4. PROGRAMMING OPERATIONS EO1-11154
4.19 %+ and %- Preset Rate Setting
4-58
4.19 %+ and %- Preset Rate Setting
A preset rate may be set on each of the [%+] and [%-] keys, one independent rate for each key. Once a rate is
preset, the % key will simply be depressed without a prior rate entry to active the preset rate. If a rate is entered
prior to the depression of the key, the entered rate (manual rate) will be activated instead.
Any time outside a sale
Mode Lock: SET
1) Menu Tree
2) Operation Flowchart
Main Menu
ECR is being outside a sale and in SET mode.
Depress [↓] three times then [Enter].
or
Depress [4].
“4 RATE, LIMIT AMOUNT” is selected.
Depress the [1] or [Enter] key.
Select a [%] key to be programmed
with the [↓] key.
To select [%-] key, depress [1] or [Enter].
To select [%+] key, depress [2] or depress [↓] then [Enter].
[Enter]
Input a Preset Rate.
0,001 to 99,999 (%): Use the [.] key if decimal portion is contained.
(See NOTE below.)
[End]
This setting is ended. A long receipt is issued and the display
returns to Main Menu screen.
NOTE: When inputting 0, the % preset rate will be cancelled. If doing so, the % preset rate should be set at the
registration operation.
OPERATION
CONDITION
