Interval: Enter the alarm interv

al time in seconds.

Owner: Enter the name of the device or user that defined the entry.

Status: Select Enable/Disable the corresponding alarm entry.

Note:

When alarm variables exceed the Threshold on the same direction continuously for several times,

an alarm event will only be generated on the first time, that is, the Rising Alarm and Falling Alarm

are triggered alternately for that the alarm following to Rising Alarm is certainly a Falling Alarm and

vice versa.
