8.JOB STATUS

1. Job Status

When you press the [JOB STATUS] button on the control panel, the job status menu is displayed. The fol-

lowing information can be confirmed on this menu.

• Status of jobs (print, Internet Fax and scan) in waiting

• Log list of jobs (print, sending/receiving, scan) performed

• Print status

You can also start, pause, release, delete and move the job in waiting.

• For the status confirmation of the Fax job, see the Operator’s Manual for Facsimile Function.

• The Scanner Kit or the Printer/Scanner Kit (both optional) is necessary for the scanning function.

• The FAX Unit (optional) is necessary for the Fax function.

• The Scanner Kit or the Printer/Scanner Kit (both optinal) is necessary for the Internet Fax and E-mail

functions.

• The Printer Kit or the Printer/Scanner Kit (both optional) is necessary for printing from a client PC

through the network.
