5.USING THE EDITING FUNCTIONS

9.COVER SHEET (Cont.)

Press the [START] button.

• When the Reversing Automatic Document Feeder is used, the original is scanned and copying starts.

• When the original is placed on the original glass, perform steps 8 and 9.

Press the [YES] button and place the next original. Then press the

[START] button.

• Repeat this step until all the originals have finished being scanned.

After all the originals have finished being scanned, press the [FIN-

ISHED] button.

• Copying starts.
