8. “READY (HOLE PUNCH DUST BIN IS FULL)”

This message appears when the hole punch dustbin in the Hole Punch Unit (optional) becomes full. To

dispose of the paper bits, follow the procedure below.

Dispose of the paper bits.

Attach the hole punch dustbin.

Close the cover of the Hole Punch Unit.

Open the cover of the Hole Punch Unit.

Pull out the hole punch dustbin.
