5. Original Mode

You can select the most appropriate image processing mode (= original mode) for your original from the

following 3 modes.

[TEXT/PHOTO]: Original with text and photographs (default setting at installation)

[TEXT]: Original with text only (or text and line art only)

[PHOTO]: Original with photographs only

Place paper in the drawer(s).

Place the original(s).

Press the original mode button on the basic menu.

Select and press the button for the most appropriate original mode

for your original.

• Set other copy modes as required.

Press the [START] button.
