8.JOB STATUS

5.Print Status Display (Cont.)

Place the specified size of paper on the bypass tray, and then press

the [START] button.

• Printing is performed. Press the [JOB STATUS] button.

Printing by placing appropriate size of sheets in the drawer

Press the drawer button whose size you want to change on the touch

panel.

• You can select the desired drawer with the paper source selection ( / ) buttons.

Place paper in the corresponding drawer.

Press the blinking [JOB STATUS] button.
