Appendix A: Specifications

IEEE802.3 10Base-T Ethernet

IEEE802.3u 100Base-TX

IEEE802.3ab 1000Base-T Gigabit Ethernet

IEEE802.3z 1000Base-X Gigabit Ethernet

IEEE802.3x Flow Control

IEEE802.1p QoS

IEEE802.1q VLAN

Standards

IEEE802.1X Port-based Access Authentication

Ethernet: 10Mbps HD，20Mbps FD

Fast Ethernet: 100Mbps HD，200Mbps FD

Transmission Rate

Gigabit Ethernet: 2000Mbps FD

10Base-T: UTP/STP of Cat. 3 or above

100Base-TX: UTP/STP of Cat. 5

1000Base-T: 4-pair UTP (≤100m) of Cat. 5 or above

Transmission Medium

1000Base-X: MMF or SMF SFP Module (Optional)

LED

TL-SG5428:PWR, SYS, Link/Act LEDs, 1000Mbps LEDs

TL-SG5412F: PWR, SYS, Link/Act LEDs, 10/100/1000Mbps

BASE-T LED, 1000Mbps LEDs

Transmission Method Store and Forward

Packets Forwarding Rate

10BASE-T：14881pps/port

100BASE-TX：148810pps/port

1000Base-T：1488095pps/port

Operating Temperature: 0 ~ 40℃℃

Storage Temperature: -40 ~ 70℃℃

Operating Humidity: 10% ~ 90% RH Non-condensing

Operating Environment

Storage Humidity: 5% ~ 90% RH Non-condensing
