Datasheet

Application Note
Created by Traco Electronic AG Arp.
www.tracopower.com
Date: May 22, 2018 / Rev.: 1.0 /
Page 3 / 63
12W, Single and Dual Output
Output Specification (continue)
Parameter
Model
Min
Typ
Max
Unit
Output Over Voltage Protection (Single output only)
(Zener diode clamp)
THD 12-xx09
THD 12-xx10
THD 12-xx11
THD 12-xx12
THD 12-xx13
3.9
3.9
6.2
15
18
Vdc
Output Over Current Protection
All
150
% FL.
Output Short Circuit Protection
All
Continuous, automatics recovery
Input Specification
Parameter
Model
Min
Typ
Max
Unit
Operating Input Voltage
THD 12-12xx
THD 12-24xx
THD 12-48xx
9
18
36
12
24
48
18
36
75
Vdc
Input Current
(Maximum value at V
in
= V
in nom
; Full Load)
THD 12-1209
THD 12-1210
THD 12-1211
THD 12-1212
THD 12-1213
THD 12-1221
THD 12-1222
THD 12-1223
THD 12-2409
THD 12-2410
THD 12-2411
THD 12-2412
THD 12-2413
THD 12-2421
THD 12-2422
THD 12-2423
THD 12-4809
THD 12-4810
THD 12-4811
THD 12-4812
THD 12-4813
THD 12-4821
THD 12-4822
THD 12-4823
935
1203
1244
1219
1219
1282
1205
1205
461
594
614
602
602
633
595
595
231
297
307
301
301
316
297
297
mA
