmable relay concept provides for enunciation of certain events or states of the chiller, selected from a list of likely needs, while only using four physical output relays, as shown in the field wiring diagram.The four relays are provided (generally with a Quad Relay Output LLID) as part of the Alarm Relay Output Option.The relay’s contacts are Table 91.
PAGE 109
Installation - Electrical Emergency Stop CH530 provides auxiliary control for a customer specified/ installed latching trip out. When this customer-furnished remote contact 5K24 is provided, the chiller will run normally when the contact is closed. When the contact opens, the unit will trip on a manually resettable diagnostic.This condition requires manual reset at the chiller switch on the front of the control panel. Connect low voltage leads to terminal strip locations on 1A5, J2-3 and 4.
PAGE 110
Installation - Electrical External Chilled or Hot Water Setpoint (ECWS/EHWS) Option The CH530 provides inputs that accept either 4-20 mA or 210 VDC signals to set the external water setpoint (EWS). • When the unit is in cooling mode, the EWS will correspond to the chilled water setpoint (ECWS). • When the unit is in heating mode, the EWS will correspond to the hot water setpoint (EHWS). This is not a reset function.The input defines the set point.
PAGE 111
Installation - Electrical Depending on the type to be used, theTechView Service Tool must be used to configure the LLID and the MP for the proper input type that is being used.This is accomplished by a setting change on the CustomTab of the Configuration View withinTechView. Outdoor The J2-3 and J2-6 terminal is chassis grounded and terminal J2-1 and J2-4 can be used to source 12 VDC.The ECLS uses terminals J2-2 and J2-3. ECWS uses terminals J2-5 and J2-6.
PAGE 112
Installation - Electrical Outdoor Air Temperature Sensor Installation Requirements The outdoor air temperature sensor is optional for the RTWD water cooled units, but is a required sensor for the RTUD compressor chiller units.The sensor is required as an important input to the condenser fan control algorithm as well as for the low outdoor air ambient lockout feature. The temperature sensor probe is shipped separately inside the control panel.
PAGE 113
Installation - Electrical shielded, twisted pair connection establishes the bidirectional communications link between theTracer CH530 and the building automation system. Note: To prevent control malfunctions, do not run low voltage wiring (<30 V) in conduit with conductors carrying more than 30 volts. WARNING Proper Field Wiring and Grounding Required! All field wiring MUST be performed by qualified personnel. Improperly installed and grounded field wiring poses FIRE and ELECTROCUTION hazards.
PAGE 114
Installation - Electrical BACnet systems and devices using BACnet MS/TP.This section includes information about: Device Management-Device Communication ControlB (DM-DCC-B) ü • BACnet protocol implementation conformance statement (PICS) Device Management-Dynamic Device Binding-A (DMDDB-A) ü • Object types: descriptions and configuration (see Table 98, p.
PAGE 115
Installation - Electrical Object Types Table 98.
PAGE 116
Installation - Electrical Table 98.
PAGE 117
Installation - Electrical Table 98.
PAGE 118
Installation - Electrical Device Address Binding Table 99. Device Address Binding Supported? Static Device Binding Supported ü Networking Options Networking Descriptions Supported Option Annex H, BACnet Tunneling Analog output Object Identifier Object Name Analog Output 1 ANSI X3.4 Supported ü ISO 8859-1 ü JIS C 6226 Object Data Points and Diagnostic Data Points with Corresponding Chiller Models For quick reference, the following tables are listed two different ways.
PAGE 119
Installation - Electrical Table 100. Analog Input (continued) Object Identifier Object Name Description Analog Input, 24 Unit Power Consumption The power being consumed by the chiller. Analog Input, 25 Local Atmospheric Pressure Local atmospheric pressure. Table 100. Analog Input (continued) Units Kilowatts PSI Analog Input, 26 StartsNumber of starts for Compressor 1A compressor 1A. None Analog Input, 27 StartsNumber of starts for Compressor 1B compressor 1B.
PAGE 120
Installation - Electrical Table 100. Analog Input (continued) Object Identifier Object Name Table 101.
PAGE 121
Installation - Electrical Table 102. Multistate Input (continued) Table 104. Binary Input (continued) BCI-C Object Object Identifier Name Description Object States Multi-State Input, 6 Cooling Type Cooling type of the condenser. 1 = Water Cooled 2 = Air Cooled Manuf Location 1 = Field Applied 2 = La Crosse 3 = Pueblo 4 = Charmes 5 = Rushville 6 = Macon 7 = Waco 8 = Lexington Location where 9 = Forsyth chiller was 10 = Clarksville manufactured. 11 = Ft.
PAGE 122
Installation - Electrical Table 105. All ObjectTypes Sorted by Object Name (Refer to previous tables for detailed descriptions of objects) Table 105. All ObjectTypes Sorted by Object Name (Refer to previous tables for detailed descriptions of objects) Object Identifie Object Name r(a) Object Identifie Object Name r(a) Description Analog Output 1 Chilled Water Setpoint Desired leaving water temperature if chiller is in cooling mode.
PAGE 123
Installation - Electrical Table 105. All ObjectTypes Sorted by Object Name (Refer to previous tables for detailed descriptions of objects) Object Identifie Object Name r(a) Description Analog Input, 68 Phase AB VoltageCompressor 2B Phase AB voltage, compressor 2B. Analog Input, 69 Phase BC VoltageCompressor 2B Phase BC voltage, compressor 2B. Analog Input, 70 Phase CA VoltageCompressor 2B Analog Input, 71 Table 105.
PAGE 124
Installation - Electrical Table 105. All ObjectTypes Sorted by Object Name (Refer to previous tables for detailed descriptions of objects) Object Identifie Object Name r(a) BI 25; Last Diagnostic. •The active text of this object will reflect the description of the last diagnostic to occur on the chiller. BO 2; Remote Diagnostic Reset Command. •This Description Binary Input, 3 Capacity Limited Indicates if conditions may exist that prevent the chiller from reaching setpoint.
PAGE 125
RTWD/RTUD Operating Principles This section contains an overview of the operation of RTWD Series R chillers equipped with microcomputerbased control systems. It describes the overall operating principles of the RTWD water chiller. Note: To ensure proper diagnosis and repair, contact a qualified service organization if a problem should occur. General RTWD The Model RTWD units are dual-compressor, dual circuit, water-cooled liquid chillers.These units are equipped with unit-mounted starter/control panels.
PAGE 126
RTWD/RTUD Operating Principles Figure 47. RTWD/RTUD components (back view) Circuit 2 Compressor Junction Box Discharge Service Valve Condenser (RTWD only) Gas Pump (behind frame) Base rail for forklifting (optional) Refrigeration (Cooling) Cycle Overview The refrigeration cycle of the Series R chiller is conceptually similar to that of otherTrane chiller products.
PAGE 127
RTWD/RTUD Operating Principles Figure 48. Pressure enthalpy curve Liquid 3 4 2 Pressure 1 5 Gas Enthalpy Evaporation of refrigerant occurs in the evaporator. A metered amount of refrigerant liquid enters a distribution system in the evaporator shell and is then distributed to the tubes in the evaporator tube bundle.The refrigerant absorbs heat and vaporizes as it cools the water flowing through the evaporator tubes. Refrigerant vapor leaves the evaporator as saturated vapor (State Pt. 1).
PAGE 128
RTWD/RTUD Operating Principles Figure 49.
PAGE 129
RTWD/RTUD Operating Principles Oil System Operation (RTWD/RTUD) Overview Oil that collects in the bottom of the oil separator is at condensing pressure during compressor operation; therefore, oil is constantly moving to lower pressure areas. As the oil leaves the separator, it passes through the oil cooler (if installed). It then goes through the service valve and filter. At this point it travels through the oil control valve.Then it provides oil injection and bearing lubrication.
PAGE 130
RTWD/RTUD Operating Principles The helical rotary compressor is a positive displacement device.The refrigerant from the evaporator is drawn into the suction opening at the end of the motor barrel, through a suction strainer screen, across the motor, and into the intake of the compressor rotor section.The gas is then compressed and discharged directly into the discharge line. There is no physical contact between rotors and compressor housing.
PAGE 131
Controls Interface CH530 Communications Overview TheTrane CH530 control system that runs the chiller consists of several elements: languages as factory-ordered or can be easily downloaded from www.trane.com. The DynaView enclosure design is weatherproof and made of durable plastic for use as a device on the outside of the unit. The display on DynaView is a 1/4 VGA display with a resistive touch screen and an LED backlight.The display area is approximately 4 inches wide by 3 inches high (102mm x 60mm).
PAGE 132
Controls Interface Display Screens The AUTO and STOP keys, take precedence over the Enter and Cancel keys. (While a setting is being changed, AUTO and STOP keys are recognized even if Enter or Cancel has not been pressed.) Basic Screen Format The basic screen format appears as: Tab navigator The ALARMS button appears only when an alarm is present, and blinks (by alternating between normal and reverse video) to draw attention to a diagnostic condition.
PAGE 133
Controls Interface operator that a diagnostic exists.The second purpose is to provide navigation to a diagnostic display screen. Run Inhibit, etc.).The “additional info” icon will present a subscreen that lists in further detail the subsystem modes. Figure 52. Diagnostic screen Note: A complete listing of diagnostics and codes is included in the Diagnostic Section. Manual Override Exists An indicator to present the presence of a manual override will share space with the Alarms enunciator key.
PAGE 134
Controls Interface Table 107. Chiller mode Chiller Modes Description Top Level Mode Further information is provided by the submode Sub-modes Stopped The chiller is not running either circuit, and cannot run without intervention. Stopped Sub-modes Local Stop Immediate Stop No Circuits Available Chiller is stopped by DynaView Stop button command- cannot be remotely overridden.
PAGE 135
Controls Interface Table 107. Chiller mode (continued) Chiller Modes Description Top Level Mode Further information is provided by the submode Sub-modes The chiller is not currently running and there is a call for cooling but the lead circuit start is delayed by certain interlocks or proofs.
PAGE 136
Controls Interface Table 108. Circuit modes Circuit Modes Description Top Level Mode Further information is provided by the submode Sub-modes Stopped The given circuit is not running and cannot run without intervention. Stopped Sub-modes Diagnostic Shutdown - Manual Reset Front Panel Circuit Lockout External Circuit Lockout The circuit has been shutdown on a latching diagnostic.
PAGE 137
Controls Interface Table 108. Circuit modes (continued) Circuit Modes Description Top Level Mode Further information is provided by the submode Sub-modes Current Limit High Condenser Pressure Limit The compressor is running and its capacity is being limited by high currents. The current limit setting is 120% RLA (to avoid overcurrent trips) or lower as set by the compressor's "share" of the active current limit (demand limit) setting for the entire chiller.
PAGE 138
Controls Interface • Constant Return • Outdoor • Disabled The left column text “Front Panel”, “BAS” or “Schedule”, “External”, “Auxiliary”, “Chilled Water Reset”, and “Active Chilled Water Setpoint” will always be present regardless of installation or enabling those optional items. In the second column “-----” will be shown if that option is Not Installed, otherwise the current setpoint from that source will be shown.
PAGE 139
Controls Interface Local Time of Day Schedule Screen Table 110. Feature settings (continued) Resolution or (Enumerations), Default Description Units Chilled Water Reset (Const Return, Outdoor, Return, Disable), Disable Enum Return Reset Ratio XXX % Return Start Ratio XXX.X Temp Return Maximum Reset XXX.X Temp Outdoor Reset Ratio XXX % Outdoor Start Reset XXX.X Temp Outdoor Maximum Reset XXX.
PAGE 140
Controls Interface Event Time Screen Event Enable/Disable Screen Event Arbitrated Settings Screens For analog setpoints, the screen is slightly different than the standard screen, because there are two additional buttons - “Enable” and “Disable”. Selecting “Used” will make the setting valid and allow the user to change the value. Selecting “Not Used” will make the setting invalid, and will not allow the user to change the value.
PAGE 141
Controls Interface displayed in a changeable format consistent with its type. Binary setpoints are considered to be simple two state enumerations and will use radio buttons. Analog setpoints are displayed as spin buttons.The lower half of the screen is reserved for help screens. Display Settings Screen Table 113.
PAGE 142
Controls Interface Mode Override for Enumerated Settings is shown below: Date/Time Subscreen The setpoint screen for setting up the CH530 date is shown below:The user must select Day, Month, orYear and then use the up/down arrows to adjust. The setpoint screen for setting up the CH530 time with a 12 hour format is shown below:The user must select Hour or Minute and then use the up/down arrows to adjust. Adjusting hours will also adjust am/pm.
PAGE 143
Controls Interface Lockout Screen The DynaView Display andTouch Screen Lock screen is shown.This screen is used if the Display andTouch Screen Lock feature is Enabled.Thirty minutes after the last key stroke this screen will be displayed and the Display and Touch Screen will be locked out until “159 Enter” is entered. Until the proper password is entered there will be no access to the DynaView screens including all reports, all setpoints, and Auto/Stop/Alarms/Interlocks.
PAGE 144
Controls Interface Table 117. Report name: system compressor (continued) Description Resolution Units Energy Consump - Resettable kWh Time of Last Reset time-date Energy Consump - NonReset kWh Power Up and Self Tests Power-Up DynaView On Power-Up DynaView will progress through three screens: First Screen, Application Status, Boot Software P/N, Self Test and ApplicationTime Stamp. Table 118. Report name: circuit compressor Description Resolution Units Oil Pressure XXX.
PAGE 145
Controls Interface TechView TechView is the PC (laptop) based tool used for servicing Tracer CH530.Technicians that make any chiller control modification or service any diagnostic withTracer CH530 must use a laptop running the software application “TechView.” TechView is aTrane application developed to minimize chiller downtime and aid the technicians understanding of chiller operation and service requirements. Important: 3. A download link will be sent to the e-mail address provided.
PAGE 146
Controls Interface Minimum PC requirements to install and operate TechView TechView is also used to perform any CH530 service or maintenance function. Servicing a CH530 main processor includes: • Microsoft Windows XP Professional or Windows Vista Business operating system • Internet Explorer 6.0 and higher • Monitoring chiller operation • USB 2.
PAGE 147
Controls Interface Figure 55. Unit view (RTUD) The Unit View displays the system, control point name, value and unit of measure. It reflects active setpoints and allows you to make changes. Unit View also displays, in real time, all non-setpoint data organized by tabs. As data changes on the chiller, it is automatically updated in the Unit View.
PAGE 148
Controls Interface Figure 56. Unit view - RTUD condenser elevation Table 121. Unit view tabs - detail Tab System Control Point Name Status Unit Min Max Default deg F (C) 10 (-12.22) 65 (18.33) 45 (7.22) 80 (26.66) 140 (60) 90 (32.22) 60 120 120 ft -26.25 98.
PAGE 149
Controls Interface Table 121.
PAGE 150
Controls Interface Table 121.
PAGE 151
Controls Interface Table 121.
PAGE 152
Controls Interface Table 121.
PAGE 153
Controls Interface Table 121. Unit view tabs - detail (continued) Tab System Control Point Name Status Unit Circuit 2 Revise Compressor 2A Run Time Setting hrs:mins Min Max Circuit 2 Revise Compressor 2A Starts Setting starts Chiller Data Recorder Enable/Disable Setpoint Chiller Data Recorder Change Delta Setpoint Chiller Data Recorder Sample Period Setpoint Default 0 4294967295 0 1.0 0.2 Sec 1 3600 2 0 2.8 0.6 0 34.5 13.
PAGE 154
Controls Interface Figure 57. Fields in white To change the setpoint, enter a new value for the setpoint into the text field. Figure 58. Change setpoint If the entered value is outside the given range, the background turns red. Figure 59. Change out of range If the value entered is not valid, an error message will display and the change will not occur. Figure 60. Setpoint change failed Status View Status View displays, in real time, all non-setpoint data organized by subsystem tabs.
PAGE 155
Controls Interface Figure 61. Status view Table 122. Status view tab - detail (continued) Table 122.
PAGE 156
Controls Interface Table 122. Status view tab - detail (continued) Tab Table 122.
PAGE 157
Controls Interface Table 122. Status view tab - detail (continued) Tab Control Point Name Table 122.
PAGE 158
Controls Interface Resetting the active diagnostics may cause the chiller to resume operation. The Active and History diagnostics have separate tabs. A button to reset the active diagnostics displays when either tab is selected. Figure 62. Diagnostic view Configuration View This view is under the CH530 tab. It displays the active configuration and allows you to make changes to the unit configuration. Figure 63.
PAGE 159
Controls Interface Table 123. Configuration view items - detail (continued) Tab Item RTWD/CH530 Configuration Control Sequence Description Table 123.
PAGE 160
Controls Interface Table 123. Configuration view items - detail (continued) Tab Item Compressor 1A Frame Size Description Table 123. Configuration view items - detail (continued) Tab Item K1 K2 L1 Condenser Leaving Hot Water Temp Control (HWTC) L2 N1 BAS Communication/Local Time of Day Schedule (COMM) N2 Compressor 2A Frame Size Local Time of Day Scheduling K2 L2 ECWS Maximum Temperature 10 to 18.
PAGE 161
Controls Interface Table 123. Configuration view items - detail (continued) Tab Item Description Warning Programmable Status Relay 3 (J2-4,5,6) Table 123.
PAGE 162
Controls Interface Figure 64. Configuration view - options tab Software View Software view allows you to verify the version of chiller software currently running on the DynaView and download a new version of chiller software to the DynaView. You can also add up to two available languages to load into the DynaView. Loading an alternate language file allows the DynaView to display its text in the selected alternate language, English will always be available. Figure 65.
PAGE 163
Controls Interface . Figure 66. Binding view Replacing or Adding Devices If a device is communicating but incorrectly configured, it might not be necessary to replace it. If the problem with the device is related to communication, attempt to rebind it, and if the device becomes correctly configured, it will then communicate properly. If a device that needs to be replaced is still communicating, it should be unbound.
PAGE 164
Controls Interface Figure 68. A/C fan controls - RTUD No Fan Controls (Water Cooled) If this setting is set to “No Fan Controls (Water Cooled)”, the unit shall be controlled exactly the same as an RTWD unit, that is, that the control logic and sequences will assume that there is a water cooled condenser and condenser water pump control, condenser water flow proving, and circuits start delay times associated with condenser water pump prerun times shall be employed.
PAGE 165
Controls Interface If this setting is set to “None”, fan control shall be per the full speed fixed speed fan tables with each circuit applying the Fan Deck Arrangement configuration selected below. If this setting is “Two Speed Fan” (TSPD), fan control shall provide for the first fan to be a two speed fan and control and the first two relays of the quad relay shall be used for low and high speed control of that fan.
PAGE 166
Controls Interface Fan Deck Arrangement Circuit 2 Note: Present if A/C Fan Control (ACFC) = Integral This setting is the same as above, except for circuit 2. Each circuit may have different fan arrangements, but both must use an identical type of low ambient fan control if applicable. Example for Fan Configurations An air cooled condensing unit is selected that properly matches the capacity of the RTUD unit intended for a comfort cooling application.
PAGE 167
Controls Interface Figure 73. Service tool configuration - fan deck arrangement The character in the 4 digit descriptor define the number of fans that are intended to be wired to each of the 4 relays on the respective circuit’s quad fan control relay LLID.The first of the two possible 5 fan arrangements uses sequence 1 H 1 3.This sequence implies there should be 1 fan wired to relay 1 (terminals J2-1,3 of module 1A25 – Circuit 1 Fan Control module, which are internally wired to the 1X11 terminals 1 & 2).
PAGE 168
Pre-Start Checkout When installation is complete, but prior to putting the unit into service, the following pre-start procedures must be reviewed and verified correct: WARNING Hazardous Voltage! Disconnect all electric power, including remote disconnects before servicing. Follow proper lockout/ tagout procedures to ensure the power can not be inadvertently energized. Failure to disconnect power before servicing could result in death or serious injury.
PAGE 169
Pre-Start Checkout Unit Voltage Power Supply WARNING Live Electrical Components! During installation, testing, servicing and troubleshooting of this product, it may be necessary to work with live electrical components. Have a qualified licensed electrician or other individual who has been properly trained in handling live electrical components perform these tasks. Failure to follow all electrical safety precautions when exposed to live electrical components could result in death or serious injury.
PAGE 170
Pre-Start Checkout WARNING Hazardous Voltage! Disconnect all electric power, including remote disconnects before servicing. Follow proper lockout/ tagout procedures to ensure the power can not be inadvertently energized. Failure to disconnect power before servicing could result in death or serious injury. Water System Flow Rates Establish a balanced chilled water flow through the evaporator.The flow rates should fall between the minimum and maximum values.
PAGE 171
Unit Start-Up Procedures Sequence of Operation Power Up The Power up chart shows the respective DynaView screens during a power up of the main processor.This process takes from 30 to 50 seconds depending on the number of installed Options. On all power ups, the software model will always transition through the 'Stopped' Software state independent of the last mode. If the last mode before power down was 'Auto', the transition from 'Stopped' to 'Starting' occurs, but it is not apparent to the user.
PAGE 172
Power Applied Auto Waiting to Start Re-calibrate EXV (overdrive closed and then to 50%) Oil Heater always energized when compressor is deenergized Confirm Evaporator Water Flow Within 20 minutes (6 Sec Filter) Energize Evaporator Water Pump Relay (adj 0 to 30 mins) Condenser Water Pump Pre-Run Waiting to Start Waiting to Start Waiting to Start Waiting to Start (0 to 300 Sec) Start Command to Lead Cprsr* * Lead Compressor (and its lead circuit) is determined by staging algorithm – “fixed st
PAGE 173
Unit Start-Up Procedures Stopped to Starting: The stopped to starting diagram shows the timing from a stopped mode to energizing the compressor.The shortest allowable time would be under the following conditions: 1. No motor restart inhibit 2. Evaporator and Condenser Water flowing 3. Power up Start DelayTimer has expired 4. Adjustable Stop to StartTimer has expired 5. Need to cool The above conditions would allow the compressor to start in 60 seconds.
PAGE 174
Power Applied Auto EXVs selfclose on power up EXV remains closed EXV stroke to Preposition 0-20 sec Waiting to Start Set Condenser Fan’s Pre-Flow % per Outdoor Temperature Confirm Presence of Oil (0 to 2 mins) Waiting to Start Energize Oil Return Drain Solenoid of Lead Circuit Send Start Command to Lead Compressor Start Command to Lead Compressor* Check Evap Pressure for Low Pressure Cutout Pre-Position EXV of Lead Circuit Energize Unload Solenoid of Lead Cprsr Energize Oil Return Fill So
PAGE 175
RLC-SVX09H-EN Stopped Or Run Inhibit Oil Heaters Always Energized When Respective Compressors Are De-Energized Confirm Evaporator Water Flow Within 20 minutes (6 Sec Filter) Energize Evaporator Water Pump Relay (adj 0 to 30 mins) Condenser Water Pump Pre-Run Waiting to Start Enforce 'Cprsr Strt Delay' (0 to 300 Sec) Waiting to Start Waiting to Start Start Command to Lead Cprsr* Pre-Position EXV of Lead Circuit Energize Unload Solenoid of Lead Cprsr Energize Oil Return Fill Solenoid of Lead Circu
PAGE 176
Oil Heaters Always Energized When Respective Compressors Are De-Energized Confirm Evaporator Water Flow Within 20 minutes (6 Sec Filter) Energize Evaporator Water Pump Relay Enforce Restart Inhibit Timer (0 to 5 mins) Confirm Evaporator Water Flow (6 Second Filter) Auto EXV stroke to Preposition 0-20 sec Waiting to Start Set Condenser Fan’s Pre-Flow % per Outdoor Temperature Confirm Presence of Oil (0 to 2 mins) Waiting to Start Call for Cooling (adj Differential to Start is met) * Lead Compr
PAGE 177
Unit Start-Up Procedures Start-up refrigerant charges are shown in the General Data tables. Important: NOTICE: Equipment Damage! Ensure that the oil separator and compressor heaters have been operating for a minimum of 24 hours before starting. Failure to do so may result in equipment damage. A clear sight glass alone does not mean that the system is properly charged. Also check system subcooling, liquid level control and unit operating pressures. 9. Measure the system subcooling. 2.
PAGE 178
Unit Start-Up Procedures Figure 80. Start-up log RTWD/RTUD Start-up Test Log Job Name Job Location Model # Serial # Sales Order # ship date: start date: Job elevation (ft.
PAGE 179
RLC-SVX09H-EN Running Energize Unload Solenoid Both Compressors DeEnergize Step Load Solenoid Both Compressors Brief Run-Unload, both Compressors (5 Seconds) 1 sec Shutting Down Energize all Oil Heaters De-Energize Oil Return Fill and Draing Solenoids of Both Circuits Leave Both Cprsr’s Unload Solenoids Energized for 60 mins De-Energize Condenser Water Pump Relay Both Circuit’s EXVs to 50% for off cycle Confirm No Compressor Currents 8 Seconds after compressor is de-energized De-Energize Evapora
PAGE 180
1 sec DeEnergize Step Load Solenoid Both Compressors Energize Unload Solenoid Both Compressors Brief Run-Unload, both Compressors (5 Seconds) Shutting Down Check for Normal Pumpdown Termination Criteria Met** Close EXV’s and Perform Operational Pumpdown (if regd*) for both Circuits The maximum allowed time for Operational Pumpdown is 2 minutes.
PAGE 181
Service and Maintenance Overview This section describes preventative maintenance procedures and intervals for the RTWD unit. Use a periodic maintenance program to ensure optimal performance and efficiency of the Series R units. An important aspect of the chiller maintenance program is the regular completion of the “Series R Operating Log”; an example of this log is provided in this manual.
PAGE 182
Service and Maintenance WARNING Hazardous Voltage! Disconnect all electric power, including remote disconnects before servicing. Follow proper lockout/ tagout procedures to ensure the power can not be inadvertently energized. Failure to disconnect power before servicing could result in death or serious injury. • Perform all weekly and monthly maintenance procedures. • Check the refrigerant charge and oil level. Refer to “Maintenance Procedures”.
PAGE 183
Service and Maintenance Chiller Log Main Tab Chiller Mode Evap Ent/Lvg Water Temp Cond Ent/Lvg Water Temp Active Chilled Water Setpoint (F) Average Line Current (%RLA) Active Current Limit Setpoint (%RLA) So ware Type Software Version Reports Tab 15 min Run Time 30 min 1 hr Evaporator Evap Entering Water Temperature (F) Evap Leaving Water Temperature (F) Evap Sat Rfgt Temp (F) Evap Rfgt Pressure (psia) Evap Approach Temp (F) Evap Water Flow Switch Status Expansion Valve Position (%) Expansion Valve Pos
PAGE 184
Service and Maintenance 184 RLC-SVX09H-EN
PAGE 185
Service and Maintenance Service Procedures Cleaning the Condense (RTWD Only) WARNING NOTICE: Proper Water Treatment! The use of untreated or improperly treated water could result in scaling, erosion, corrosion, algae or slime. It is recommended that the services of a qualified water treatment specialist be engaged to determine what water treatment, if any, is required.
PAGE 186
Service and Maintenance (course/fine, English/metric). Bolt diameter (English/ metric). Figure 83. Water box lifting #ABLES #HAINS OR 3LINGS 11. Disconnect water pipes, if connected. 12. Remove the two bolts with drill point mark. Install the long bolts into these two holes.The long bolts are located on the two thread holes just above the waterbox, as shown in Figure 84. Figure 84. Waterbox removal - remove bolts #ONNECTION $EVICE long bolt drill point m ark 7ATERBOX 5.
PAGE 187
Service and Maintenance Important: Figure 86. Waterbox removal - swing out, install lifting chain Do not leave waterbox suspended from lifting device. 17. Work a round nylon or brass bristled brush (attached to a rod) in and out of each of the condenser water tubes to loosen the sludge. 18. Thoroughly flush the condenser water tubes with clean water. Note: (To clean internally enhanced tubes, use a bidirectional brush or consult a qualified service organization for recommendations.
PAGE 188
Service and Maintenance Table 129. RTWD/RTUD Evaporator waterbox weights (continued) Standard Grooved Pipe Waterbox Model Size Hz Effic Waterbox RTWD 150, 160, 180, 200, 220, 250 60 HIGH Return RTWD 150, 160, 180, 200 60 PREM Return RTWD 130, 140, 160, 180, 200, 220, 250 50 HIGH Return RTWD 160, 180, 200 50 PREM Return RTUD 150, 160, 180, 200, 220, 250 60 HIGH Return Weight - kg (lbs) Lifting Connection 29.9 (66) M12x1.75 Table 130.
PAGE 189
Service and Maintenance significantly higher temperature than the ambient outdoor air temperature (5 ºF or more). 1. Run the unit fully unloaded for approximately 20 minutes. All of the fans should also be validated to be operational with the proper fan blade rotation direction. Dirty, or fouled coils, or otherwise limited or restricted air flow through the coils, can significantly degrade the efficiency of the chiller as well as result in unnecessary limits and nuisance trips.
PAGE 190
Service and Maintenance 6. If the level is below 4”, there is not enough oil in the sump.This can occur from not enough oil in the system or more likely, oil migration to the evaporator. Oil migration can occur from a low refrigerant charge, gas pump malfunction, etc. Note: If the oil is logged in the evaporator confirm the operation of the gas pump. If the gas pump is not functioning properly all oil will be logged in the evaporator. 7.
PAGE 191
Service and Maintenance Figure 89. Recommended oil filter replacement Unit shut down Minimum system pressure differential = 25 psid GP2 / RTWD Clean Filter Versus Recommended Filter Replacement Line CH530 RTWD Oil Pressure Protection Scheme Start protection line for 1st 2.5 minutes of operation Run protection line after 2.
PAGE 192
Service and Maintenance • Fully open expansion valve • Possible whistling sound coming from liquid line (due to high vapor velocity) • High condenser + subcooler pressure drop Some symptoms of a refrigerant over-charged unit: • High subcooling • Evaporator liquid level higher than centerline after shut down • Larger than normal condenser approach temperatures (entering condenser saturated temperature – leaving condenser water temperature) 5.
PAGE 193
Diagnostics Diagnostic Name and Source: Name of Diagnostic and its source. Note that this is the exact text used in the User Interface and/or ServiceTool displays. AffectsTarget: Defines the “target” or what is affected by the diagnostic. Usually either the entire Chiller, or a particular Circuit or Compressor is affected by the diagnostic (the same one as the source), but in special cases functions are modified or disabled by the diagnostic.
PAGE 194
Diagnostics Starter Diagnostics Table 133. Starter Diagnostics Diagnostic Name and Source Compressor Did Not Accelerate: Transition Compressor 1A Affects Target *Circuit Severity Info Persist Active Modes ence [Inactive Modes] Latch Criteria Reset Level Start Mode The compressor did not come up to speed (fall to <85%RLA) in the allotted time defined by the Maximum Acceleration Timer and a transition was Remote forced (motor put across the line) at that time. This applies to all starter types.
PAGE 195
Diagnostics Table 133. Starter Diagnostics Diagnostic Name and Source Affects Target Power Loss - Compressor *Circuit 1A Severity Immediate Persist Active Modes ence [Inactive Modes] Criteria Reset Level Non Latch The compressor had previously established currents while running and then all three phases of current were lost. Design: Less than 10% RLA, trip in 2.64 seconds.
PAGE 196
Diagnostics Table 133.
PAGE 197
Diagnostics Table 133.
PAGE 198
Diagnostics Table 134. Main Processor Diagnostics (continued) Diagnostic Name Affects Target BAS Failed to Establish None Communication Severity Persistence Special Action Non Latch Active Modes [Inactive Modes] Criteria Reset Level At power-up The BAS was setup as "installed" and the BAS did not communicate with the Lontalk LCIC within 15 minutes after chiller controls powerup. Refer to Section on Setpoint Arbitration to determine how setpoints and operating modes Remote may be effected.
PAGE 199
Diagnostics Table 134. Main Processor Diagnostics (continued) Diagnostic Name Evaporator Approach Error – Circuit 1 Affects Target Circuit Severity Immediate Persistence Latch Active Modes [Inactive Modes] Criteria Reset Level Respective circuit running The Evaporator approach temperature for the respective circuit (ELWT – Evap Sat Temp Ckt x) is negative by 10ºF or more, for 1 minute continuously while the circuit/compressor is Remote operating.
PAGE 200
Diagnostics Table 134.
PAGE 201
Diagnostics Table 134.
PAGE 202
Diagnostics Table 134.
PAGE 203
Diagnostics Table 134.
PAGE 204
Diagnostics Table 134.
PAGE 205
Diagnostics Table 134. Main Processor Diagnostics (continued) Diagnostic Name Affects Target Low Evaporator Water Chiller Temp: Unit On Low Oil Flow Compressor 1A Circuit Severity Immediate and Special Action Immediate Persistence Active Modes [Inactive Modes] Criteria Reset Level Non Latch The evaporator water temp. fell below the cutout setpoint for 30 degree F Seconds while the Any Ckt[s] Energzd compressor was running.
PAGE 206
Diagnostics Table 134.
PAGE 207
Diagnostics Table 134. Main Processor Diagnostics (continued) Diagnostic Name Affects Target Pumpdown Terminated Circuit - Circuit 1 Severity Info Persistence Active Modes [Inactive Modes] Criteria NonLatch Service or Operational Pumpdown Operational or Service Pumpdown cycle for this circuit was terminated abnormally due to excessive time (op pd only) or due to a specific set of diagnostic criteria – but w (o associated latching diagnostics .
PAGE 208
Diagnostics Table 134. Main Processor Diagnostics (continued) Diagnostic Name Affects Target Starter Module Memory Error Type 2 - Circuit Starter 2A Severity Immediate Persistence Latch Active Modes [Inactive Modes] Criteria Reset Level All Checksum on EEPROM copy of the Starter LLID configuration failed. Factory default values Local used. Immediate and Special Action Non Latch All Starter Panel High Limit Thermostat (170?F) trip was detected.
PAGE 209
Diagnostics Table 135. Communication Diagnostics Diagnostic Name Affects Target Severity Active Modes [Inactive Persistence Modes] Criteria Reset Level Comm Loss: Chiller% RLA Output Chiller Info Latch All Continual loss of communication between the MP and the Functional ID has occurred for a 30 Remote second period.
PAGE 210
Diagnostics Table 135. Communication Diagnostics Diagnostic Name Affects Target Severity Active Modes [Inactive Persistence Modes] Criteria Reset Level Comm Loss: Evaporator Rfgt Circuit Liquid Level, Circuit #1 Normal Latch All Continual loss of communication between the MP and the Functional ID has occurred for a 30 Remote second period.
PAGE 211
Diagnostics Table 135.
PAGE 212
Diagnostics Table 135. Communication Diagnostics Diagnostic Name Affects Target Severity Active Modes [Inactive Persistence Modes] Criteria Reset Level Comm Loss: Noise Setback None Relay Info Latch All Continual loss of communication between the MP and the Functional ID has occurred for a 30 Remote second period.
PAGE 213
Diagnostics Table 135. Communication Diagnostics Diagnostic Name Affects Target Severity Active Modes [Inactive Persistence Modes] Criteria Reset Level Starter 1A Comm Loss: MP Cprsr Immediate Latch All Starter has had a loss of communication with the Local MP for a 15 second period. Starter 2A Comm Loss: MP Cprsr Immediate Latch All Starter has had a loss of communication with the Local MP for a 15 second period. Table 136.
PAGE 214
Diagnostics Table 136. Main Processor (Boot Messages and Diagnostics) Description Troubleshooting DynaView Display Message Err5: Operating System Error Restart Timer: [30 sec countdown timer] An Operating System error has occurred while running the application code. This event will normally cause a safe shutdown of the entire chiller. Once the countdown timer reaches 0, the processor will reset, clear diagnostics, and attempt to restart the application and allow a normal restart of chiller as appropriate.
PAGE 215
Wiring Schematics Table 138 provides a list of field wiring diagrams, electrical schematics and connection diagrams for RTWD and RTUD units.The complete wiring package is documented in RLC-SVE01*-EN. A laminated wiring diagram booklet is also shipped with each unit. Unit Electrical Data To determine the specific electrical characteristics of a particular chiller, refer to the nameplates mounted on the units. Table 138.
