User manual
Table Of Contents
- Surveillix™ XVSe / DVSe
- Hardware Manual
- Manual Edition 30340AF – SEPTEMBER 2011
- Printed in USA
- About this Guide
- Technician Notes
- Product Description
- Features
- Front Panel Controls
- Rear Panel Connectors
- Identifying Included Components
- Optional Components
- Keyboard Setup
- Mouse Setup
- Monitor Setup
- Power Setup
- Making Connections on an XVSe
- Making Connections on DVSe
- Hard Drive Array (DVSe only)
- Turning on the recorder
- Turning Off the recorder
15
FEATURES
Toshiba’s Surveillix DVRs include the following new features:
• Optimized and Designed for Microsoft
®
Windows 7 Embedded
®
• Up to 32 Camera Inputs
• Supports up to 16 Relay Outputs on Alarm Activation
• Supports up to 16 Sensor Inputs for Alarm Control
• Remote System Operation & Configuration
• Supports Multiple Simultaneous Remote Connections
• PAN / TILT / ZOOM Controls
• Simultaneous Video Search, Playback and Backup
• Video Indexes for Easy Searching
• Multiple Levels of Security Access
• Up to 32 Looping Outputs
• Up to 2 Composite Outputs
• Up to 32 Network Recording Channels
• Up to 16 Audio Inputs
• High Performance, Durable, Rack mount Case
• Output the Video to a NTSC/PAL Display
• Up to 8 Terabytes internal storage
• Digital Signature Support
• Continuous, Motion Detection, Alarm, Pre-Alarm, and Scheduled Recording Modes
• Hardware Watchdog
• Recording Resolution 720x480 / 720x240 / 360x240 NTSC
720x576 / 720x288 / 360x288 PAL
