12.SPECIFICATIONS & OPTIONS
1.e-STUDIO520/600/720/850 Specifications (Cont.)
12
Continuous copying speed
sheets/min.
• The bypass copying speed is as listed above when specifying the paper size; however when the paper
size is not specified, the copy speed of all sizes is on ‘*1’.
• The values above are measured when originals are set on the original glass, 1-sided, 100% and non-
sort multiple copies are made.
• “Face up” and “Face down” in the table mean the paper exit faces.
• Only A4-sized paper can be set in the Tandem Large Capacity Feeder.
• This specification varies depending on the copying conditions and the environment.
Paper
type
Paper size Feeder
e-STUDIO520 e-STUDIO600 e-STUDIO720 e-STUDIO850
Face
up
Face
down
Face
up
Face
down
Face
up
Face
down
Face
up
Face
down
Plain
paper
(64 -
80
g/m
2
)
A4, A5-R, B5,
LT, ST-R,
8.5" SQ
Drawer /
Tandem LCF
52 52 60 60 72 72 85 85
Bypass 45 45 46 46 46 46 50 50
A4-R, B5-R,
LT-R
Drawer 42 42 46 46 52 50 61 56
Bypass 37 37 38 38 38 38 42 42
B4, FOLIO, LG,
COMP, 13" LG
Drawer 37 37 41 38 44 41 52 45
Bypass 32 32 34 34 34 34 38 38
A3, LD Drawer 33 31 36 32 37 34 43 37
Bypass
*1
28 28 30 30 30 30 34 34
Thick 1
(- 105
g/m
2
)
A4, A5-R, B5,
LT, ST-R,
8.5" SQ
Drawer /
Tandem LCF
52 52 60 60 72 72 85 85
Bypass 45 45 46 46 46 46 50 50
A4-R, B5-R,
LT-R
Drawer 42 42 46 46 52 50 61 56
Bypass 37 37 38 38 38 38 42 42
B4, FOLIO, LG,
COMP, 13" LG
Drawer 37 37 41 38 44 41 52 45
Bypass 32 32 34 34 34 34 38 38
A3, LD Drawer 33 31 36 32 37 34 43 37
Bypass
*1
28 28 30 30 30 30 34 34
Thick 2
(- 163
g/m
2
)
A4, A5-R, B5,
LT, ST-R,
8.5" SQ
Drawer /
Tandem LCF
52 52 60 60 72 72 85 85
Bypass 45 45 46 46 46 46 50 50
A4-R, B5-R,
LT-R
Drawer 42 42 46 46 52 50 61 56
Bypass 37 37 38 38 38 38 42 42
B4, FOLIO, LG,
COMP, 13" LG
Drawer 37 37 41 38 44 41 52 45
Bypass 32 32 34 34 34 34 38 38
A3, LD Drawer 33 31 36 32 37 34 43 37
Bypass
*1
28 28 30 30 30 30 34 34
Thick 3
(- 209
g/m
2
)
A4, A5-R, B5,
LT, ST-R,
8.5" SQ
Drawer /
Tandem LCF
52 52 60 60 65 65 72 72
Bypass 45 45 46 46 46 46 46 46
A4-R, B5-R,
LT-R
Drawer 42 42 46 46 50 48 52 50
Bypass 37 37 38 38 38 38 38 38
B4, FOLIO, LG,
COMP, 13" LG
Drawer 37 37 41 38 43 40 44 41
Bypass 32 32 34 34 34 34 34 34
A3, LD Drawer 33 31 36 32 37 34 37 34
Bypass
*1
28 28 30 30 30 30 30 30
