11. REGISTERING PROCEDURE AND PRINT FORMAT EO1-11154
11.45 When a Power Failure Occurs...
11-30
11.45 When a Power Failure Occurs...
If a power failure occurs, all sales data stored in the memory are automatically protected by the battery installed
in the ECR. The battery is rechargeable and it is recharged when the AC power returns. As the power returns,
the ECR revives to continue the work and displays the last item entered before the power failure. However,
please note the following phenomena to occur on the ECR when the power is regained:
1. The printer will work to print the entered data without failure after the power recovery, if any data was being
printed. However, one extra line may be fed on the power recovery depending on the power-recovery timing.
2. The following are the display indications on the power recovery:
ECR CONDITION at the time of Power Failure DISPLAY INDICATION on the Power Recovery
No key-in has been operated. Displays zero. Operations may go on. OUTSIDE A
SALE
Numeric or Declaration keys have
been entered but not motorized keys.
Regains the display content that was obtained just
before the power failure. The operations may be
continued.
No Numeric or Declaration keys have
been entered.
DURING A
SALE
Numeric or Declaration keys have
been entered.
Regains the display content that was obtained just
before the power failure. The operations may be
continued.
In case a power failure occurred during printing, after the power recovery, the power failure symbol “**” is printed
in one line.
Example:
-- Journal Print Format --
DP
09 €2,00
DP
09 €1,00
********************************
DP
11 €0,50
SUBTL €2,50
CASH €
2,50
MISC €3,00
CHANGE €0,50
ITEM 2
JONES 0357 18:55TM
