Operation Manual

4. PROGRAMMING OPERATIONS EO1-11154
4.2 Character Entries
4- 8
Character Setting Operations
• To set a one-byte character, enter the COL (column) code and then the ROW code, followed by the [#] key.
ex.) To set “%”, enter 205 and depress the [#] key.
To set “kg”, enter1508 and depress the [#] key.
• To set a space instead of a character, simply depress the [#] key without a prior entry, or enter 200 and
depress the [#] key.
• To set two-byte characters, depress the [Dbl] key to declare the two-byte character entry, then enter a
character code, followed by the [#] key. The [Dbl] key declaration is effective until this key is depressed again.
ex.) To set “GROUP” all in two-byte characters:
[Dbl]
407 [#] 502 [#] 415 [#] 505 [#] 500 [#]
G R O U P
Two-byte character declaration
ex.) To set “GROUP”, “G” in two bytes, and “ROUP” in one byte:
[Dbl]
407 [#] [Dbl] 502 [#] 415 [#] 505 [#] 500 [#]
G R O U P
Two-byte character Cancelling
declaration the declaration
