Operation Manual

4. PROGRAMMING OPERATIONS EO1-11154
4.9 Store Name Message Programming
4-26
(continued from the previous page)
Operation LCD Display Remarks
The [Enter] key depression results in
that the input message is entered and
displayed.
When the [Enter] key is depressed, the
message programmed in the 2nd line is
printed.
Example of key operation)
[→] [→] [→] [→] [→] [→] [→] [3] [0] [1] [#]
[3] [0] [3] [#] [3] [0] [4] [#] [3] [0] [3] [#] [→]
[P] [E] [A] [C] [H] [→] [D] [R] [I] [V] [E]
[Enter]
The [Enter] key depression allows the
ECR to enter the 3rd line message
input mode. ( A is shown on the
upper-right corner of the LCD display
screen.) The 3rd line message is
input.
Numbers of programmed characters and of
programmable characters are displayed on
the 7-segment numeric display.
The [Enter] key depression results in
that the input message is entered and
displayed.
When the [Enter] key is depressed, the
message programmed in the 3rd line is
printed.
Example of key operation)
[→] [→] [→] [→] [→] [→] [→][→] [P] [H] [O]
[N] [E] [3] [1] [0] [#] [→] [3] [0] [8] [#] [3] [0]
[7] [#] [2] [1] [3] [#] [3] [0] [6] [#] [3] [0] [4]
[#] [3] [0] [3] [#] [3] [0] [7] [#] [Enter]
The [Enter] key depression allows the
ECR to enter the 4th line message
input mode. ( A is shown on the
upper-right corner of the LCD display
screen.) The 4th line message is
input.
Numbers of programmed characters and of
programmable characters are displayed on
the 7-segment numeric display.
The [Enter] key depression results in
that the input message is entered and
displayed.
When the [Enter] key is depressed, the
message programmed in the 4th line is
printed.
Example of key operation)
[Enter] (No message is input.)
The [End] key depression allows the
ECR to end this programming.
A long receipt is issued and the display
returns to Main Menu screen.
NOTE: In the above example, characters except for alphabets are
entered using the character code entry method.
31-10-2005 MON #0
STORE NAME
1
TEC STORE
2
1343 PEACH DRIVE
3
PHONE: 87-6437
4
0017 16:59TM
