3. READ (X) AND RESET (Z) REPORTS EO1-11154
3.2 General Notes On Report Takings
3-14
INDIVIDUAL CASHIER READ or RESET (Daily or GT)
Read Report Sample
• Operation: Mode Lock: X for read
Z for reset
When the ECR is being outside a sale and in X mode, depress the
[1] or [Enter] key.
Select “CASHIER” with the [↓] or [↑] key, then depress the [6] or
[Enter] key.
Select “INDIVIDUAL CASHIER” with the [↓] or [↑] key, then depress
the [2] or [Enter] key.
Input a cashier code (01 to 08, 99) of which report is to be taken,
then depress the [AT/TL] key.
(This guidance message is displayed only when the cashier code
entry method is activated.)
In CASHIER SIGNING Method, the ID code here is the 2-digit manager-assign
portion of the Cashier Code
Cashier ID Code
& Cashier’s Name
Report for Cashier 1 (Cashier Code: 01, Cashier Name: JONES)
Same contents as Financial Reports except for GT, NET GT and NEG GT are not printed
[C] Key Count
Consignment Count
Validation Count
Money Declaration Count
Individual Cashier Read Report Count
Individual Cashier Reset Report Count (on Reset Reports only)
Receipt Consecutive No., Current Tim
TEC STORE
1343 PEACH DRIVE
PHONE: 87-6437
Open 8:00am to 7:00pm
Closed: every Wednesday
31-10-2005 MON #3001
X_CLERK
01 JONES
GS
125
€346,77
NS
112
€300,48
CLEAR 1
CONSIGN CTR 1
VALI CTR 1
M.DCR 3
0001X
0001Z
9999 19:00TM
