TOSHIBA Operation Unit LKBST-65-TF12 SERIES Owner's Manual
CE Compliance (for EU only) This product complies with the requirements of EMC Directive including their amendments. “This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.” “Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.” FCC Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
Safety Summary EO1-19039 6DIHW\ 6XPPDU\ Personal safety in handling or maintaining the equipment is extremely important. Warnings and Cautions necessary for safe handling are included in this manual. All warnings and cautions contained in this manual should be read and understood before handling or maintaining the equipment. Do not attempt to effect repairs or modifications to this equipment.
Safety Summary 'LVFRQQHFW WKH SOXJ &RQQHFW D JURXQGLQJ ZLUH EO1-19039 If foreign objects (metal fragments, water, liquids) enter the machines, first turn off the power switches and disconnect the power cord plugs from the outlet, and then contact your authorized TOSHIBA TEC representative for assistance. Continued use of the machine in that condition may cause fire or electric shock. 'LVFRQQHFW WKH SOXJ Ensure that the equipment is properly grounded. Extension cables should also be grounded.
EO1-19039 LKBST-65-TF12 SERIES TABLE OF CONTENTS Page 1. INTRODUCTION----------------------------------------------------------------------------------------- 1- 1 1.1 Accessories ------------------------------------------------------------------------------------------------ 1- 1 2. SPECIFICATIONS -------------------------------------------------------------------------------------- 2- 1 2.1 2.
1. INTRODUCTION EO1-19039 1.1 Accessories 1. INTRODUCTION Thank you for purchasing the TOSHIBA LKBST-65 Operation Unit. This Operation Unit is comprised of a high brightness 12.1-inch color TFT (800x600 dots, 65,536 or 260,000 colours) with Touch Panel and a keyboard. The Operation Unit has been developed exclusive to the TOSHIBA ST-7000 series high-grade POS terminal which is designed for specialty store. The keyboard unit has a maximum of 40 keys (including numeric keys).
2. SPECIFICATIONS EO1-19039 2.1 Basic Specifications 2. SPECIFICATIONS 2.1 Basic Specifications Description 12.1-inch 248.0 (W) x 186.5 (H) mm 246.0 (W) x 184.5 (H) mm 800 (W) x 600 (H) dots 64K color (65,536 colors) or 260,000 colors 0.3075 (W) x 0.3075 (H) mm Transparency TFT Fluorescent lamp x 2 pcs. Side light type Touch Panel 12.1-inch 250.0 (W) x 185.5 (H) mm 243.8 (W) x 181.1 (H) mm Analog Resistor film (Grass + PET) 80% or more Finger touch or Pen (See NOTE 1.
3. APPEARANCE EO1-19039 3.1 Front View 3. APPEARANCE 3.
3. APPEARANCE EO1-19039 3.2 Control Lock and Mode Selector Keys 3.2 Control Lock and Mode Selector Keys Control Lock S MA X 2 REG 3 4 5 6 1 (8) (7) Mode Selector Keys S • MA X REG The key can be inserted or removed at Position 1 or 2 of the Control Lock.
4. SETUP PROCEDURE EO1-19039 4.1 Precautions for Setup 4. SETUP PROCEDURE CAUTION: The installation should be performed by an authorized installing dealer. Please contact your nearest TOSHIBA TEC representative. NOTE: The following option kits are required for connecting the unit to the POS terminal. ST-7000-2E/F series: KIT-7000-DSP1-QM-R ST-7000-1C series: KIT-7000-DSP3-QM-R 4.1 Precautions for Setup 1. Avoid locations where the unit might get wet.
5. ADJUSTMENT EO1-19039 5.1 Tilt Angle Adjustment 5. ADJUSTMENT Tilt angle, Brightness, Speaker Volume and Key Tone Volume are adjustable on the unit. CAUTION: 1. Be careful not to catch your fingers by tilt unit when changing the display angle. 2. Do not adjust the tilt angle by holding the LCD panel. Doing so may damage the unit. Be sure to hold the LCD Frame. 5.1 Tilt Angle Adjustment The tilt angle is adjustable freely within a range of 40° to 80°.
5. ADJUSTMENT EO1-19039 5.3 Speaker Volume Adjustment 5.3 Speaker Volume Adjustment The speaker volume is adjustable with the speaker volume control on the left of the rear cover as shown below. Adjust the volume with a small Phillips head screwdriver. Clockwise turn will turn up the volume and counterclockwise turn will turn down the volume. NOTES: 1. 2. Before adjusting the speaker volume, fully turn the speaker volume control on the front of the ST-7000 clockwise.
6. GENERAL MAINTENANCE EO1-19039 6.1 Cleaning 6. GENERAL MAINTENANCE 6.1 Cleaning WARNING! 1. Be sure to disconnect the power cord of the POS terminal prior to performing any maintenance. 2. Do not pour water directly on or wipe the LCD with a soaked cloth, as this may cause fire, electric shock, or machine failure. CAUTION! 1. Never use a solvent like thinners or benzene for cleaning. Using such solvents may discolor the covers. 2. Do not use any sharp object to clean the LCD display.
7. TROUBLESHOOTING EO1-19039 7. TROUBLESHOOTING 7. TROUBLESHOOTING WARNING! If you cannot solve a problem with the following solutions, do not attempt to repair it yourself. Turn the power OFF, unplug the POS terminal, then contact your TOSHIBA TEC representative for assistance. Problem The unit does not turn on Check Point • by turning on the POS terminal. Are the cables connected Solution • properly? • Properly connect the display interface cable again.
