Clearing functions selected

When you press the selected button, the function which has been selected is cleared. Or the selected set-

ting is cleared automatically by the automatic function clear* when the equipment has been left inactive for

a specified period of time.

* Automatic function clear:

This function works when a specified period of time has passed since the last paper exit or the last entry of

any button. This function returns all the function settings to default without the need to press the [FUNC-

TION CLEAR] button. When the department management function is being used, the display returns to the

department code input menu. When this function is not being used, the display returns to the basic menu

of the copier function.

The period for the automatic function clear is set at 45 seconds by default at the time of installation of the

equipment. See the User Functions Guide for change of this setting.

Adjusting the contrast of the touch panel

Turn this adjustment volume on the left side of the control panel to adjust the contrast of the touch panel.
