REAR PANEL CONNECTORS
The rear panel of the recorder contains the connectors used to attach cameras, sensors, and relays to the recorder. Below are diagrams that
outline the location and description of each connector.
XVSe
16 Channel (240)
AC power
BNC looping output cable adapter Looping output termination
Video input (BNC) Sensor inputs Control outputs RCA video out Cooling fan
PTZ
Optical output
USB USB
NetworkeSATA
USB
Audio input adaptor
5.1 Surround sound
Line in – line level
Speaker out
Microphone in – not used
HDMI
DVI-I
16 Channel (240V)
AC power
BNC looping output cable adapter Looping output termination
Video input (BNC) Sensor inputs Control outputs RCA video out Cooling fan
PTZ
Optical output
5.1 Surround sound
USB USB
NetworkeSATA Line in – line level
Speaker out
Microphone in – not used
USBHDMI
DVI-I
