9. FUNCTIONS OF EACH KEY EO1-11154
9. FUNCTIONS OF EACH KEY
9- 3
Key Functions
Reference
page
Subtotal key
Used to obtain subtotal of the current transaction.
11-12
Cash Amount Tendered/Cash Total key
Used to record all cash paid transactions, and will be able to finalize
a sale operation.
11-15
Cheque key
This is one of non-cash media keys, and used to cash a cheque
when the ECR is outside a sale, or to finalize the transaction as a
cheque payment.
11-15,17
Credit key
This is another non-cash media key, and usually programmed as
“Credit Sale Total” key.
11-15
Media-Coupon key
This is another non-cash media key, and usually programmed as
“Coupon Tender” key.
11-15
Miscellaneous Media Key
This is one of additional non-cash media keys that may be installed
besides [CHK TEND] and [CRT]. This key has the same functions
and programmabilities as the [CHK TEND] key, and usually used
as Tender-only key.
11-15
to
Credit 1 to Credit 5 keys
These are additional non-cash media keys that may be installed
besides those already described, according to the requirements of
each store.
11-15
to
Cash Payment1 to 3 keys
Used for cash-tendering operation with the respective preset
amount.
11-15
or
Previous Balance keys
Used to enter a previous balance in a charge posting operation.
11-25
Transfer key
Used to transfer the entire balance in a charge posting operation
with no payment.
11-25
to
Tax Modifier Key(s)
Used to reverse the taxable/non-taxable status on departments,
PLUs, or other tax-status programmable keys. These keys may be
installed when the “Add-on Tax” feature is selected.
11-14
Tax Exempt key
Used to declare the exemption of the taxes from the sale.
11-14
Salesperson key
Used to record sales contribution data of each salesperson for
report purpose.
11-23
Repeat key
Used to repeat a department or PLU item entry.
11-5
to
Foreign Currency keys
Used in tendering or exchange with foreign currencies.
11-20,21
TX1/M
TX8/M
EX
SALES
PERSON
RPT
ST
AT/TL
CRT
MISC
TEND
PB+
PB-
CREDIT
1
CREDIT
5
TRF
CPN
CASH 1
CASH 3
CUR
1
CUR
5
CHK
TEND
