11. REGISTERING PROCEDURE AND PRINT FORMAT EO1-11154
11.44 Remote Slip Printer (hardware option) Operation
11-29
11.44 Remote Slip Printer (hardware option) Operation
(1) The EPSON Remote Slip Printer TM-U295 may be connected to the ECR as an optional device.
(2) The remote slip printer will operate printing if a slip is properly inserted.
(3) At a registration operation (in REG, MGR, or - mode)
• The remote slip printer will automatically activate printing when the slip has properly been set to the printer
table.
• Remote slip print compulsion for any Previous Balance entry can be selected by the program option.
• When the slip is full during a registration operation, the message “SLIP PAPER OUT” is indicated in the
LCD display and the registration operation is prohibited until another slip is properly set. Data stored in the
slip printer is printed on the slip. Subsequently the [C] key depression extinguishes the message and the
remaining data is printed.
(4) At a Read/Reset operation (in X or Z mode)
• The remote slip printer will automatically activate printing when the slip has properly been set to the printer
table.
• When the slip is full during a registration operation, the message “SLIP PAPER OUT” is indicated in the
LCD display. Data stored in the slip printer is printed on another slip which is properly set. Subsequently
the [C] key depression extinguishes the message and the remaining data is printed.
(5) The gap of the slip inlet is usually opened, and the slip may be inserted or withdrawn freely outside a
receipt/journal print sequence.
When a slip is properly set to the remote slip printer and the ECR is operated, the gap will be closed and
printing will be performed. When the sale is finalized and the receipt is issued, the gap of the remote slip
printer will be opened to allow the slip withdrawal. (The gap keeps closed during sale item entries.)
(6) The RELEASE key on the remote slip printer may be used for opening the closed gap. When pressing this
key during a print operation, the remote slip printer pauses printing and the gap is opened.
(7) Printing on the slip will be performed in the same format of receipt.
(8) If the remote slip printer turns OFF or the cable is disconnected, it may cause a” SLIP OFF LINE” error.
During the error, a connection confirmation message is indicated by the [ITEM CORR] key depression. At
this time, the [ITEM CORR] key depression again will let the slip printer disconnected. The [C] key
depression will remain the slip printer connected.
EPSON Remote Slip Printer TM-U295
Slip Paper
